310-001
O-Ring Sealed Shrink Boot Adapter
Rotatable Coupling - Standard Profile
310
CONNECTOR
DESIGNATORS
* Conn. Desig. G & J -
Consult Factory For
45° and 90°
310 F S 001 M 16 D T
Product Series
Connector
Designator
Angle and Profile
H = 45°
J = 90°
S = Straight
Basic Part No.
Shrink Boot (Table III -
Omit for None)
Drain Holes
(Omit for None)
Shell Size
(Table I)
Finish (Table II)
A-F-D-G*
H-J*-L-S
ROTATABLE
COUPLING
O-Ring
A Thread
(Table I)
F
(Table III)
Drain Holes
4 Places Optional
Cable
Entry
E (Table III)
C Typ
(Table I)
GLENAIR
SYMBOL
B
C
G
M
NF
TABLE II - STANDARD FINISHES
FINISH
Cadmium Plate, Olive Drab
Anodize, Black
Hard Coat, Anodic
Electroless Nickel
Cadmium Plate, Olive Drab Over
Electroless Nickel
See Back Cover for Complete Finish Information
and Additional Finish Options
(Table IV)
G
J
(Table IV)
H (Table IV)
K
(Table IV)
© 2005 Glenair, Inc.
CAGE Code 06324
Printed in U.S.A.
GLENAIR, INC.
•
1211 AIR WAY
•
GLENDALE, CA 91201-2497
•
818-247-6000
•
FAX 818-500-9912
www.glenair.com
E-Mail: sales@glenair.com
Series 310 - Page 2
Rotatable Coupling - Standard Profile
See inside back cover fold-out or pages 13 and 14 for unabridged Tables I and II.
TABLE III: CABLE ENTRY AND SHRINK BOOT
Shell Size - Conn. Desig.
Cable Entry
Min.
A-F-J-L-S
G-H
E Max
F Max
.250 (6.4)
08
09
.533 (13.5)
.940 (23.9)
.355 (9.0)
10
11
.605 (15.4)
.940 (23.9)
.491 (12.5)
12
13
.774 (19.7)
.940 (23.9)
.565 (14.4)
14
15
.838 (21.3)
.940 (23.9)
.690 (17.5)
17
.963 (24.5)
16
.940 (23.9)
.769 (19.5)
18
19
1.042 (26.5)
.940 (23.9)
.894 (22.7)
21
1.217 (30.9)
20
.940 (23.9)
1.019 (25.9)
1.355 (34.4)
22
23
.940 (23.9)
1.134 (28.8)
24
25
1.443 (36.7)
.940 (23.9)
1.369 (34.8)
29
1.709 (43.4)
28
.940 (23.9)
1.615 (41.0)
1.919 (48.7)
32
33
1.005 (25.5)
* Shrink Boot Supplied with "T" Option
(see Part Number Development)
Shrink Boot *
770-003S102
770-001S103
770-001S103
770-001S103
770-001S104
770-001S104
770-001S106
770-001S107
770-001S107
770-001S108
770-001S108
TABLE IV: DIMENSIONS
Shell Size - Conn. Desig.
G
H
A-F-L-S
H
Max
Max
08
09
.639 (16.2)
.810 (20.6)
11
10
.664 (16.9)
.840 (21.3)
12
13
.688 (17.5)
.860 (21.8)
15
14
.705 (17.9)
.890 (22.6)
16
17
.732 (18.6)
.910 (23.1)
18
19
.748 (19.0)
.920 (23.4)
20
21
.773 (19.6)
.940 (23.9)
23
22
.800 (20.3)
.980 (24.9)
24
25
.823 (20.9)
1.010 (25.7)
29
28
1.041 (26.4)
1.180 (30.0)
32
33
1.092 (27.7)
1.370 (34.8)
Now Available
with the “NESTOR”
J
Max
.750 (19.1)
.810 (20.6)
.870 (22.1)
.920 (23.4)
.980 (24.9)
1.020 (25.9)
1.080 (27.4)
1.140 (29.0)
1.200 (30.5)
1.480 (37.6)
1.610 (40.9)
K
Max
.920 (23.4)
.980 (24.9)
1.040 (26.4)
1.110 (28.2)
1.170 (29.7)
1.190 (30.2)
1.250 (31.8)
1.330 (33.8)
1.400 (35.6)
1.640 (41.7)
1.880 (47.8)
Glenair’s Non-Detent,
Spring-Loaded, Self-
Locking Coupling.
Add “-445” to Specify
This AS85049 Style “N”
Coupling Interface.
© 2005 Glenair, Inc.
1.
2.
3.
4.
See Shrink Boot Reference Information (page 40).
Metric dimensions (mm) are indicated in parentheses.
O-Rings not supplied with drain hole option.
O-Rings not supplied with Connector Designators A and G.
CAGE Code 06324
Printed in U.S.A.
GLENAIR, INC.
•
1211 AIR WAY
•
GLENDALE, CA 91201-2497
•
818-247-6000
•
FAX 818-500-9912
www.glenair.com
E-Mail: sales@glenair.com
Series 310 - Page 3
310
310-001
O-Ring Sealed Shrink Boot Adapter
