Maximum Junction Temperature (Plastic Package) . . . . . . . .150
o
C
Maximum Storage Temperature Range . . . . . . . . . . -65
o
C to 150
o
C
Maximum Lead Temperature (Soldering 10s) . . . . . . . . . . . . .300
o
C
(SOIC - Lead Tips Only)
*Pb-free PDIPs can be used for through hole wave solder process-
ing only. They are not intended for use in Reflow solder processing
applications.
CAUTION: Stresses above those listed in “Absolute Maximum Ratings” may cause permanent damage to the device. This is a stress only rating and operation of the
device at these or any other conditions above those indicated in the operational sections of this specification is not implied.
NOTES:
1. Short circuit may be applied to ground or to either supply.
2.
JA
is measured with the component mounted on an evaluation PC board in free air.
Electrical Specifications
PARAMETER
Input Offset Voltage
Input Offset Voltage
Temperature Drift
Input Offset Current
Input Current
Large-Signal Voltage Gain
T
A
= 25
o
C, V+ = 15V, V- = 0V, Unless Otherwise Specified
TEST
CONDITIONS
V
S
=
7.5V
CA3130
MIN
-
-
V
S
=
7.5V
V
S
=
7.5V
V
O
= 10V
P-P
R
L
= 2k
-
-
50
94
70
0
V
S
=
7.5V
R
L
= 2k
R
L
= 2k
R
L
=
R
L
=
-
12
-
14.99
-
12
12
-
-
TYP
8
10
0.5
5
320
110
90
-0.5 to 12
32
13.3
0.002
15
0
22
20
10
2
MAX
15
-
30
50
-
-
-
10
320
-
0.01
-
0.01
45
45
15
3
MIN
-
-
-
-
50
94
80
0
-
12
-
14.99
-
12
12
-
-
CA3130A
TYP
2
10
0.5
5
320
110
90
-0.5 to 12
32
13.3
0.002
15
0
22
20
10
2
MAX
5
-
20
30
-
-
-
10
150
-
0.01
-
0.01
45
45
15
3
UNITS
mV
V/
o
C
pA
pA
kV/V
dB
dB
V
V/V
V
V
V
V
mA
mA
mA
mA
SYMBOL
|V
IO
|
V
IO
/T
|I
IO
|
I
I
A
OL
Common-Mode
Rejection Ratio
Common-Mode Input
Voltage Range
Power-Supply
Rejection Ratio
Maximum Output Voltage
CMRR
V
ICR
V
IO
/V
S
V
OM
+
V
OM
-
V
OM
+
V
OM
-
Maximum Output Current
I
OM
+ (Source) at V
O
= 0V
I
OM
- (Sink) at V
O
= 15V
Supply Current
I+
I+
V
O
= 7.5V,
R
L
=
V
O
= 0V,
R
L
=
FN817 Rev.6.00
Aug 1, 2005
Page 2 of 17
CA3130, CA3130A
Electrical Specifications
Typical Values Intended Only for Design Guidance, V
SUPPLY
= ±7.5V, T
A
= 25
o
C
Unless Otherwise Specified
SYMBOL
TEST CONDITIONS
10k Across Terminals 4 and 5 or
4 and 1
R
I
C
I
e
N
f = 1MHz
BW = 0.2MHz, R
S
= 1M
(Note 3)
C
C
= 0
C
C
= 47pF
CA3130,
CA3130A
22
1.5
4.3
23
15
4
UNITS
mV
T
pF
V
MHz
MHz
PARAMETER
Input Offset Voltage Adjustment Range
Input Resistance
Input Capacitance
Equivalent Input Noise Voltage
Open Loop Unity Gain Crossover Frequency
(For Unity Gain Stability
47pF
Required.)
