05002
DA05L
thru
DA24CM
STANDARD CAPACITANCE TVS ARRAY
APPLICATIONS
✔
Low Frequency I/O Ports
✔
RS-232 & RS-423 Data Lines
✔
Power Bus Lines
✔
Monitoring & Industrial Signal and Data Ports
✔
Microprocessor Based Equipment
IEC COMPATIBILITY
(EN61000-4)
✔
61000-4-2 (ESD): Air - 15kV, Contact - 8kV
✔
61000-4-4 (EFT): 40A - 5/50ns
✔
61000-4-5 (Surge): 24A, 8/20µs Level 2 (Line-Ground) & Level 3 (Line-Line)
8 PIN DIP
FEATURES
✔
800 Watts Peak Pulse Power per Line (tp=8/20µs)
✔
Unidirectional & Bidirectional Configuration
✔
ESD Protection > 40 kilovolts
✔
Available in 5V, 12V, 15V & 24V
✔
Standard Dual-In-Line Package
✔
Protects 4 to 6 Lines
✔
RoHS Compliant
MECHANICAL CHARACTERISTICS
✔
✔
✔
✔
Molded 8 Pin Dual-In-Line (DIP) Package
Weight 0.55 grams (Approximate)
Available in Lead-Free Pure-Tin Plating(Annealed)
Solder Reflow Temperature:
Pure-Tin - Sn, 100: 260-270°C
✔
Consult Factory for Leaded Device Availability
✔
Flammability Rating UL 94V-0
✔
Packaging: 50 Pieces Per Tube
✔
Marking: Logo, Part Number, Date Code & Pin One Defined By Dot on Top of Package
PIN CONFIGURATIONS
UNIDIRECTIONAL
DAxL Series
8
7
6
5
8
BIDIRECTIONAL
DAxxCL Series
7
6
5
1
2
3
4
1
2
3
4
DAxxM Series
8
7
6
5
8
DAxxCM Series
7
6
5
1
2
3
4
1
2
3
4
05002.R9 2/07
1
www.protekdevices.com
DA05L
thru
DA24CM
DEVICE CHARACTERISTICS
MAXIMUM RATINGS
@ 25°C Unless Otherwise Specified
PARAMETER
Peak Pulse Power (t
p
= 8/20µs) - See Figure 1
Operating Temperature
Storage Temperature
Forward Surge Rating
SYMBOL
P
PP
T
L
T
STG
I
F
VALUE
800
-55 to 150
-55 to 150
10
UNITS
Watts
°C
°C
Amps
ELECTRICAL CHARACTERISTICS PER LINE
PART
NUMBER
(See Note 1)
RATED
STAND-OFF
VOLTAGE
MINIMUM
BREAKDOWN
VOLTAGE
MAXIMUM
CLAMPING
VOLTAGE
(See Fig. 2)
@ I
P
= 10A
V
C
VOLTS
12.5
26.0
33.0
52.1
12.5
26.0
33.0
52.1
12.5
26.0
33.0
52.1
12.5
26.0
33.0
52.1
@ 25°C Unless Otherwise Specified
MAXIMUM
CLAMPING
VOLTAGE
(See Fig. 2)
MAXIMUM
LEAKAGE
CURRENT
MAXIMUM
CAPACITANCE
V
WM
VOLTS
DA05L
DA12L
DA15L
DA24L
DA05M
DA12M
DA15M
DA24M
DA05CL
DA12CL
DA15CL
DA24CL
DA05CM
DA12CM
DA15CM
DA24CM
5.0
12.0
15.0
24.0
5.0
12.0
15.0
24.0
5.0
12.0
15.0
24.0
5.0
12.0
15.0
24.0
@ 1mA
V
(BR)
VOLTS
6.0
13.3
16.7
26.7
6.0
13.3
16.7
26.7
6.0
13.3
16.7
26.7
6.0
13.3
16.7
26.7
@8/20µs
V
C
@ I
PP
24.6V
32.9V
37.7V
53.0V
24.6V
32.9V
37.7V
53.0V
24.6V
32.9V
37.7V
53.0V
24.6V
32.9V
37.7V
53.0V
@
@
@
@
@
@
@
@
@
@
@
@
@
@
@
@
45A
34A
27A
20A
45A
34A
27A
20A
45A
34A
27A
20A
45A
34A
27A
20A
@V
WM
I
D
µA
200
2
2
2
200
2
2
2
200
2
2
2
200
2
2
2
0V @ 1 MHz
C
pF
880
440
400
275
880
440
400
275
500
385
300
200
500
385
300
200
Note 1:
The “C” suffix specifies a bidirectional device, such as DA05CM or DA12CL.
05002.R9 2/07
2
www.protekdevices.com
DA05L
thru
DA24CM
GRAPHS
10,000
P
PP
- Peak Pulse Power - Watts
FIGURE 1
PEAK PULSE POWER VS PULSE TIME
800W 8/20µs Waveform
1,000
100
10
0.1
1
10
100
t
d
- Pulse Duration - µs
1,000
10,000
120
I
PP
- Peak Pulse Current - % of I
PP
FIGURE 2
PULSE WAVE FORM
100
t
f
Peak Value I
PP
TEST
WAVEFORM
PARAMETERS
t
f
= 8µs
t
d
= 20µs
80
% Of Rated Power
FIGURE 3
POWER DERATING CURVE
Peak Pulse Power
8/20µs
100
80
60
40
20
0
0
5
e
-t
60
40
20
Average Power
0
t
d
= t I /2
PP
10
15
t - Time - µs
20
25
30
0
25
50
75
100
125
T
L
- Lead Temperature - °C
150
05002.R9 2/07
3
www.protekdevices.com
DA05L
thru
DA24CM
8 PIN DIP PACKAGE OUTLINE & DIMENSIONS
PACKAGE OUTLINE
8 PIN DIP
A
DIMENSIONS
Orientation Dot
(Pin #1)
B
C
I
4 Places
F
DIM
A
B
C
D
E
F
G
H
I
J
K
L
MILLIMETERS
MIN
MAX
-
6.10
7.37
0.25
0°
0.51
-
3.17
-
0.84 TYP
0.38
2.54 TYP
10.2
6.60
7.87
0.50
10°
-
5.08
INCHES
MIN
MAX
-
0.240
0.290
0.010
0°
0.020
-
0.400
0.260
0.310
0.020
10°
-
0.200
G
D
4 Places
E
H
L
J 4 Places
K
8 Places
-
0.125
-
1.78
-
0.070
0.84 TYP 0.033 TYP 0.033 TYP
0.53
0.015
0.021
2.54 TYP 0.100 TYP 0.100 TYP
NOTES:
1. Dimensions are exclusive of mold flash and metal
burrs.
BULK ORDERING NOMENCLATURE:
1. No Suffix = Product Shipped in Tubes of 50 pcs per Tube.
2. Suffix -LF = Lead-Free, Pure-Tin Plating, i.e.,
DA05L-LF.
Outline & Dimensions: Rev 1 - 11/01, 06004
COPYRIGHT © ProTek Devices 2007
SPECIFICATIONS: ProTek reserves the right to change the electrical and or mechanical characteristics described herein without notice (except JEDEC).
DESIGN CHANGES: ProTek reserves the right to discontinue product lines without notice, and that the final judgement concerning selection and specifications is
the buyer’s and that in furnishing engineering and technical assistance, ProTek assumes no responsibility with respect to the selection or specifications of such
products.
ProTek Devices
2929 South Fair Lane, Tempe, AZ 85282
Tel: 602-431-8101 Fax: 602-431-2288
