BCM5703
®
10/100/1000BASE-T CONTROLLER WITH INTEGRATED TRANSCEIVER
FEATURES
SUMMARY OF BENEFITS
•
Single-chip solution for LAN on Motherboard (LOM) and
•
•
•
•
•
•
400-pin FBGA package
•
3.3V I/Os (5V tolerant)
•
JTAG
network interface card (NIC) applications
•
Integrated 10BASE-T/100BASE-TX/1000BASE-T transceivers
•
10/100/1000 triple-speed MAC
•
Host interfaces
- PCI v2.2—32/64 bits, 33/66 MHz
- PCI-X v1.0—64 bits, 66/100/133 MHz
•
Ultra-deep 96-KB on-chip packet buffer
•
Dual high-speed RISC cores with 16-KB caches
- Programmable, in-line packet classification
•
SMBus 2.0 controller
•
On-chip power circuit controller and Wake on LAN (WOL)
power switching circuit
Performance features:
•
TCP, IP, UDP checksum
•
TCP segmentation
•
CPU task offload
•
Adaptive interrupts
•
Ultra-deep 96-KB packet buffer
Robust manageability:
•
PXE 2.0 remote boot
•
Alert
Standard Format—ASF
1.0 support
•
Wake on LAN
•
Out-of-box (OOB) Wake on LAN
•
Intelligent platform management interface (IPMI), version 1.5
•
Statistic gathering (SNMP MIB II, Ethernet-like MIB, Ethernet
MIB)
•
Comprehensive diagnostic and configuration software suite
•
ACPI 1.1a compliant multiple power modes
Advanced network features:
•
Priority queuing—802.1p layer 2 priority encoding; support for
four priority queues
•
Virtual LANs—802.1q VLAN tagging; support for up to 64
VLANs
•
Jumbo frames (9 KB)
•
802.3x flow control
Advanced server features:
•
Link aggregation—802.3ad, GEC/FEC, Smart Load
Balancing™ (supports heterogeneous teams)
•
Heterogeneous, mixed-speed failover
•
PCI Hot-Plug support
Low-power, 0.13-um CMOS design
•
Industry’s smallest 10/100/1000 MAC+PHY solution—power
•
•
•
•
•
•
•
•
and space optimized for LOM and low-profile NIC
applications
Completely backward-compatible:
•
To existing 10/100 network infrastructure
•
To existing PCI-based desktop and server platforms
Futureproof
•
PCI-X interface, on-chip programmable CPUs, ASF support
Performance focused—optimized for throughput and CPU
utilization
•
Adaptive interrupts
•
PCI-X eliminates PCI bottlenecks
•
Ultra-deep 96-KB packet buffer lowers CPU utilization and
avoids PCI congestion
•
CPU task offloads reduces utilization level of CPU
Robust and highly manageable
•
PXE 2.0, ACPI 1.1a, Wake on LAN, ASF 1.0, IPMI
•
Integrated cable testing—link quality, length, pair skew, pair
polarity, pair swap
Advanced features
•
VLAN, priority queuing, jumbo frames
•
RISC processors for advanced packet classification
Server class reliability, availability, and performance features
•
Link aggregation and load balancing
•
Switch-dependent
•
802.3ad (LACP), generic trunking (GEC/FEC)
•
Switch- and NIC-independent
•
Smart Load Balancing™—unique technology that supports
heterogeneous teams, and can operate with any switch
•
Failover
•
Smart Load Balancing allows heterogeneous failover
•
PCI Hot Plug
Low-power for zero airflow implementations
•
0.13-um CMOS design
•
Advanced power management
Space savings for LOM
•
400-pin FBGA package
•
No external memory
•
Integrated power circuitry
OVERVIEW
RX
10/100/1000
PHY
TX
10/100/1000
MAC
Buffer
Memory
Memory
Controller
Dual Processor
PCI/PCI-X
PLL
32-KB
Memory
EEPROM
Control
PCI/PCI-X
Bus
LED Control
SMBus
PLL
PCI
Clk
LED Signals
SMB Interface EEPROM Interface
The BCM5703 is a fully integrated 10/100/1000BASE-T Gigabit
Ethernet media access control and physical layer transceiver solution for
high performance network applications. The BCM5703 is a highly
integrated solution combining a triple-speed, IEEE 802.3 compliant
media access controller (MAC), PCI and PCI-X bus interfaces, an on-
chip buffer memory, and an integrated physical layer transceiver in a
single device. The BCM5703 is fabricated in a low-voltage, 0.13-µm
CMOS process providing a low-power system solution. The BCM5703
provides a complete single-chip Gigabit Ethernet NIC or LOM solution.
The BCM5703 includes a 10/100/1000-Mbps Ethernet MAC with full/
half-duplex capability at all speeds and a 10/100/1000 copper PHY.
Support for the following 802.3 functions is featured in the MAC: VLAN
tagging, layer 2 priority encoding, link aggregation, and full-duplex flow
control.
The device provides both PCI v2.2 and PCI-X v1.0 bus interfaces. The
BCM5703 provides a large on-chip buffer memory for stand-alone
operation. Dual on-chip high-performance processors enable custom
frame processing features, including TCP segmentation.
The transceiver is fully compatible with the IEEE 802.3 standard for
auto-negotiation of speed. Additionally, several Plug and Play
enhancements have been added to make the device even more user-
friendly. A link quality indicator LED gives installers an instant visual
indication of any issues with the wiring plant supporting operation at the
desired speed, which include physical wiring defects or channel
conditions, such as excessive cable length, return loss, crosstalk, echo,
and noise. Broadcom’s remote cable management and diagnostics
software can be used with the device to provide remote management of
the cable and a first level of diagnostics and fault isolation.
The BCM5703 continually monitors various channel conditions. The
optional wirespeed capability allows the BCM5703 to force auto-
negotiation to be automatically limited by the speed that the channel can
reliably support (rather than by the performance of the end equipment).
Target Applications of the BCM5703
Network Interface Cards (NIC) designs
LAN on Motherboard (LOM) designs
Single Port
10/100/1000
BASE-T
1000
BASE-SX
1000
BASE-LX
10/100/1000
BASE-T
PCI 2.2 Adapters
PCI-X v1.0 Adapters
PCI 2.2 Adapters
PCI-X v1.0 Adapters
PCI 2.2 Adapters
PCI-X v1.0 Adapters
Single Port
10/100/1000
BASE-T
10/100/1000
BASE-T
PCI 2.2 LOM
PCI-X v1.0 LOM
PCI 2.2 LOM
PCI-X v1.0 LOM
Dual Port
Dual Port
PCI 2.2 Adapters
Gigabit Ethernet Network Interface Cards (NICs)
and LAN-on Motherboard (LOM) applications for
servers and workstations.
BCM5703 Software Support
•
Microsoft
®
Windows
®
98, NT4.0, 2000, XP, NT64
•
Linux
®
2.2, 2.4
•
Linux64
®
•
NetWare
®
4.x, 5.x, 6.x
•
PXE 2.0
Broadcom
®
, the pulse logo,
Connecting everything
®
, and Smart Load Balancing™ are trademarks of
Broadcom Corporation and/or its subsidiaries in the United States and certain other countries. All other
trademarks mentioned are the property of their respective owners.
®