Slew Rate:
Open Loop
Closed Loop
Transient Response:
Rise Time
Overshoot
Settling Time (To <0.1%, V
IN
= 4V
P-P
)
NOTE:
f
T
SR
C
C
= 0
C
C
= 56pF
C
C
= 56pF,
C
L
= 25pF,
R
L
= 2k
(Voltage Follower)
30
10
V/s
V/s
t
r
OS
t
S
0.09
10
1.2
s
%
s
3. Although a 1M source is used for this test, the equivalent input noise remains constant for values of R
S
up to 10M
Electrical Specifications
PARAMETER
Input Offset Voltage
Input Offset Current
Input Current
Common-Mode Rejection Ratio
Large-Signal Voltage Gain
Typical Values Intended Only for Design Guidance, V+ = 5V, V- = 0V, T
A
= 25
o
C
Unless Otherwise Specified (Note 4)
SYMBOL
V
IO
I
IO
I
I
CMRR
A
OL
V
O
= 4V
P-P
, R
L
= 5k
TEST CONDITIONS
CA3130
8
0.1
2
80
100
100
CA3130A
2
0.1
2
90
100
100
0 to 2.8
300
500
200
UNITS
mV
pA
pA
dB
kV/V
dB
V
A
A
V/V
Common-Mode Input Voltage Range
Supply Current
V
ICR
I+
V
O
= 5V, R
L
=
V
O
= 2.5V, R
L
=
0 to 2.8
300
500
200
Power Supply Rejection Ratio
NOTE:
V
IO
/V+
4. Operation at 5V is not recommended for temperatures below 25
o
C.
FN817 Rev.6.00
Aug 1, 2005
Page 3 of 17
CA3130, CA3130A
Schematic Diagram
BIAS CIRCUIT
Q
1
D
1
Z
1
8.3V
R
1
40k R
2
5k
INPUT STAGE
NON-INV.
INPUT
+
INV.-INPUT
2
3
D
5
D
6
(NOTE 5) D
7
D
8
OUTPUT
STAGE
Q
6
Q
7
SECOND
STAGE
D
2
D
3
D
4
Q
4
Q
5
CURRENT SOURCE FOR
Q
6
AND Q
7
Q
2
“CURRENT SOURCE
LOAD” FOR Q
11
Q
3
7
V+
Q
8
OUTPUT
6
-
R
3
1k
Q
9
Q
10
R
4
1k
Q
11
R
5
1k
R
6
1k
Q
12
5
OFFSET NULL
1
COMPENSATION
8
STROBING
4
V-
NOTE:
5. Diodes D
5
through D
8
provide gate-oxide protection for MOSFET input stage.
Application Information
Circuit Description
Figure 1 is a block diagram of the CA3130 Series CMOS
Operational Amplifiers. The input terminals may be operated
down to 0.5V below the negative supply rail, and the output
can be swung very close to either supply rail in many
applications. Consequently, the CA3130 Series circuits are
ideal for single-supply operation. Three Class A amplifier
stages, having the individual gain capability and current
consumption shown in Figure 1, provide the total gain of the
CA3130. A biasing circuit provides two potentials for common
use in the first and second stages.
Terminal 8 can be used both for phase compensation and to
strobe the output stage into quiescence. When Terminal 8 is
tied to the negative supply rail (Terminal 4) by mechanical or
electrical means, the output potential at Terminal 6 essentially
rises to the positive supply-rail potential at Terminal 7. This
condition of essentially zero current drain in the output stage
under the strobed “OFF” condition can only be achieved when
the ohmic load resistance presented to the amplifier is very
high (e.g.,when the amplifier output is used to drive CMOS
digital circuits in Comparator applications).
Input Stage
The circuit of the CA3130 is shown in the schematic diagram. It
consists of a differential-input stage using PMOS field-effect
transistors (Q
6
, Q
7
) working into a mirror-pair of bipolar
transistors (Q
9
, Q
10
) functioning as load resistors together with
resistors R
3
through R
6
.
