Data sheet
OMNIMATE Signal - series BL/SL 3.50
BLZF 3.50/02/180LR SN OR BX
Weidmüller Interface GmbH & Co. KG
Klingenbergstraße 16
D-32758 Detmold
Germany
Fon: +49 5231 14-0
Fax: +49 5231 14-292083
www.weidmueller.com
Product image
Female connectors with tension clamp system for
connecting cables in 3.50 pitch. They provide space for
labelling and can be coded.
Similar to illustration
General ordering data
Type
Order No.
Version
GTIN (EAN)
Qty.
Product data
Packaging
BLZF 3.50/02/180LR SN OR BX
1531210000
PCB plug-in connector, female plug, 3.50 mm,
No. of poles: 2, 180°, Tension-clamp connection,
Clamping range, max. : 1.5 mm², Box
4050118336184
100 pc(s).
IEC: 320 V / 14.5 A / 0.2 - 1.5 mm²
UL: 300 V / 10 A / AWG 26 - AWG 14
Box
Creation date May 16, 2019 1:53:52 PM CEST
Catalogue status 01.05.2019 / We reserve the right to make technical changes.
1
Data sheet
OMNIMATE Signal - series BL/SL 3.50
BLZF 3.50/02/180LR SN OR BX
Weidmüller Interface GmbH & Co. KG
Klingenbergstraße 16
D-32758 Detmold
Germany
Fon: +49 5231 14-0
Fax: +49 5231 14-292083
www.weidmueller.com
Technical data
13.4 mm
14.5 mm
29.5 mm
2.041 g
Width (inches)
Height (inches)
Depth (inches)
Dimensions and weights
Width
Height
Depth
Net weight
0.528 inch
0.571 inch
1.161 inch
system parameters
Product family
OMNIMATE Signal - series
BL/SL 3.50
Tension-clamp connection
0.138 inch
2
0.138 inch
1
Safe from finger touch
5.00 mΩ
10 mm
DIN 5264-A
7N
Type of connection
Pitch in mm (P)
Conductor outlet direction
L1 in mm
Number of rows
Rated cross-section
Touch-safe protection acc. to DIN VDE
0470
Can be coded
Screwdriver blade
Plugging cycles
Pulling force/pole, max.
Field connection
3.5 mm
180°
3.5 mm
1
1.5 mm²
IP 20
Yes
0.4 x 2.5
25
5N
Wire connection method
Pitch in inches (P)
No. of poles
L1 in inches
Pin series quantity
Touch-safe protection acc. to DIN VDE
57 106
Volume resistance
Stripping length
Screwdriver blade standard
Plugging force/pole, max.
Material data
Insulating material
Colour chart (similar)
CTI
PBT
RAL 2000
UL 94 flammability rating
Contact material
Layer structure of plug contact
Storage temperature, max.
Operating temperature, min.
Temperature range, installation, min.
≥ 200
V-0
Copper alloy
4-8 µm Sn hot-dip tinned
55 °C
-50 °C
-30 °C
Colour
Insulating material group
Insulation strength
orange
IIIa
GWFI
Contact surface
Storage temperature, min.
Max. relative humidity during storage
Operating temperature, max.
Temperature range, installation, max.
≥ 10
8
Ω
960 °C
tinned
-25 °C
80 %
100 °C
100 °C
Conductors suitable for connection
Clamping range, min.
0.13 mm²
Clamping range, max.
1.5 mm²
Wire connection cross section AWG,
AWG 28
min.
Wire connection cross section AWG,
AWG 16
max.
Solid, min. H05(07) V-U
0.2 mm²
Solid, max. H05(07) V-U
1.5 mm²
Flexible, min. H05(07) V-K
0.2 mm²
Flexible, max. H05(07) V-K
1.5 mm²
w. plastic collar ferrule, DIN 46228 pt 4, 0.2 mm²
min.
w. plastic collar ferrule, DIN 46228 pt 4, 1 mm²
max.
w. wire end ferrule, DIN 46228 pt 1, min0.2 mm²
w. wire end ferrule, DIN 46228 pt 1,
1.5 mm²
max.
Outer diameter of insulation, max.
2.9 mm
Plug gauge in accordance with EN
2.4 mm x 1.5 mm
60999 a x b; ø
Creation date May 16, 2019 1:53:52 PM CEST
Catalogue status 01.05.2019 / We reserve the right to make technical changes.
2
Data sheet
OMNIMATE Signal - series BL/SL 3.50
BLZF 3.50/02/180LR SN OR BX
Weidmüller Interface GmbH & Co. KG
Klingenbergstraße 16
D-32758 Detmold
Germany
Fon: +49 5231 14-0
Fax: +49 5231 14-292083
www.weidmueller.com
Technical data
Cross-section for conductor connection
Clampable conductor
Reference text
Max. clamping range
fine-wired
Type
0.5 mm²
nominal
Stripping length
nominal
AEH
nominal
Stripping length
fine-wired
Type
Cross-section for conductor connection
0.75 mm²
nominal
Stripping length
nominal
AEH
nominal
Stripping length
fine-wired
Type
Cross-section for conductor connection
1 mm²
nominal
Stripping length
nominal
AEH
nominal
Stripping length
fine-wired
Type
Cross-section for conductor connection
1.5 mm²
nominal
Stripping length
nominal
AEH
The outside diameter of the plastic collar should not be larger than the pitch (P).
