SPECIFICATION CONTROL DRAWING
Product Rev.
Product
Name
S02-01-W2-24-00-100
S02-02-W2-24-00-100
S02-03-W2-24-00-100
S02-04-W2-24-00-100
S02-05-W2-24-00-100
N/C
N/C
N/C
N/C
N/C
Ident.
Code
S0201R
S0202R
S0203R
S0204R
S0205R
Product Dimensions
øB
øC
L±1.75
min
min
(L±0.070)
16.50
1.90
2.65
(0.650)
(0.075)
(0.105)
16.50
2.65
3.68
(0.650)
(0.105)
(0.145)
16.50
4.30
5.08
(0.650)
(0.170)
(0.200)
19.10
(0.750)
19.10
(0.750)
5.95
(0.235)
7.00
(0.275)
6.45
(0.255)
7.60
(0.300)
øD
max
1.90
(0.075)
2.65
(0.105)
4.30
(0.170)
5.95
(0.235)
7.00
(0.275)
Cable Dimensions
øE
øF
max
min
2.65
0.90
(0.105)
(0.035)
3.68
1.40
(0.145)
(0.055)
5.08
2.15
(0.200)
(0.085)
6.45
(0.255)
7.60
(0.300)
3.30
(0.130)
4.30
(0.170)
øG
min
0.50
(0.020)
0.75
(0.030)
1.25
(0.050)
1.80
(0.070)
2.50
(0.100)
MATERIALS
1. INSULATION SLEEVE: Heat-shrinkable, transparent blue, radiation cross-linked polyvinylidene fluoride.
2. SOLDER PREFORM WITH FLUX AND THERMAL INDICATOR:
SOLDER: TYPE Sn63 per ANSI-J-STD-006.
FLUX:
TYPE ROL1 per ANSI-J-STD-004.
THERMAL INDICATOR: Color change: violet to colorless.
3. MELTABLE RING: Environment resistant thermoplastic. Color: blue.
4. GROUND LEAD: Un-insulated Stranded Silver-plated Copper in accordance with Boeing 5M2409 Specification, AWG 24.
APPLICATION
1. These parts will provide a shield termination assembly when installed in accordance to Raychem RCPS-100-70 on cables rated
for at least 125°C, meeting the dimensional criteria listed, having tin or silver plated shields.
2. Temperature rating: -55°C to +150°C.
3. Parts shall be marked with identification code per table.
For best results, prepare the cable as shown:
“G” is the minimum diameter on which the sleeve will seal.
TITLE:
305 Constitution Drive
Menlo Park, CA 94025, USA
Unless otherwise specified dimensions are in millimeters.
Inches dimensions are in between brackets.
Tyco Electronics reserves the right to
ANGLES: N/A
TOLERANCES:
amend this drawing at any time. Users
0.00 N/A
should evaluate the suitability of the
ROUGHNESS IN
0.0 N/A
product for their application.
MICRON
0 N/A
SOLDERSLEEVE SHIELD TERMINATOR
ENVIRONMENT RESISTANT WITH LEAD
DOCUMENT NO.:
DCR NUMBER:
S02-0X-W2-24-00-100
REPLACES:
D020445
SCALE:
None
SIZE:
A
D020329
SHEET:
1 of 1
PREPARED BY:
DATE:
PROD. REV.
DOC ISSUE:
mforonda
9-Oct-02
SEE TABLE
1
If this document is printed it becomes uncontrolled. Check for the latest revision.