The mirror-pair transistors also function as a differential-to-
single-ended converter to provide base drive to the second-
stage bipolar transistor (Q
11
). Offset nulling, when desired, can
be effected by connecting a 100,000 potentiometer across
Terminals 1 and 5 and the potentiometer slider arm to Terminal
4.
FN817 Rev.6.00
Aug 1, 2005
Page 4 of 17
CA3130, CA3130A
V+
7
200A
1.35mA
200A
BIAS CKT.
8mA
(NOTE 5)
0mA
(NOTE 7)
CA3130
in Q
2
and Q
3
as constant current sources for both the first and
second amplifier stages, respectively.
At total supply voltages somewhat less than 8.3V, zener diode
Z
1
becomes nonconductive and the potential, developed
across series-connected R
1
, D
1
-D
4
, and Q
1
, varies directly
with variations in supply voltage. Consequently, the gate bias
for Q
4
, Q
5
and Q
2
, Q
3
varies in accordance with supply-
voltage variations. This variation results in deterioration of the
power-supply-rejection ratio (PSRR) at total supply voltages
below 8.3V. Operation at total supply voltages below about
4.5V results in seriously degraded performance.
+
3
INPUT
2
A
V
5X
A
V
6000X
A
V
30X
OUTPUT
6
V-
4
5
1
C
C
COMPENSATION
(WHEN REQUIRED)
8
STROBE
-
Output Stage
The output stage consists of a drain-loaded inverting amplifier
using CMOS transistors operating in the Class A mode. When
operating into very high resistance loads, the output can be
swung within millivolts of either supply rail. Because the output
stage is a drain-loaded amplifier, its gain is dependent upon
the load impedance. The transfer characteristics of the output
stage for a load returned to the negative supply rail are shown
in Figure 2. Typical op amp loads are readily driven by the
output stage. Because large-signal excursions are non-linear,
requiring feedback for good waveform reproduction, transient
delays may be encountered. As a voltage follower, the
amplifier can achieve 0.01% accuracy levels, including the
negative supply rail.
NOTE:
8. For general information on the characteristics of CMOS transistor-
pairs in linear-circuit applications, see File Number 619, data sheet
on CA3600E “CMOS Transistor Array”.
OUTPUT VOLTAGE (TERMINALS 4 AND 8) (V)
17.5
15
12.5
1k
10
7.5
5
2.5
0
0
2.5
5
7.5
10
12.5
15
17.5
20
22.5
GATE VOLTAGE (TERMINALS 4 AND 8) (V)
500
OFFSET
NULL
NOTES:
6. Total supply voltage (for indicated voltage gains) = 15V with input
terminals biased so that Terminal 6 potential is +7.5V above
Terminal 4.
7. Total supply voltage (for indicated voltage gains) = 15V with
output terminal driven to either supply rail.
FIGURE 1. BLOCK DIAGRAM OF THE CA3130 SERIES
Cascade-connected PMOS transistors Q2, Q4 are the constant-
current source for the input stage. The biasing circuit for the
constant-current source is subsequently described.
The small diodes D
5
through D
8
provide gate-oxide protection
against high-voltage transients, including static electricity during
handling for Q
6
and Q
7
.
Second-Stage
Most of the voltage gain in the CA3130 is provided by the
second amplifier stage, consisting of bipolar transistor Q
11
and
its cascade-connected load resistance provided by PMOS
transistors Q
3
and Q
5
. The source of bias potentials for these
PMOS transistors is subsequently described. Miller Effect
compensation (roll-off) is accomplished by simply connecting a
small capacitor between Terminals 1 and 8. A 47pF capacitor
provides sufficient compensation for stable unity-gain
operation in most applications.
