1-1761465-4

Description
PCI Express RA assy 5.8mm slot 3.1mm pc
CategoryThe connector    The connector
File Size787KB,3 Pages
ManufacturerTE Connectivity
Websitehttp://www.te.com
Environmental Compliance
Download Datasheet Parametric View All

1-1761465-4 Online Shopping

Suppliers Part Number Price MOQ In stock
1-1761465-4 - - View Buy Now

1-1761465-4 Overview

PCI Express RA assy 5.8mm slot 3.1mm pc

1-1761465-4 Parametric

Parameter NameAttribute value
Brand NameAMP
Is it Rohs certified?conform to
MakerTE Connectivity
Reach Compliance Codecompliant
ECCN codeEAR99
Is SamacsysN
Other featuresROHS AND ELV COMPLIANT
Board mount optionsPEG
body width0.37 inch
subject depth0.772 inch
body length3.504 inch
Body/casing typeRECEPTACLE
Connector typeCARD EDGE CONNECTOR
Contact to complete cooperationNOT SPECIFIED
Contact materialNOT SPECIFIED
contact modeRECTANGULAR
Contact resistance30 mΩ
Contact styleBELLOWED TYPE
Dielectric withstand voltage500VAC V
Durability50 Cycles
Insulation resistance100000000 Ω
Insulator colorBLACK
insulator materialTHERMOPLASTIC
Plug contact pitch0.039 inch
Installation methodRIGHT ANGLE
Installation typeBOARD
Number of connectorsONE
PCB row number4
Number of rows loaded2
Maximum operating temperature85 °C
Minimum operating temperature-40 °C
PCB contact patternSTAGGERED
Plating thickness30u inch
Rated current (signal)1.1 A
GuidelineUL
reliabilityCOMMERCIAL
Terminal length0.091 inch
Termination typeSOLDER
Total number of contacts164
Base Number Matches1
