BHS SERIES
7∼15W DC/DC CONVERTERS
Single Output & Dual Outputs
■ Pin Outs & Dimensions
<Top View>
69
(±0.5mm)
10.16
±0.3
15.24
±0.3
15.24
±0.3
15.24
±0.3
40
±0.3
43
49
±0.3
4-M3 Through
H8.5×W50×L69 (mm)
55
Thermal Radiation Plate
■ Features
●
●
●
●
●
●
●
●
●
●
●
●
●
●
4.5
4.9
15
34
50
Low Profile 8.5mm
Internal Input Filtering
Input-Output Isolation
High Efficiency 77∼88％
Wide Input Voltage Range
High Reliability
6 Sided Metal Shielding
Remote ON/OFF Control
Adjustable Output Volt. ±5％
Output Over Voltage Protection
115∼140％ Operation
Operating Ambient Temperature
−40℃∼＋85℃
Max. Case Temperature
＋105℃
Conforming to RoHS Directive
Not built-in aluminum and
tantalum electrolytic capacitor
●
●
●
●
●
●
●
●
●
●
●
●
●
●
薄型 8.5mm
入力フィルタ内蔵
入出力間絶縁
高効率 77∼88％
広範囲な入力電圧
高信頼性
６面メタルシールド
ﾘﾓ½ﾄON/OFF½ﾝﾄﾛ½ﾙ
可変出力電圧 ±5％
出力過電圧保護回路内蔵
115∼140％ 動½
動½周囲温度
−40℃∼＋85℃
最大ケース温度
＋105℃
RoHS指令対応
アルミ電解コンデンサ及び
タンタルコンデンサ不½用
8.5
Name Plate
V. ADJ
7
2
0.5
8
Magnification
φ1.2
φ4
Single Output
＋Vdc in
0 Vdc in
ON/OFF Control
＋Vdc out
0 Vdc out
No Connection
Dual Outputs
＋Vdc in
0 Vdc in
ON/OFF Control
＋Vdc out
Common
−Vdc out
0.5
Terminal
Case
Isolation Bush
■ Soldering Method
Heat Shrinkable Tube
■ Option Heat Sink
4-φ3.3
40
±0.3
Soldering
Lead
49
±0.3
55
12
46.5
■ General Characteristics
●
●
●
●
●
●
Input Voltage,Range
Output Voltage,Current
Output Voltage,Range
Efficiency
Line Regulation
Load Regulation
●
Reflected Input Ripple Noise
●
Output Ripple
●
Output Noise
●
Short Circuit Protection
●
Over Voltage Protection
●
Remote ON/OFF Control
●
Temperature Coefficient
●
Operating Ambient Temp.
●
Max. Plate Temperature
●
Storage Temperature
●
Isolation Voltage
●
Isolation Impedance
●
Weight
●
Humidity
●
Shock
●
Vibration
●
Surface Structure
●
MTBF
●
Warranty
(at Ta:25℃, Full Load, Nominal Vin)
DC 5, 12, 24, 48V (See Table 1)
See Table 1
See Table 1, ±5％ Adjustable
See Table 1
±0.3％ max. (at Vin Range)
Single : ±0.5％ max. (0∼100％ Load)
Dual : ±3％ max. (10∼100％ Load)
(3％ Vin)Vp-p max.
40mVp-p max.
(48V Vout : 100mVp-p max.)
100mVp-p max.
(48V Vout : 200mVp-p max.)
Built-in, Auto-restart (See Fig 2)
115∼140％ Output Voltage
ON : Short or 0∼0.8V
OFF : Open or 2∼10V
(Between pin ② ∼ ③ )
0.02％／℃ max.
−40℃∼＋85℃ (See Fig 1)
−30℃∼＋85℃ (5V Vin)
＋105℃
−40℃∼＋115℃
AC1500V one minute
(Input−Output−Case)
100MΩ min. (at DC1000V)
(Input−Output−Case)
Main Body : 60g max.
