5.0x7.0mm
Surface Mount LVCMOS
Clock Oscillator Series
Description
The Connor Winfield
Xxxx - Series is a 5.0x7.0mm
Surface Mount, LVCMOS,
Fixed Frequency Crystal
Controlled Oscillator (XO)
designed for applications requiring tight
frequency stability, wide temperature
range and low jitter. Operating at 2.5V
or 3.3V supply voltage, the Xxxx -
Series provides an LVCMOS Output
with enable / disable function. The
surface mount package is designed for
high-density mounting and is optimum
for mass production.
Model Specifications
ABSOLUTE MAXIMUM RATINGS
PARAMETER
Storage Temperature
Supply Voltage
(Vcc)
UNITS
MINIMUM
-55
-0.5
MINIMUM
(Fo)
20
20
-20
-25
-50
-100
0
-40
0
-20
(Vcc)
(See Table 9)
(See Table 9)
(Icc)
40 to 79.999 MHz
80 to 89.999 MHz
90 to 124.999 MHz
125 to 164.999 MHz
165 to 225 MHz
-
-
-
-
-
MINIMUM
(High)
(Low)
(Vih)
(Vil)
0.7Vcc
-
-
-
(Icc)
-
-
-
-
-
-
NOMINAL
-
-
-
-
-
15
26
36
46
61
MAXIMUM
-
0.3Vcc
2
200
10
mA
mA
mA
mA
mA
TABLE 3
UNITS
Vdc
Vdc
ms
ns
uA
NOTE
3
3
2.375
3.135
2.500
3.3
2.625
3.465
Vdc
Vdc
-
-
-
-
-
-
-
-
-
-
200
225
20
25
50
100
70
85
85
70
MHz
MHz
ppm
ppm
ppm
ppm
°C
°C
°C
°C
2
2
2
2
1
NOMINAL
-
-
NOMINAL
MAXIMUM
125
5.0
MAXIMUM
UNITS
°C
Vdc
TABLE 2
UNITS
NOTE
CW 0704
X123
133.33M
Features:
Model Xxxx - Series
5.0 x7.0mm Surface Mount Package
2.5V or 3.3V Operation
LVCMOS Output Logic
Frequency Stabilities Available:
X14x / X24x / X34x / X44x: +/-20ppm
X11x / X21x / X31x / X41x: +/-25ppm
X12x / X22x / X32x / X42x: +/-50ppm
X13x / X23x / X33x / X43x: +/-100ppm
Temperature Ranges Available:
X1xx Series: 0 to 70°C
X2xx Series: -40 to 85°C
X3xx Series: 0 to 85°C
X4xx Series: -20 to 70°C
Low Jitter <1pS RMS
Tri-State Enable/Disable
Tape and Reel Packaging
RoHS Compliant / Lead Free
TABLE 1
NOTE
2111 Comprehensive Drive
Aurora, Illinois 60505
Phone: 630- 851- 4722
Fax: 630- 851- 5040
www.conwin.com
US Headquarters:
630-851-4722
European Headquarters:
+353-61-472221
OPERATING SPECIFICATIONS
PARAMETER
Frequency Range
Models Xx4x, Xx1x Series
Models Xx2x, Xx3x Series
Total Frequency Tolerance
Model Xx4x
Model Xx1x
Model Xx2x
Model Xx3x
Model X1xx
Model X2xx
Model X3xx
Model X4xx
Supply Voltage
Model Xxx2
Model Xxx3
Supply Current
(See Table 9)
(See Table 9)
(See Table 9)
(See Table 9)
(See Table 9)
(See Table 9)
(See Table 9)
(See Table 9)
(See Table 9 for full part number)
Operating Temperature Range
INPUT CHARACTERISTICS
PARAMETER
Enable Voltage
Disable Voltage
Enable Time
Disable Time
Output Disable Current (Standby Current)
LVCMOS OUTPUT CHARACTERISTICS
PARAMETER
LOAD
Voltage
Current
(High)
(Low)
(High)
(Low)
Duty Cycle at 50% of Vcc
Rise / Fall Time 10% to 90%
Start-Up Time
Period Jitter
Phase Jitter (BW=12kHz to 20MHz)
Jitter: Peak to Peak (BW=10Hz to 20MHz)
SSB Phase Noise at 10Hz offset
SSB Phase Noise at 100Hz offset
SSB Phase Noise at 1KHz offset
SSB Phase Noise at 10KHz offset
SSB Phase Noise at 100KHz offset
(Voh)
(Vol)
(Ioh)
(Ioh)
MINIMUM
-
Vcc-0.4
-
-8
-
45
-
-
-
-
-
-
-
-
-
-
NOMINAL
-
-
-
MAXIMUM
15
-
0.4
-
8
55
2
2
5
1
25
-
-
-
-
-
UNITS
pF
Vdc
Vdc
mA
mA
%
ns
ms
ps RMS
ps RMS
ps pk tp pk
dBc/Hz
dBc/Hz
dBc/Hz
dBc/Hz
dBc/Hz
TABLE 4
NOTE
-
-
50
1
-
3
0.5
-
-60
-90
-125
-140
-145
Bulletin
Page
Revision
Date
Sm118
1 of 2
09
04 Apr 2009
Specifications subject to change without notice. All dimensions in inches. © Copyright 2008 The Connor-Winfield Corporation
2111 Comprehensive Drive
Aurora, Illinois 60505
Phone: 630-851-4722
Fax: 630-851-5040
www.conwin.com
Notes
1) Maximum output frequency for the +/-20ppm and the +/-25ppm models is 200 MHz.
