NCP612, NCV612
100 mA CMOS Low Iq
Voltage Regulator in an
SC70−5
The NCP612/NCV612 series of fixed output linear regulators are
designed for handheld communication equipment and portable battery
powered applications which require low quiescent. The
NCP612/NCV612 series features an ultra−low quiescent current of
40
mA.
Each device contains a voltage reference unit, an error
amplifier, a PMOS power transistor, resistors for setting output
voltage, current limit, and temperature limit protection circuits.
The NCP612/NCV612 has been designed to be used with low cost
ceramic capacitors. The device is housed in the micro−miniature
SC70−5 surface mount package. Standard voltage versions are 1.5,
1.8, 2.5, 2.7, 2.8, 3.0, 3.1, 3.3, 3.7, and 5.0 V.
Features
http://onsemi.com
MARKING
DIAGRAM
SC70−5
(SC−88A/SOT−353)
SQ SUFFIX
CASE 419A
5
xxxM
G
G
M
5
1
1
xxx = Specific Device Code
M = Date Code*
G
= Pb−Free Package
•
•
•
•
•
Low Quiescent Current of 40
mA
Typical
Low Dropout Voltage of 230 mV at 100 mA and 3.0 V V
out
Low Output Voltage Option
Output Voltage Accuracy of 2.0%
Temperature Range of −40°C to 85°C (NCP612)
Temperature Range of −40°C to 125°C (NCV612)
•
NCV Prefix for Automotive and Other Applications Requiring Site
and Control Changes
•
Pb−Free Packages are Available
Typical Applications
(Note: Microdot may be in either location)
*Date Code orientation and/or position may vary
depending upon manufacturing location.
PIN CONNECTIONS
V
in
Gnd
Enable
1
2
3
(Top View)
4 N/C
5 V
out
•
•
•
•
Cellular Phones
Battery Powered Consumer Products
Hand−Held Instruments
Camcorders and Cameras
Battery or
Unregulated
Voltage
Vout
C1
+
1
2
5
+
C2
ORDERING INFORMATION
See detailed ordering and shipping information in the package
dimensions section on page 9 of this data sheet.
ON
OFF
3
4
This device contains 86 active transistors
Figure 1. Typical Application Diagram
©
Semiconductor Components Industries, LLC, 2007
1
January, 2007 − Rev. 1
Publication Order Number:
NCP612/D
NCP612, NCV612
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
Á Á
Á
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
ÁÁÁÁÁÁÁÁ
Á
Á Á
Á
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
Á Á
Á
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
ÁÁÁÁÁÁÁ
Á
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
Á Á
Á Á Á
Á
Á
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
ÁÁÁÁÁÁÁÁ
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
Á Á
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
ÁÁÁÁÁÁÁÁ
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
Á Á
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
Á Á
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
PIN FUNCTION DESCRIPTION
Pin No.
1
2
3
4
5
Pin Name
Vin
Description
Positive power supply input voltage.
Power supply ground.
Gnd
Enable
N/C
This input is used to place the device into low−power standby. When this input is pulled low, the device is
disabled. If this function is not used, Enable should be connected to Vin.
No internal connection.
Vout
Regulated output voltage.
MAXIMUM RATINGS
Rating
Input Voltage
Enable Voltage
Output Voltage
Power Dissipation and Thermal Characteristics
Power Dissipation
Thermal Resistance, Junction−to−Ambient
Operating Junction Temperature
Operating Ambient Temperature
Storage Temperature
Symbol
V
in
Enable
V
out
P
D
R
qJA
T
J
T
A
T
stg
Value
0 to 6.0
−0.3 to V
in
+0.3
−0.3 to V
in
+0.3
Internally Limited
300
+150
−40 to +125
−55 to +150
Unit
V
V
V
W
°C/W
°C
°C
°C
Stresses exceeding Maximum Ratings may damage the device. Maximum Ratings are stress ratings only. Functional operation above the
Recommended Operating Conditions is not implied. Extended exposure to stresses above the Recommended Operating Conditions may affect
device reliability.