SUPPLY VOLTAGE: V+ = 15, V- = 0V
T
A
= 25
o
C
LOAD RESISTANCE = 5k
2k
Bias-Source Circuit
At total supply voltages, somewhat above 8.3V, resistor R
2
and
zener diode Z
1
serve to establish a voltage of 8.3V across the
series-connected circuit, consisting of resistor R
1
, diodes D
1
through D
4
, and PMOS transistor Q
1
. A tap at the junction of
resistor R
1
and diode D
4
provides a gate-bias potential of about
4.5V for PMOS transistors Q
4
and Q
5
with respect to Terminal 7.
A potential of about 2.2V is developed across diode-connected
I need a differential 8-to-1 switch. Currently, only CD4052 has a differential 4-to-1 switch. I can use two output terminals in parallel and then control the En terminal to select the chip. I have a C...
I checked it carefully... (The author has a serious mental illness and always identifies the cause of the problem and determines the responsibility for the accident as soon as a problem occurs...) The...
Chapter 1PCB Layout In PCB design, wiring is an important step to complete product design. It can be said that the previous preparations are all done for it. In the entire PCB , the design process of ...
[backcolor=rgb(238, 238, 238)][size=12px]As the title says, 5509 development board + YXxds510 emulator, customized to be more than 80% new, 300 yuan for packaged, excluding postage[/size][/backcolor]Q...
Why can't I find the txt file of msp430 in the folder after IAR generates it? It seems that it is not generated at all. I wonder if there is something wrong with the settings?...
I need to develop a program for DirectShow video capture. Why do I keep getting the following error message: Error Creating Device Enumerator? The hardware device has been installed. Please give me so...
Today, with the increasing integration of functions, mobile phones can also be used as portable media players (PMP), digital cameras, handheld computers (PDAs), and even global positioning systems ...[Details]
introduction
Throughout the history of automotive lighting, power has always played an important role. Initially, cars only needed headlights to see the road in the dark. Later, other light so...[Details]
System design is a complex process. It is not enough to just use ICs. There are many details to consider. This article uses a high-fidelity music playback system as an example to introduce how to s...[Details]
This paper establishes a fuel cell engine test platform based on the NI integrated hardware and software environment. This platform can realize the test and control of fuel cell engines and their a...[Details]
I've been studying dot matrix recently. It looks simple, but it takes a while to master it completely! The 8*8 dot matrix hardware circuit I'm making now is like this. The row is driven by 74HC138 + t...[Details]
12v Lead Acid batteries used in trucks, cars, RVs and uninterruptible power supplies are usually rated at 12V. This circuit monitors the battery, the charge and discharge curves, gives the cu...[Details]
introduction
At present, measuring instruments are developing towards networking, and each individual embedded instrument will become a node on the Internet. This system realizes the network...[Details]
In the "digital pressure measurement" experimental device of applied physics, the subject technical knowledge of analog circuits, digital circuits, sensors and single-chip microcomputers is used. In o...[Details]
introduction
Steam turbines are driven by high-temperature and high-pressure steam generated by boilers to run at high speed. They are key power equipment in thermal power plants. The emergenc...[Details]
As the global LED market demand continues to increase, my country's LED industry will face huge opportunities in the future. However, the core LED technology and patents are basically monopolized b...[Details]
People who often surf the Internet until late at night, their families always complain that turning on the big lights in the living room affects their rest, but some people don't have keyboard ligh...[Details]
1 Introduction
CAN (Controller Area Network) bus is a kind of field bus. It is used in many industrial sectors due to its outstanding advantages such as high performance, high reliability, high...[Details]
For a long time, my country has implemented "community-style collective heating" for hot water heating, and settled accounts based on the heating area, regardless of whether the user uses heat. Thi...[Details]
Single-chip microcomputer is the abbreviation of single-chip microcomputer. It is made by integrating CPU, ROM, RAM, TIMER/COUNTER and input/output interface (I/O) on a large-scale integrated circu...[Details]
With the rapid development of the IT industry, the demand for small DC cooling fans with PWM control (hereinafter referred to as fans) used in electronic products is increasing. This type of DC fan...[Details]
Analog electronics
京公网安备 11010802033920号
EEWORLD
