RNF-100-MINI-SPL-3/64-BK Overview

RNF-100-MINI-SPL-3/64-BK

RNF-100-MINI-SPL-3/64-BK Parametric

Parameter Name	Attribute value
Wall type	single
Product Series	RNF-100
Voltage (max) (kV)	.6
color	black
Shrinkage	2:1
Material	Irradiated modified polyolefin
flexibility	Flexible
Fluid type	water, hydraulic oil, aviation fuel
Expand inner diameter (minimum value)	1.17 mm [ .046 in ]
Recovered inner diameter (maximum value)	.58 mm [ .023 in ]
Recovered wall thickness (nominal)	.4 mm [ .016 in ]
Recovered wall thickness (tolerance)	.15 mm [ .006 in ]
Shrinkage temperature (min) (°C)	95
Resistant	tension, friction, mechanical damage, liquid
Operating temperature range (°C)	-55 – 135
Flammability	ignition retardation
Shrinkage temperature (°C)	121
fluid resistance	splash proof
Applicable area	global, global
Encapsulation method	spool
Product source	US
Low outgassing	no

Preview

Download Datasheet

View All

RAYCHEM Tubing Products

Tubing Kits and Mini-Spools

Smaller Packaging Options

for Single Wall and

Adhesive-Lined Tubing

Products

Product Facts

VERSAFIT and RNF-100

tubing: 2:1 shrink ratio

DWP-125: 3:1 shrink ratio

ES1000: 4:1 shrink ratio

VERSAFIT tubing’s low full

recovery temperature

reduces installation time

and the risk of damage to

temperature-sensitive

components

RNF-100 offers excellent

physical, chemical, and

electrical properties that

meet or exceed commercial,

industrial and military

standards for highly

reliable, general purpose

tubing

DWP-125 and ES1000 have

high-shrink-ratios to allow

for insulation and sealing of

irregular shapes; few sizes

cover a wide range of

diameters

RoHS compliant

Heat-shrinkable Tubing

Applications

Single wall VERSAFIT and

RNF-100 tubing provide

electrical insulation and

strain relief of in-line com-

ponents, electrical connec-

tions, wire terminations, and

splices. They can be used

to bundle wires for flexible

light duty harnesses. Also

to identify or color code

wires, cables, terminals and

electronic components.

Adhesive-lined DWP-125

and ES1000 environmen-

tally seal and protect a

wide variety of electrical

applications, including wire

splices, terminations, break-

outs and connector-to-

cable transitions.

Installation

Minimum full recovery

temperature:

VERSAFIT: 90°C [194°F]

RNF-100: 121°C [250°F]

DWP-125: 125°C [257°F]

ES1000: 135°C [275°F]

Operating Temperature Range

VERSAFIT and RNF-100:

-55°C to 135°C

[-67°F to 275°F]

DWP-125:

-40°C to 110°C

[-40°F to 230°F]

ES1000:

-40°C to 130°C

[-40°F to 266°F]

Specifications/Approvals

Series

VERSAFIT

RNF-100

DWP-125

ES1000

E35586 VW-1

600 V, 125°C

E35586

600 V, 125°C

E35586

600 V, 125°C

E85381

600 V, 125°C

CSA

Raychem

RW-3009

RT-350

DWP-125 SCD

RT-1113

LR31929 VW-1

600 V, 125°C

LR31929

600 V, 125°C

—

Available in:

Americas

Europe

Asia Pacific

1-125

9-1773447-9

CIS WR 08/2011

te.com

Dimensions are in inches and

millimeters unless otherwise

specified. Values in brackets

are metric equivalents.

Dimensions are shown for

reference purposes only.

Specifications subject

to change.

USA: 1-800-522-6752

Canada: 1-905-475-6222

Mexico: 52-55-1106-0800

L. & S. America: 54-11-4733-2200

Germany: 49-6251-133-1999

China: 86-400-820-6015

Japan: 81-44-844-8013

UK: 44-800-267-666
