Specification Control Drawing
55K9081
Issue 11
15th December 2009
Page 1 of 2
Page 2 is internal use only
WIRE, MODIFIED FLUOROPOLYMER INSULATED, 600 VOLT, 180°C, CONTROLLED WEIGHT
The complete requirements for procuring the wire described herein shall consist of this document and
Airbus Industrie Specification ABS0820 Issue 4.
Conductor -
Nickel Plated High Strength
Copper Alloy (size 24),
Nickel Plated Copper
(size 22 to 18)
Part
Description
Conductor
Stranding
No/Dia
(mm)
Min.
55K9081-24-*
55K9081-22-*
55K9081-20-*
55K9081-18-*
19/0.12
19/0.15
19/0.20
19/0.25
0.550
0.700
0.940
1.180
Max.
0.575
0.730
0.975
1.210
114.0
60.0
33.2
21.1
Conductor
Diameter
(mm)
Maximum
Resistance
@ 20°C
(ohms/ km)
Total
Wall
Thickness
Min.
(mm)
0.20
0.20
0.20
0.20
Lower
Spec
Limit
0.97
1.11
1.35
1.60
Target
FINISHED WIRE
Diameter
(mm)
Insulation -
Radiation Crosslinked
Modified ETFE
Weight
(kg/ km)
Upper
Spec
Limit
1.07
1.21
1.45
1.70
Target
Upper
Spec
Limit
3.12
4.29
7.02
10.75
1.02
1.16
1.40
1.65
2.87
3.96
6.53
9.82
COLOUR CODE:
When used as a primary wire:
Size 24, 20 and 18 coloured white
Size 22 coloured light green
Defined by cable SCD
When used as a component:
PERFORMANCE
REQUIREMENTS
To be tested to the issue in effect of WSD 840 and meet the requirements of
ABS0820 Issue 4.
MARKING:
Coloured Black, every 300 ± 50 mm for:
size 20 and 18 horizontally along axis
size 22 and 24 vertically along axis.
Each mark shall be connected by a dashed line, each dash at 40-50mm,
5mm long, 0.5mm minimum width.
- - - BPXX U GBSYY - - - Where the XX is replaced by the wire size and the YY is
replaced by a year code designator in accordance with the table below.
e.g. - - - BP24 U GBS09 - - -
NB. When used as a component,
the mark is defined by the cable SCD.
APPROVAL:
Electronic sign off - no signatures will appear.
