RM25F1330BP datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Passive components> The resistor> RM25F1330BP

RM25F1330BP: DescriptionFixed Resistor, Metal Glaze/thick Film, 1W, 133ohm, 200V, 1% +/-Tol, 100ppm/Cel, Surface Mount, 2512, CHIP; CategoryPassive components The resistor; File Size89KB，4 Pages; ManufacturerCal-Chip Electronics; Environmental Compliance

Download Datasheet Parametric View All

RM25F1330BP Overview

Fixed Resistor, Metal Glaze/thick Film, 1W, 133ohm, 200V, 1% +/-Tol, 100ppm/Cel, Surface Mount, 2512, CHIP

RM25F1330BP Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Maker	Cal-Chip Electronics
package instruction	CHIP
Reach Compliance Code	compliant
ECCN code	EAR99
structure	Glass Coat
JESD-609 code	e3
Manufacturer's serial number	RM
Installation features	SURFACE MOUNT
Number of terminals	2
Maximum operating temperature	125 °C
Minimum operating temperature	-55 °C
Package height	0.55 mm
Package length	6.3 mm
Package shape	RECTANGULAR PACKAGE
Package form	SMT
Package width	0.5 mm
method of packing	BULK
Rated power dissipation(P)	1 W
Rated temperature	70 °C
resistance	133 Ω
Resistor type	FIXED RESISTOR
series	RM(25)
size code	2512
surface mount	YES
technology	METAL GLAZE/THICK FILM
Temperature Coefficient	100 ppm/°C
Terminal surface	Matte Tin (Sn) - with Nickel (Ni) barrier
Terminal shape	WRAPAROUND
Tolerance	1%
Operating Voltage	200 V
Base Number Matches	1

Preview

Download Datasheet

View All

Cal-Chip

Electronics, Incorporated

RM S

ERIES

Thick Film Chip Resistors - RM Series

“Fixed Chip Resistors” manufactured for more compact electronic compo-

nents and automatic mounting system.

These Chip Resistors have electrical stability and mechanical stress due to

used reliable metal glazed paste printed on Alumina substrate. Resistors will

reduce your cost and save developmental time.

FEATURES

1. Very small, thin and light weight.

2. Both flow soldering and reflow soldering are applicable.

3. Owing to the reduced lead inductance, the high frequency

characteristic is excellent.

4. Suitable size and packaging for surface mount assembly.

PART NUMBERING

(EX) 0805 1 /10 watt 5% 10ohm

100

1. Code Designation:

Thick Film Chip Resistors

2. Dimensions:

RM04

RM10

RM14

RM25

1.0x.5mm;

RM06 1.6x.8mm;

2.0xl.25mm; RM12 3.2x1.6mm

3.2x2.65mm; RM20 5.0x2.5mm;

6.3x3.1 mm

3. Resistance Tolerance:

F: ±1%; J: ±5%

4. Nominal Resistance:

5% - 3 Digit

1st 2 significant 3rd

is multiplier (10x)

1% - 4 digit

1st 3 significant

4th multiplier (10x)

0000 = jumper “0” ohm

5. Packaging:

Bulk packaging: BP

Tape packaging: CT