2) Inclusive of calibration @ 25°C, frequency vs. temperature stability, supply voltage
change, load change, shock and vibration, 10 years aging.
3) When the oscillator is disabled, the outputs are at High Impedance. Output is enabled
with no connection on pad 1.
Package Outline
.197
(5.00mm)
.060
(1.50mm)
Maximum
Ordering Information
X
Type:
Clock Series
5x7mm
1
Temperature Range:
1 = 0 to 70° C
2 = -40 to 85° C
3 = 0 to 85° C
4 = -20 to 70° C
2
Frequency Stability:
4 = +/-20 ppm
1 = +/-25 ppm
2 = +/-50 ppm
3 = +/-100 ppm
3
Supply Voltage:
2 = 2.5Vdc.
3 = 3.3Vdc.
-
133.33M
Output Frequency:
Frequency Format
-xxx.xM Min.*
-xxx.xxxxxxM Max.*
*Amount of numbers
after the decimal point.
M = MHz
.275
(7.00mm)
Suggested Pad Layout
Example: X123-133.33M = LVCMOS Clock, 0 to 70°C, ±50ppm, 3.3V @ 133.33 MHz
Package Characteristics
TABLE 5
Package
Moisture Sensitive Level
Termination Finish
Ceramic surface mount package
MSL - 1
0.7um Gold over 2.5um Nickel
Environmental Characteristics
Vibration:
Shock:
Soldering:
Solderability
TABLE 6
Vibration per Mil Std 883E Method 2007.3 Test Condition A
Mechanical Shock per Mil Std 883E Method 2002.4 Test Condition B.
SMD product suitable for Convection Reflow soldering. Peak
temperature 260°C. Maximum time above 220°C, 60 seconds.
Solderability per Mil Std 883E Method 2003
Pad Connections - Enable / Disable Function
Pad
1
2
3
4
TABLE 7
Connection
Enable/Disable
Ground
Output
Vcc
TABLE 8
Enable / Disable
Function (Pad 1)
High or Open
Low
Output
Enable
Disable (High Impedance)
Solder Profile
Temperature
260°C
220°C
180°C
150°C
120°C
CW 0704
X123
133.33M
260°C
Model Matrix
Frequency
Tolerance
±20ppm
X142
X242
X342
X442
X143
X243
X343
X443
TABLE 9
Frequency
Tolerance
±25ppm
X112
X212
X312
X412
X113
X213
X313
X413
Frequency
Tolerance
±50ppm
X122
X222
X322
X422
X123
X223
X323
X423
Frequency
Tolerance
±100ppm
X132
X232
X332
X432
X133
X233
X333
X433
Supply
Voltage
2.5Vdc
2.5Vdc
2.5Vdc
2.5Vdc
3.3Vdc
3.3Vdc
3.3Vdc
3.3Vdc
Temperature
Range
0 to 70°C
-40 to 85°C
0 to 85°C
-20 to 70°C
0 to 70°C
-40 to 85°C
0 to 85°C
-20 to 70°C
0
120 S
Max.
Time
10 S
60 S
Max.
360 Sec. Max.
LVCMOS Output Waveform
Tape and Reel Specifications
90%
50%
10%
1
