MITSUMI
H=1mm Paper Slide Switches
SSP Series
Switches
FEATURES
1. Super thin 1mm (horizontal), 1.08mm (vertical)
in height.
2. SMT type and reflow-soldering for surface
mounting.
3. Taped packaging for automatic mounting.
4. 2 types.1-circuit, 2-contacts (SSP-122***), 1-
circuit, 3-contacts (SSP-132MHT).
5. Changeover timing is not specified.
SSP-132MHT
(Horizontal)
SSP-122BHT
(Horizontal)
SSP-122RVT
(Vertical)
USES
1. Function selector switches for portable audios, radios, LCD TV sets, video cameras, and such.
2. Write protect switches for memory cards.
MODEL NAME CODE
SSP-122BHT
T (Taping)
H (Horizontal)
V (Vertical)
M (Horizontal, with boss)
B (Horizontal, with boss)
R (Vertical, without boss)
2 (With Earth Terminals)
Number of contacts
2
3
1 (Number of circuits)
P (H=1mm Paper Slide Switches)
S (Slide)
S (Switch)
SPECIFICATIONS
Electrical
Characteristics
Mechanical
Characteristics
Life
Rating
Contact Resistance
Insulation Resistance
Withstand Voltage
Operating Force
0.3A, 4V DC
200mΩ or less
100MΩ or more
1 minute at 100V AC
1.47 ± 1N(150 ± 100gf)
Horizontal 10,000cycles
Vertical 6,000cycles
MITSUMI
H=1mm Paper Slide Switches
TYPE
Model Name Code
SSP-122BHT
SSP-122RVT
SSP-132MHT
Order Number
R66 6546
R66 6406
R66 6382
No. of
Poles
1
1
1
No. of
Contacts
2
2
3
Travel
(mm)
1.5
1.3
1.5
Knob Direction
Horizontal
Vertical
Horizontal
Boss
With
Without
With
Pcs /Reel
5,000
5,000
5,000
DIMENSIONS
2.9
2.9
3-0.5
(5.8)
7.9
max. 0.1
1
2
3
(0.6)
1.7
0.35
C0.15
3
1.5
Knob position of shipment
7.1
0
0.4
-0.1
0
1.3
-0.05
The float of Earth Terminal
C0.2
0.75
0
+0.1
-0.05
Travele
0
1
-0.1
1.5
Recommend Metal Mask thickness:100µm
3-0.7
2.9
2.9
ø0.9
+0.1
-0
2
0.6
1.5
3
6.9
8.6
Unit : mm
Tolerance : ±0.15mm
3
±0.07
1
2
0.1
0.2
2-ø0.6
2-ø0.8
7.7
(5.8)
4-0.5
Peference land measurements
3
1.3
0.8
3
COM
3
Circuit Diagram
1-Pole. 2-Positions
Peference land measurements
SSP-122BHT
4-R0.1
2-0.6
1.3 TRAVEL
WITH DETENT
4-R0.3
0.8
0.9
6.7
1
1
(0.6)
1.8
1.1
1
2
0.6
7.1
0.6
1.6
+0.1
-0.15
1.08
0
1.7
-0.2
0
0.4
-0.1
1
±0.1
0.8
5.1
±0.2
TRAVEL
TRAVEL
+0.1
-0.05
3-0.5
1.35
(1.54)
3.2
10.7
±0.2
9.5
1.5 a b c 1.5
7
±0.1
0
The float of
Earth Terminal
0.3
0
1.5
-0.2
2-
C
Peference land measurements
Knob position of shipment
0
1.3
-0.05
3
1.7
±0.2
1
2
COM
3
1
0.2
C0.15
1.7
2-ø0.6
0
2-ø0.8
-0.1
3
2
COM
4
Circuit Diagram
1-Pole. 2-Positions
Circuit Diagram
1-pole, 3-positions
SSP-122RVT
Unit : mm
Tolerance : ±0.15mm
SSP-132MHT
Unit : mm
Tolerance : ±0.15mm
4-0.8
2-ø0.8
+0.1
+0.02
9.1
4-1.2
0.
2
1.1
2.5
3
5.1
4-0.5
0.6
1.2
(COM)
4
4-0.5
4-0.5
4-0.9
7.7
7
±0.1
1.8
1
2.65
3
3.2
1
4-0.7
Knob position of shipment
1
0.7
