Note3: no suffix for CTRL function with Positive Logic (1=ON, 0=OFF)
add “N” for CTRL function with Negative Logic (0=ON, 1=OFF)
Note4: add suffix -HC for premounted Heat-sink and clips
Package
(4)
Control Logic
(3)
www.recom-power.com
REV.: 3/2017
PD-1
RP30-EW
DC/DC Converter
Specifications
measured at Ta = 25°C, nominal input voltage, full load otherwise noted
BASIC CHARACTERISTICS
Parameter
Input Voltage Range
Series
Condition
nom. Vin = 24V
nom. Vin = 48V
Vin = 24V
DC-DC ON
DC-DC OFF
DC-DC ON
DC-DC OFF
Min.
10VDC
18VDC
Typ.
24VDC
48VDC
8VDC
Max.
40VDC
75VDC
10VDC
18VDC
Under Voltage Lockout (UVLO)
Vin = 48V
Input Filter
(5)
Input Reflected Ripple Current
(6)
Input Surge Voltage
Start-up time
Operating Frequency Range
Minimum Load
% of full load
16VDC
L-C Type
20mAp-p
50VDC
100VDC
10ms
10ms
270kHz
300kHz
330kHz
0%
10%
60mVp-p
75mVp-p
100mVp-p
Open or 3.0V < Vr < 12V
Short or 0V <Vr < 1.2V
Short or 0V <Vr < 1.2V
Open or 3.0V < Vr < 12V
3mA
-0.5mA
0.5mA
nominal Vin and full load
Vin= 24V, 100ms max.
Vin= 48V, 100ms max.
Power up
Remote ON/OFF
Single
Dual
Ripple and Noise
Others
measured by 20Mhz bandwidth
5Vout
with a 0.1µF/50V MLCC
12Vout, 15Vout
Positive Logic
DC-DC ON
DC-DC OFF
DC-DC ON
DC-DC OFF
DC-DC OFF
DC-DC ON
Remote ON/OFF
(7)
Negative Logic
Input current of Remote pin (CTRL)
Notes:
Note5: An external filter capacitor is required for normal operation. The capacitor should be capable of handling 1A
ripple current for 48V/24V models.
RECOM suggest: Nippon chemi-con KY series, 220µF/100V, ESR 90m
Ω.
Note6: Simulated source impedance of 12µH. 12µH inductor in series with +Vin.
Note7: The ON/OFF control function can be positive or negative logic. The pin voltage is referenced to -Vin pin.
RP30-2405SE
95
90
85
Efficiency vs. Output Current
90
85
Efficiency vs. Input Voltage
Efficiency [%]
80
75
70
65
60
55
50
45
40
10
20
30
40
50
60
70
80
10Vin
24Vin
40Vin
90
100
Efficiency [%]
80
75
70
65
60
10
13
16
19
22
25
28
31
34
37
40
Output Current [%]
continued on next page
PD-2
REV.: 3/2017
Input Voltage [VDC]
www.recom-power.com
RP30-EW
DC/DC Converter
Specifications
measured at Ta = 25°C, nominal input voltage, full load otherwise noted
RP30-4805SEW
Efficiency vs. Output Current
95
90
85
85
80
75
70
90
Series
Efficiency vs. Input Voltage
Efficiency [%]
Efficiency [%]
18Vin
48Vin
75Vin
20
30
40
50
60
70
80
90
100
80
75
70
65
60
18
24
30
36
42
48
54
60
66
72
75
65
60
55
50
45
40
10
Output Current [%]
Input Voltage [VDC]
REGULATIONS
Parameter
Output Voltage Accuracy
Voltage Adjustability
Line Voltage Regulation
Load Voltage Regulation
(8)
Cross Regulation
Transient Response recovery time
low line to high line at full load
no load to full load
Single
Dual
Condition
Value
±1%
±10%
±0.5%
±0.5%
±1.0%
±5%
250µs
asymmetrical 25%<>100% load
25% load step change
Notes:
Note8: The dual output required a minimum 10% loading on the output to maintain specified
regulation. Operation under no-load condition will not damage these devices, however they
may not meet all listed specification.
External Output Trimming
Output Voltage Trimming
Single output Powerline converters offer the feature of trimming the output voltage over a certain range around the nominal value by using external
trim resistors. No general equation can be given for calculating the trim resistors, but the following trimtables give typical values for chosing these
trimming resistors. If voltages between the given trim points are required, extrapolate between the two nearest given values to work out the resistor
required or use a variable resistor to set the output voltage. Output can be externally trimmed by using the method shown below.