1. This device series contains ESD protection and exceeds the following tests:
Human Body Model 2000 V per MIL−STD−883, Method 3015
Machine Model Method 200 V
2. Latch−up capability (85°C)
"200
mA DC with trigger voltage.
http://onsemi.com
2
NCP612, NCV612
ELECTRICAL CHARACTERISTICS
(V
in
= V
out(nom.)
+ 1.0 V, V
enable
= V
in
, C
in
= 1.0
mF,
C
out
= 1.0
mF,
T
J
= 25°C, unless otherwise noted.)
Characteristic
Output Voltage (T
A
= 25°C, I
out
= 10 mA)
1.5 V
1.8 V
2.5 V
2.7 V
2.8 V
3.0 V
3.1 V
3.3 V
3.7 V
5.0 V
Output Voltage (T
A
= −40°C to 85°C, I
out
= 10 mA)
1.5 V
1.8 V
2.5 V
2.7 V
2.8 V
3.0 V
3.1 V
3.3 V
3.7 V
5.0 V
Output Voltage (T
A
= −40°C to 125°C, I
out
= 10 mA) NCV612 Only
1.5 V
1.8 V
2.5 V
2.7 V
2.8 V
3.0 V
3.1 V
3.3 V
5.0 V
Output Voltage (T
A
= −40°C to 85°C, I
out
= 100 mA)
1.5 V
1.8 V
2.5 V
2.7 V
2.8 V
3.0 V
3.1 V
3.3 V
3.7 V
5.0 V
Line Regulation (I
out
= 10 mA)
1.5 V−4.4 V (V
in
= V
out(nom.)
+ 1.0 V to 6.0 V)
4.5 V−5.0 V (V
in
= 5.5 V to 6.0 V)
Load Regulation (I
out
= 1.0 mA to 100 mA)
Output Current (V
out
= (V
out
at I
out
= 100 mA) −3%)
1.5 V−3.9 V (V
in
= V
out(nom.)
+ 2.0 V)
4.0 V−5.0 V (V
in
= 6.0 V)
Symbol
V
out
1.455
1.746
2.425
2.646
2.744
2.940
3.038
3.234
3.626
4.900
V
out
1.455
1.746
2.425
2.619
2.716
2.910
3.007
3.201
3.626
4.900
V
out
1.440
1.728
2.400
2.592
2.688
2.880
2.976
3.201
4.850
V
out
1.440
1.728
2.400
2.592
2.688
2.880
2.976
3.201
3.589
4.850
Reg
line
−
−
Reg
load
I
o(nom.)
100
100
200
200
−
−
−
1.0
1.0
0.3
3.0
3.0
0.8
mV/mA
mA
1.5
1.8
2.5
2.7
2.8
3.0
3.1
3.3
3.7
5.0
1.560
1.872
2.600
2.808
2.912
3.120
3.224
3.399
3.811
5.150
mV/V
1.5
1.8
2.5
2.7
2.8
3.0
3.1
3.3
5.0
1.560
1.872
2.600
2.808
2.912
3.120
3.224
3.399
5.150
V
1.5
1.8
2.5
2.7
2.8
3.0
3.1
3.3
3.7
5.0
1.545
1.854
2.575
2.781
2.884
3.090
3.193
3.399
3.774
5.100
V
1.5
1.8
2.5
2.7
2.8
3.0
3.1
3.3
3.7
5.0
1.545
1.854
2.575
2.754
2.856
3.060
3.162
3.366
3.774
5.100
V
Min
Typ
Max
Unit
V
http://onsemi.com
3
NCP612, NCV612
ELECTRICAL CHARACTERISTICS
(continued)
(V
in
= V
out(nom.)
+ 1.0 V, V
enable
= V
in
, C
in
= 1.0
mF,
C
out
= 1.0
mF,
T
J
= 25°C, unless otherwise noted.)
