5026A13119 Product Details
Coaxial Cable (RGType, Cheminax, Ethernet and Twin
Ax)
Always EU RoHS/ELV Compliant
(
Statement of Compliance
)
Product Highlights:
Cable Type = Cheminax
Conductor Type = TinPlated Copper
Impedance (Nominal) = 50 Ω
Cable Diameter = 2.13 mm
Wire Size = 26 mm² [AWG]
View all Features
Share
Print
Email
Quick Links
Pricing & Availability
Search for Tooling
Product Feature Selector
Contact Us About This Product
5026A13119
TE Internal Number: 440246000
Active
Add to My Part List
Request Sample
Find Similar Products
Buy Product
Documentation & Additional Information
Product Drawings:
CHEMINAX 50 OHM, AWG 26, 7 STRANDS OF AWG 34, COAXIA... (PDF, English)
Catalog Pages/Data Sheets:
None Available
Product Specifications:
None Available
Application Specifications:
None Available
Instruction Sheets:
None Available
CAD Files:
None Available
Additional Information:
Product Line Information
Related Products:
Tooling
List all Documents
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
Cable Type = Cheminax
Wire Size (mm² [AWG]) = 26
Dielectric Material = Rayfoam L
Cable Style = RoundBraid Single Shielded
Electrical Characteristics:
Impedance (Nominal) (Ω) = 50
Velocity of Propagation, Nominal (%) = 78
Capacitance (pF/ft) = 27.1
Dimensions:
Cable Diameter (mm [in]) = 2.13 [.084]
Body Features:
Conductor Type = TinPlated Copper
Wire Diameter, Nominal (mm [in]) = 0.48 [0.019]
Shield Material = TinPlated Copper
Cable Jacket Color = White
Cable Jacket Material = Thermorad
Display Features:
Dielectric Diameter (mm [in]) = 1.19 [0.047]
Industry Standards:
Approved Standards = UL 1837, 3258, 3259 and 3264
RoHS/ELV Compliance = RoHS compliant, ELV compliant
Lead Free Solder Processes = Not relevant for lead free process
RoHS/ELV Compliance History = Always was RoHS compliant
Packaging Features:
Wire Source = United States
Other:
Brand = Raychem