Trim up
7(7)
RU
8(8)
6(5)
8(8)
Trim down
RD
RP30-xx3.3SEW
Trim up
Vout =
R
U
=
Trim down
Vout =
R
D
=
1
3.333
57.93
1
3.267
69.47
2
3.366
26.16
2
3.234
31.23
3
3.399
15.58
3
3.201
18.49
4
3.432
10.28
4
3.168
12.12
5
3.465
7.11
5
3.135
8.29
6
3.498
4.99
6
3.102
5.74
7
3.531
3.48
7
3.069
3.92
8
3.564
2.34
8
3.036
2.56
9
3.597
1.46
9
3.003
1.50
10
3.63
0.75
10
2.97
0.65
%
Volts
kOhms
%
Volts
kOhms
continued on next page
www.recom-power.com
REV.: 3/2017
PD-3
RP30-EW
DC/DC Converter
Specifications
measured at Ta = 25°C, nominal input voltage, full load otherwise noted
RP30-xx05SEW
Trim up
Vout =
R
U
=
Trim down
Vout =
R
D
=
Trim up
Vout =
R
U
=
Trim down
Vout =
R
D
=
1
5.05
36.57
1
4.95
45.53
2
5.10
16.58
2
4.90
20.61
3
5.15
9.92
3
4.85
12.31
4
5.20
6.58
4
4.80
8.15
5
5.25
4.59
5
4.75
5.66
6
5.30
3.25
6
4.70
4.00
7
5.35
2.30
7
4.65
2.81
8
5.4
1.59
8
4.60
1.92
9
5.45
1.03
9
4.55
1.23
10
5.50
0.59
10
4.50
0.68
%
Volts
kOhms
%
Volts
kOhms
Series
RP30-xx12SEW
1
12.12
367.91
1
11.88
460.99
2
12.24
165.95
2
11.76
207.95
3
12.36
98.64
3
11.64
123.60
4
12.48
64.98
4
11.52
81.42
5
12.60
44.78
5
11.40
56.12
6
12.72
31.32
6
11.28
39.25
7
12.84
21.70
7
11.16
27.20
8
12.96
14.49
8
11.04
18.16
9
13.08
8.88
9
10.92
11.13
10
13.20
4.39
10
10.8
5.51
%
Volts
kOhms
%
Volts
kOhms
RP30-xx15SEW
Trim up
Vout =
R
U
=
Trim down
Vout =
R
D
=
1
15.15
404.18
1
14.85
499.82
2
15.3
180.59
2
14.70
223.41
3
15.45
106.06
3
14.55
131.27
4
15.60
68.80
4
14.40
85.20
5
15.75
46.44
5
14.25
57.56
6
15.90
31.53
6
14.10
39.14
7
16.05
20.88
7
13.95
25.97
8
16.20
12.90
8
13.80
16.10
9
16.35
6.69
9
13.65
8.42
10
16.50
1.72
10
13.50
2.282
%
Volts
kOhms
%
Volts
kOhms
Dual Output Voltage Trim Tables
RP30-xx12DEW
Trim up
Vout =
R
U
=
Trim down
Vout =
R
D
=
1
24.24
218.21
1
23.76
273.44
2
24.48
98.10
2
23.52
123.02
3
24.72
58.07
3
23.28
72.87
4
24.96
38.05
4
23.04
47.80
5
25.20
26.04
5
22.80
32.76
6
25.44
18.03
6
22.56
22.73
7
25.68
12.32
7
22.32
15.57
8
25.92
8.03
8
22.08
10.20
9
26.16
4.69
9
21.84
6.02
10
26.40
2.02
10
21.6
2.67
%
Volts
kOhms
%
Volts
kOhms
RP30-xx15DEW
Trim up
Vout =
R
U
=
Trim down
Vout =
R
D
=
PD-4
1
30.30
268.29
1
29.70
337.71
2
30.60
120.64
2
29.40
152.02
3
30.90
71.43
3
29.10
90.13
4
31.20
46.82
4
28.80
59.18
5
31.50
32.06
5
28.50
40.61
6
31.80
22.21
6
28.20
28.23
7
32.10
15.10
7
27.90
19.39
8
32.40
9.91
8
27.60
12.76
9
32.70
5.81
9
27.30
7.60
10
33.00
2.53
10
27.00
3.47
%
Volts
kOhms
%
Volts
kOhms
REV.: 3/2017
www.recom-power.com
RP30-EW
DC/DC Converter
Specifications
measured at Ta = 25°C, nominal input voltage, full load otherwise noted
PROTECTIONS
Parameter
Short Circuit Protection (SCP)
3.3Vout
5Vout
Zener Diode Clamp
12Vout
15Vout
% of Iout rated
I/P to O/P
I/P to O/P to case
500VDC
Notes:
Note9: This power module is not internally fused. An input line fuse must always be used.
Series
Condition
Value
continuous, automatic recovery
3.9VDC
6.2VDC
15VDC
18VDC
150% max.
115°C typ.
1.6kVDC/1minute
1.6kVDC/1minute
1GΩ min.
1000pF max.
Over Voltage Protection (OVP)
Over Load Protection (OLP)
Over Temperature Protection (OTP)
Isolation Voltage
Isolation Resistance
Isolation Capacitance
ENVIRONMENTAL
Parameter
Operating Temperature Range
Maximum Case Temperature
Temperature Coefficient
Thermal Impedance
(10)
Operating Humidity
Thermal Shock
Vibration
MTBF
MIL-HDBK-217F
Bellcore TR-NWT-000332
(10)
RP30-483.3SEW
100
80
60
40
20
0
-40
100
80
60
40
20
0
-40
Condition
without derating
with derating
Value
-40°C to +70°C
-40°C to +100°C
+100°C
±0.02%/°C max.
Natural convection (20LFM)
Natural convection (20LFM) with Heat-sink
10°C/Watt
8.24°C/Watt
5% - 95% RH
MIL-STD-810F
MIL-STD-810F
759.8 x 10
3
hours
1315 x 10
3
hours
RP30-483.3SEW with Heat-sink
Derating Graph
(11)
Output Power [%]
Output Power [%]
-20
0
20
40
60 70 80
100 120
-20
0
20
40
60
Ambient Temperature [°C]
Ambient Temperature [°C]
80
75
100 120
Notes:
Note10: BELLCORE TR-NWT-000332. Case l: 50% Stress, Temperature at 40°C (Ground fixed and controlled environment).
Note11: Derating graphs are valid only for the shown part numbers. If you need detailed derating-information about a part-
number not shown here please contact our technical support service at techsupportAT@recom-power.com
