KUP9314A1324 Product Details
Industrial Relays (General Purpose)
Converted to EU RoHS but not ELV Compliant
(
Find RoHS Compliant
Alternates
/
Statement of Compliance
)
Share
Print
Email
Quick Links
Pricing & Availability
Search for Tooling
Product Feature Selector
Contact Us About This Product
KUP9314A1324
(813931182)
TE Internal Number: 813931182
Product Highlights:
KUP93 Series
Contact Current Class = 5A to 10A Class, Less Than
16A
Contact Rated Current = 10 A
Terminal Type = PCBTHT, Quick Connect, Solder
Contact Arrangement = 3 Form B (NC)
View all Features
Active
Add to My Part List
Request Sample
Find Similar Products
Buy Product
Documentation & Additional Information
Documents are temporarily unavailable. We are working hard to correct the problem. Please try
again later.
Additional Information:
Product Line Information
Additional Product Images:
Schematic
Wiring Diagram
Related Products:
Tooling
Product Features
(Please use the Product Drawing for all design activity)
Electrical Characteristics:
Contact Current Class = 5A to 10A Class, Less Than 16A
Contact Rated Current (A) = 10
Contact Limiting Continuous Current (A) = 10
Contact Limiting Making Current (A) = 10
Contact Limiting Breaking Current (A) = 10
Insulation Initial Dielectric Between Coil/Contact Class = 1000V to
1500VA Class
Insulation Initial Dielectric Between Open Contacts (V rms) = 500
Insulation Initial Dielectric Between Contacts and Coil (V rms) =
1500
Contact Rated Voltage (VAC) = 240
Contact Rated Voltage (VDC) = 28
Contact Limiting ShortTime Current (A) = 10
Contact Switching Recommended Load, Min. = 300mA at 12V
Coil Rated Voltage (VAC) = 24
Coil Resistance (Ω) = 72
Coil Rated Power, AC (VA) = 3.00
Coil Rated Power Class = 2.0VA to 3.0VA Class
Insulation Initial Dielectric Between Adjacent Contacts (V rms) =
1500
Insulation Initial Insulation Resistance (MΩ) = 100000
Dimensions:
Mechanical Length Class = 35mm to 40mm Class
Length (mm [in]) = 38.90 [1.550]
Mechanical Width Class = 30mm to 40mm Class
Width (mm [in]) = 35.70 [1.405]
Mechanical Height Class = 40mm to 50mm Class
Height (mm [in]) = 48.40 [1.905]
Body Features:
Mount Type = PCB, Socket
Weight (g [oz]) = 86.00 [3.034]
Contact Features:
Terminal Type = PCBTHT, Quick Connect, Solder
Contact Material = AgCdO
Contact Number of Poles = 3
Configuration Features:
Contact Arrangement = 3 Form B (NC)
Coil Magnetic System = Monostable, AC
Industry Standards:
RoHS/ELV Compliance = RoHS/Not ELV Compliant
Lead Free Solder Processes = Not relevant for lead free process
RoHS/ELV Compliance History = Converted to comply with RoHS not
ELV directives
Approved/Registered Standards = UL, CSA
Environmental:
Environmental Category of Protection = RTI
Environmental Ambient Temperature, Max. (°C [°F]) = 45 [113]
Environmental Ambient Temperature Class = 0 to 50°C Class
Packaging Features:
Packaging Method = Tray
Other:
Series = KUP93
Brand = Potter & Brumfield
