SPECIFICATIONS
Current Rating:
Contact Material:
Contact Resistance:
Insulation Material:
Insulation Resistance:
Shell Material:
Withstanding:
Operating Temp:
C
3.0 Amps
Copper, Gold Plating
10 mΩ Max.
PBT Thermoplastic, UL94V-0, Black
5GΩ Min
Steel, Front Shell Tin Finished
Back Shell Tin Finished
Dimples on Plug Only
1000V AC min.
-55ºC ~ +125ºC
B
C
D
D
E
Series
Type
Footprint
HDSXX
MM
E
XX=Pins FM=Machined pin, E=.35 (8.89mm)
15,26,44,
R/A female
62,78
MM=Machined pin,
R/A male
Shell Plating
TN
TN = Tin
Mounting
XX
01=#4-40 jackscrews w/bracket
01S=#4-40 Steel jackscrews
installed
02=.118” through-hole
03=Riveted clinch nut
F
RoHS compliant
Rev.
Description
Date
Approved
Drawing
Name
Approved Howard
Checked Lizzy
Drawn Tina
0.0 ± 0.35
1
2
3
4
Options
XX
[blank]=White Insulator
BK=Black insulator
30GD=30µ” gold
P=Plastic Bracket
M=Metal Bracket
MBL=Metal Bracket w/ Board Locks
MPS=Metal Bracket w/ plastic pin support
E
F
Date
07/31/09
07/31/09
07/31/09 Part No.:
Central Components Manufacturing
440 Lincoln Blvd., Middlesex, New Jersey 08846
Phone 732 469-5720 888 288-5152 Fax 732 469-1919
HDS26-MM-E-TN-03-MPS
G
7
8
9
G
0.00 ± 0.20 Angles ± 3’
UNIT: mm
5
6
Description: D-Subminiature connector, Right Angle, Open Type
Machine-Pin, Male. 8.89mm Footprint