1.5 mm²
12 mm
10 mm
12 mm
10 mm
12 mm
10 mm
10 mm
Rated data acc. to IEC
tested acc. to standard
IEC 60664-1, IEC 61984
10 A
8A
160 V
2.5 kV
2.5 kV
Rated current, min. no. of poles
(Tu=20°C)
Rated current, min. no. of poles
(Tu=40°C)
Rated voltage for surge voltage class /
pollution degree II/2
Rated voltage for surge voltage class /
pollution degree III/3
Rated impulse voltage for surge voltage
class/ pollution degree III/2
Short-time withstand current resistance
14.5 A
12 A
320 V
160 V
2.5 kV
3 x 1s with 100 A
Rated current, max. no. of poles
(Tu=20°C)
Rated current, max. no. of poles
(Tu=40°C)
Rated voltage for surge voltage class /
pollution degree III/2
Rated impulse voltage for surge voltage
class/ pollution degree II/2
Rated impulse voltage for surge voltage
class/ contamination degree III/3
Rated data acc. to CSA
Rated voltage (Use group B / CSA)
Rated current (Use group B / CSA)
Wire cross-section, AWG, min.
300 V
10 A
AWG 26
Rated voltage (Use group D / CSA)
Rated current (Use group D / CSA)
Wire cross-section, AWG, max.
300 V
10 A
AWG 14
Rated data acc. to UL 1059
Institute (UR)
Certificate No. (UR)
E60693
Rated voltage (Use group D / UL 1059) 300 V
Rated current (Use group D / UL 1059) 10 A
Wire cross-section, AWG, max.
AWG 14
Rated voltage (Use group B / UL 1059)
Rated current (Use group B / UL 1059)
Wire cross-section, AWG, min.
Reference to approval values
300 V
10 A
AWG 26
Specifications are
maximum values, details -
see approval certificate.
Packing
Packaging
VPE width
Box
85 mm
VPE length
VPE height
70 mm
140 mm
Creation date May 16, 2019 1:53:52 PM CEST
Catalogue status 01.05.2019 / We reserve the right to make technical changes.
3
Data sheet
OMNIMATE Signal - series BL/SL 3.50
BLZF 3.50/02/180LR SN OR BX
Weidmüller Interface GmbH & Co. KG
Klingenbergstraße 16
D-32758 Detmold
Germany
Fon: +49 5231 14-0
Fax: +49 5231 14-292083
www.weidmueller.com
Technical data
EC002637
EC002638
27-44-04-02
27-44-03-09
ETIM 5.0
eClass 6.2
eClass 8.1
eClass 9.1
Classifications
ETIM 4.0
ETIM 6.0
eClass 7.1
eClass 9.0
EC002637
27-26-07-04
27-44-04-02
27-44-03-09
Notes
Notes
• Additional colours on request
• Gold-plated contact surfaces on request
• Rated current related to rated cross-section & min. No. of poles.
• Max. outer diameter of the conductor: 2.9 mm
• Wire end ferrule without plastic collar to DIN 46228/1
• Wire end ferrule with plastic collar to DIN 46228/4
• Crimp shape A for wire-end ferrules with crimping tools PZ 1,5 (order no. 9005990000) or PZ 6/5 (order no.
9011460000) for larger wire cross-sections recommended.
• P on drawing = pitch
• Rated data refer only to the component itself. Clearance and creepage distances to other components are to
be designed in accordance with the relevant application standards.
Conformity: The products are developed, manufactured and delivered according international recognized
standards and norms and comply with the assured properties in the data sheet resp. fulfill decorative properties
in accordance with IPC-A-610 "Class 2". Further claims on the products can be evaluated on request.
IPC conformity
Approvals
Approvals
ROHS
Conform
Downloads
Approval/Certificate/Document of
Conformity
Brochure/Catalogue
Engineering Data
Declaration of the Manufacturer
FL DRIVES EN
MB DEVICE MANUF. EN
FL DRIVES DE
FL BUILDING SAFETY EN
FL APPL LED LIGHTING EN
FL INDUSTR.CONTROLS EN
FL MACHINE SAFETY EN
FL HEATING ELECTR EN
FL APPL_INVERTER EN
FL_BASE_STATION_EN
FL ELEVATOR EN
FL POWER SUPPLY EN
FL 72H SAMPLE SER EN
PO OMNIMATE EN
STEP
Creation date May 16, 2019 1:53:52 PM CEST
Catalogue status 01.05.2019 / We reserve the right to make technical changes.
4
Data sheet
OMNIMATE Signal - series BL/SL 3.50
BLZF 3.50/02/180LR SN OR BX
Weidmüller Interface GmbH & Co. KG
Klingenbergstraße 16
D-32758 Detmold
Germany
Fon: +49 5231 14-0
Fax: +49 5231 14-292083
www.weidmueller.com
Drawings
Dimensional drawing
Graph
Graph
Graph
Creation date May 16, 2019 1:53:52 PM CEST
Catalogue status 01.05.2019 / We reserve the right to make technical changes.
