BAS19_

Description
0.2 A, 100 V, SILICON, SIGNAL DIODE
Categorysemiconductor    Discrete semiconductor
File Size285KB,4 Pages
ManufacturerDiodes
Websitehttp://www.diodes.com/
Download Datasheet Parametric Compare View All

BAS19_ Overview

0.2 A, 100 V, SILICON, SIGNAL DIODE

BAS19_ Parametric

Parameter NameAttribute value
Number of terminals3
Number of components1
Processing package descriptionPLASTIC PACKAGE-3
stateTRANSFERRED
packaging shapeRECTANGULAR
Package SizeSMALL OUTLINE
surface mountYes
Terminal formGULL WING
terminal coatingNOT SPECIFIED
Terminal locationDUAL
Packaging MaterialsPLASTIC/EPOXY
structureSINGLE
Diode component materialsSILICON
Maximum power consumption limit0.3500 W
Diode typeSIGNAL DIODE
Maximum reverse recovery time0.0500 us
Maximum repetitive peak reverse voltage100 V
Maximum average forward current0.2000 A
BAS19 / BAS20 / BAS21
SURFACE MOUNT FAST SWITCHING DIODE
Features
Fast Switching Speed
Surface Mount Package Ideally Suited for Automated Insertion
For General Purpose Switching Applications
High Conductance
Totally Lead-Free & Fully RoHS Compliant (Notes 1 & 2)
Halogen and Antimony Free. “Green” Device (Note 3)
Qualified to AEC-Q101 Standards for High Reliability
PPAP Capable (Note 4)
Mechanical Data
Case: SOT23
Case Material: Molded Plastic.
UL Flammability Classification Rating 94V-0
Moisture Sensitivity: Level 1 per J-STD-020
Terminals: Solderable per MIL-STD-202, Method 208
Lead Free Plating (Matte Tin Finish Annealed over Alloy 42
Leadframe).
Polarity: See Diagram
Weight: 0.008 grams (Approximate)
SOT23
Top View
Top View
Internal Schematic
Ordering Information
(Note 5)
Part Number
BAS19-7-F
BAS20-7-F
BAS20-13-F
BAS20Q-13-F
BAS21-7-F
BAS21Q-7-F
BAS21-13-F
BAS21Q-13-F
Notes:
Qualification
Commercial
Commercial
Commercial
Automotive
Commercial
Automotive
Commercial
Automotive
Case
SOT23
SOT23
SOT23
SOT23
SOT23
SOT23
SOT23
SOT23
Packaging
3,000/Tape & Reel
3,000/Tape & Reel
10,000/Tape & Reel
10,000/Tape & Reel
3,000/Tape & Reel
3,000/Tape & Reel
10,000/Tape & Reel
10,000/Tape & Reel
1. No purposely added lead. Fully EU Directive 2002/95/EC (RoHS), 2011/65/EU (RoHS 2) & 2015/863/EU (RoHS 3) compliant.
2. See https://www.diodes.com/quality/lead-free/ for more information about Diodes Incorporated’s definitions of Halogen- and Antimony-free, "Green" and
Lead-free.
3. Halogen- and Antimony-free "Green” products are defined as those which contain <900ppm bromine, <900ppm chlorine
(<1500ppm total Br + Cl) and <1000ppm antimony compounds.
4. Automotive products are AEC-Q101 qualified and are PPAP capable. Automotive, AEC-Q101 and standard products are electrically and thermally the
same, except where specified. For more information, please refer to https://www.diodes.com/quality/.
5. For packaging details, go to our website at http://www.diodes.com/products/packages.html.
Marking Information
KXX
KXX = Product Type Marking Code
BAS19 Marking: KA8, KT3; KT2
BAS20 Marking: KT2, KT3
BAS21 Marking: KT3
YM = Date Code Marking
Y = Year (ex: F = 2018)
M = Month (ex: 9 = September)
Date Code Key
Year
Code
Month
Code
2000
L
Jan
1
2001
M
Feb
2
2002
N
Mar
3
…..
…..
Apr
4
YM
2016
D
2017
E
Jun
6
2018
F
2019
G
Jul
7
2020
H
Aug
8
2021
I
Sep
9
2022
J
Oct
O
2023
K
Nov
N
2024
L
Dec
D
June 2018
May
5
BAS19 / BAS20 / BAS21
Document number: DS12004 Rev. 22 - 2
1 of 4
www.diodes.com
© Diodes Incorporated

BAS19_ Related Products

BAS19_ BAS19 BAS20 BAS21
Description 0.2 A, 100 V, SILICON, SIGNAL DIODE 0.2 A, 100 V, SILICON, SIGNAL DIODE 0.2 A, 150 V, SILICON, SIGNAL DIODE SIGNAL DIODE
state TRANSFERRED TRANSFERRED CONSULT MFR ACTIVE
Diode type SIGNAL DIODE SIGNAL DIODE Signal diode Signal diode
Number of terminals 3 3 3 -
Number of components 1 1 1 -
Processing package description PLASTIC PACKAGE-3 PLASTIC PACKAGE-3 PLASTIC PACKAGE-3 -
packaging shape RECTANGULAR RECTANGULAR Rectangle -
Package Size SMALL OUTLINE SMALL OUTLINE SMALL OUTLINE -
surface mount Yes Yes Yes -
Terminal form GULL WING GULL WING GULL WING -
terminal coating NOT SPECIFIED NOT SPECIFIED NOT SPECIFIED -
Terminal location DUAL DUAL pair -
Packaging Materials PLASTIC/EPOXY PLASTIC/EPOXY Plastic/Epoxy -
structure SINGLE SINGLE single -
Diode component materials SILICON SILICON silicon -
Maximum power consumption limit 0.3500 W 0.3500 W 0.3500 W -
Maximum reverse recovery time 0.0500 us 0.0500 us 0.0500 us -
Maximum repetitive peak reverse voltage 100 V 100 V 150 V -
Maximum average forward current 0.2000 A 0.2000 A 0.2000 A -