Characteristic
Dropout Voltage (T
A
= −40°C to 85°C, I
out
= 100 mA,
Measured at V
out(nom)
−3.0%)
1.5 V
1.8 V
2.5 V
2.7 V
2.8 V
3.0 V
3.1 V
3.3 V
3.7 V
5.0 V
Ground Current
(Enable Input = V
in
, I
out
= 1.0 mA to I
o(nom.)
)
Quiescent Current (T
A
= −40°C to 85°C)
(Enable Input = 0 V)
(Enable Input = V
in
, I
out
= 1.0 mA to I
o(nom.)
)
Output Short Circuit Current (V
out
= 0 V)
1.5 V−3.9 V (V
in
= V
out(nom.)
+ 2.0 V)
4.0 V−5.0 V (V
in
= 6.0 V)
Output Voltage Noise (f = 100 Hz to 100 kHz)
I
out
= 30 mA, C
out
= 1
mF
Enable Input Threshold Voltage
(Voltage Increasing, Output Turns On, Logic High)
(Voltage Decreasing, Output Turns Off, Logic Low)
Output Voltage Temperature Coefficient
3. Maximum package power dissipation limits must be observed.
T
*T
A
PD
+
J(max)
R
qJA
4. Low duty cycle pulse techniques are used during testing to maintain the junction temperature as close to ambient as possible.
Symbol
V
in
−V
out
−
−
−
−
−
−
−
−
−
−
I
GND
−
I
Q
−
−
I
out(max)
150
150
V
n
−
V
th(en)
0.95
−
T
C
−
−
−
"100
−
0.3
−
ppm/°C
100
−
V
300
300
600
600
mVrms
0.03
40
1.0
90
mA
40
90
mA
530
420
270
270
250
230
210
200
180
160
680
560
380
380
380
380
380
380
380
300
mA
Min
Typ
Max
Unit
mV
http://onsemi.com
4
NCP612, NCV612
TYPICAL CHARACTERISTICS
300
NCP612SQ30
V
out
, OUTPUT VOLTAGE (V)
250
I
o
= 80 mA
200
150
I
o
= 40 mA
100
50
0
−50
I
o
= 10 mA
−25
0
25
50
75
100
125
3.015
3.010
3.005
3.000
2.995
2.990
2.985
−60
V
in
= 4.0 V
V
in
= 6.0 V
3.020
V
in
− V
out
, DROPOUT VOLTAGE (mV)
−40
−20
0
20
40
60
80
100
TEMPERATURE (°C)
TEMPERATURE (°C)
Figure 2. Dropout Voltage vs. Temperature
Figure 3. Output Voltage vs. Temperature
48
I
q
, QUIESCENT CURRENT (mA)
I
q
, QUIESCENT CURRENT (mA)
I
out
= 0 mA
V
in
= 4.0 V
V
out
= 3.0 V
60
50
40
30
20
10
0
0
V
out
= 3.0 V
C
in
= 1.0
mF
C
out
= 1.0
mF
T
A
= 25°C
46
44
42
40
−60
−40
−20
0
20
40
60
80
100
1
2
3
4
5
6
7
TEMPERATURE (°C)
V
in
INPUT VOLTAGE (V)
Figure 4. Quiescent Current vs. Temperature
60
I
gnd
, GROUND CURRENT (mA)
50
40
30
20
10
0
0
V
out
= 3.0 V
C
in
= 1.0
mF
C
out
= 1.0
mF
I
out
= 30 mA
T
A
= 25°C
70
60
RIPPLE REJECTION (dB)
50
40
30
20
10
1
2
3
4
5
6
7
Figure 5. Quiescent Current vs. Input Voltage
V
in
= 4.0 V
C
out
= 1.0
mF
I
out
= 30 mA
0
100
1000
10000
FREQUENCY (Hz)
100000
1000000
V
in
INPUT VOLTAGE (V)
Figure 6. Ground Pin Current vs. Input Voltage
Figure 7. Ripple Rejection vs. Frequency
http://onsemi.com
5