Heat Sink : 40g max.
20∼95％ RH
490m/s
2
(11msec 3directions)
10∼55Hz 98m/s
2
(30minutes 3directions)
6 Sided Aluminium Case
Single : 1,000,000H
Dual : 700,000H
(Ta:25℃, 80％Load, Nominal Vin)
5 years
■ Selection Guide
Input Volt.
(Range)
(V. DC)
＊Option Heat Sink Model : A4-3080
Table 1
Efficiency
(Typical)
(％)
83
82
82
84
83
83
83
77
81
81
83
85
85
85
85
85
85
85
78
83
83
84
86
86
86
86
86
86
85
78
83
83
83
86
86
88
88
86
86
80
85
85
Output
Output
Current
Voltage
Model Number
(A)
(V. DC)
B H S 5 −3.3 S
2A
2
3.3
BHS 5− 5S
2A
2
5
B H S 5 − 6 S 1.8 A
1.8
6
B H S 5 −1 2 S
1A
1
12
B H S 5 −1 5 S 0.8 A
0.8
15
5
B H S 5 −2 4 S 0.5 A
0.5
24
(4.5∼9)
B H S 5 −2 8 S 0.4 A
0.4
28
BHS 5− 5D
1A
±1
± 5
B H S 5 −1 2 D 0.5 A
±0.5
±12
B H S 5 −1 5 D 0.4 A
±0.4
±15
B H S 1 2 −3.3 S 2.4 A
2.4
3.3
B H S 1 2 − 5 S 2.4 A
2.4
5
B H S 1 2 − 6 S 2.2 A
2.2
6
B H S 1 2 −1 2 S 1.3 A
1.3
12
B H S 1 2 −1 5 S
1A
1
15
12
B H S 1 2 −2 4 S 0.65 A
0.65
24
(8∼18)
B H S 1 2 −2 8 S 0.5 A
0.5
28
B H S 1 2 −4 8 S 0.3 A
0.3
48
B H S 1 2 − 5 D 1.2 A
±1.2
± 5
B H S 1 2 −1 2 D 0.65 A
±0.65
±12
B H S 1 2 −1 5 D 0.5 A
±0.5
±15
B H S 2 4 −3.3 S 2.4 A
2.4
3.3
B H S 2 4 − 5 S 2.4 A
2.4
5
B H S 2 4 − 6 S 2.2 A
2.2
6
B H S 2 4 −1 2 S 1.3 A
1.3
12
B H S 2 4 −1 5 S
1A
1
15
24
B H S 2 4 −2 4 S 0.65 A
0.65
24
(16∼36)
B H S 2 4 −2 8 S 0.5 A
0.5
28
B H S 2 4 −4 8 S 0.3 A
0.3
48
B H S 2 4 − 5 D 1.2 A
±1.2
± 5
B H S 2 4 −1 2 D 0.65 A
±0.65
±12
B H S 2 4 −1 5 D 0.5 A
±0.5
±15
B H S 4 8 −3.3 S 2.4 A
2.4
3.3
B H S 4 8 − 5 S 2.4 A
2.4
5
B H S 4 8 − 6 S 2.2 A
2.2
6
B H S 4 8 −1 2 S 1.3 A
1.3
12
B H S 4 8 −1 5 S
1A
1
15
48
B H S 4 8 −2 4 S 0.65 A
0.65
24
(32∼76)
B H S 4 8 −2 8 S 0.5 A
0.5
28
B H S 4 8 − 5 D 1.2 A
±1.2
± 5
B H S 4 8 −1 2 D 0.65 A
±0.65
±12
B H S 4 8 −1 5 D 0.5 A
±0.5
±15
※ 上記仕様以外にも対応可½ですので お問い合わせ下さい。
Please consult with us about other specification.
φ2
3
Pin Outs
BHS SERIES
■ Block Diagram
