MILITARY DUAL-IN-LINE SOCKETS
MIL-S-83734 APPROVED
3 Level Wrapost, Closed Frame
0,38-.064
0,25 0,46
B
Series 223...101
•
Sockets are XY stackable.
•
Machined outer sleeve with Hi-
Rel, BeCu #30 inner contact.
2,79
4,9
2,36
4,11
•
Socket pins feature closed-end
construction eliminating any
solder/flux wicking problems.
•
Series 223 use MM #0038-3
pins. See page 166 for details.
0,64
SQUARE
12,95
•
Insulators are high temperature
thermoplastic.
Total number
of pins
Quantity
per tube
Ordering Information
Mill-Max Part Number
Military Part Number
M83734/1-YYY
M83734/2-YYY
M83734/3-YYY
M83734/4-YYY
M83734/5-YYY
M83734/13-YYY
M83734/6-YYY
M83734/8-YYY
M83734/7-YYY
M83734/17-YYY
M83734/10-YYY
M83734/15-YYY
2,54
A
7,6
10,1
17,7
20,3
22,8
25,3
B
7,62
7,62
7,62
7,62
7,62
7,62
C
10,1
10,1
10,1
10,1
10,1
10,1
67
50
28
25
22
20
18
16
14
10
8
6
6
8
14
16
18
20
22
24
28
32
40
64
223-XX-306-41-101000
223-XX-308-41-101000
223-XX-314-41-101000
223-XX-316-41-101000
223-XX-318-41-101000
223-XX-320-41-101000
223-XX-422-41-101000
223-XX-624-41-101000
223-XX-628-41-101000
223-XX-632-41-101000
223-XX-640-41-101000
223-XX-964-41-101000
27,8 10,16 12,7
30,4
35,5
40,6
50,8
15,24
15,24
15,24
15,24
17,7
17,7
17,7
17,7
81,2 22,86 25,3
For Electrical,
Mechanical & Enviromental
Data, See pg. 4
XX=Plating Code
See Below
SEE PAGE 35 FOR COMPLETE QPL
SPECIFY MILL-MAX PLATING CODE XX=
FOR MILITARY CODE YYY=
33
010
007
0,76μm Au
83
011
008
88
012
009
(
32 PIN ONLY) YYY=
Sleeve (Pin)
Contact (Clip)
0,76μm Au
7,62μm Sn/Pb 7,62μm Sn/Pb
0,76μm Au
2,54μm Sn/Pb
w w w. m i l l - m a x . c o m
34
516-922-6000
