2SK1959-AZ

Description
Power Field-Effect Transistor, 2A I(D), 16V, 0.5ohm, 1-Element, N-Channel, Silicon, Metal-oxide Semiconductor FET
CategoryDiscrete semiconductor    The transistor
File Size60KB,6 Pages
ManufacturerNEC Electronics
Download Datasheet Parametric Compare View All

2SK1959-AZ Overview

Power Field-Effect Transistor, 2A I(D), 16V, 0.5ohm, 1-Element, N-Channel, Silicon, Metal-oxide Semiconductor FET

2SK1959-AZ Parametric

Parameter NameAttribute value
MakerNEC Electronics
package instructionSMALL OUTLINE, R-PSSO-F3
Reach Compliance Codeunknown
ECCN codeEAR99
Other featuresGATE PROTECTED
Shell connectionDRAIN
ConfigurationSINGLE WITH BUILT-IN DIODE
Minimum drain-source breakdown voltage16 V
Maximum drain current (ID)2 A
Maximum drain-source on-resistance0.5 Ω
FET technologyMETAL-OXIDE SEMICONDUCTOR
JESD-30 codeR-PSSO-F3
Number of components1
Number of terminals3
Operating modeENHANCEMENT MODE
Package body materialPLASTIC/EPOXY
Package shapeRECTANGULAR
Package formSMALL OUTLINE
Peak Reflow Temperature (Celsius)NOT SPECIFIED
Polarity/channel typeN-CHANNEL
Maximum pulsed drain current (IDM)4 A
Certification statusNot Qualified
surface mountYES
Terminal formFLAT
Terminal locationSINGLE
Maximum time at peak reflow temperatureNOT SPECIFIED
transistor applicationsSWITCHING
Transistor component materialsSILICON
Base Number Matches1
DATA SHEET
MOS FIELD EFFECT TRANSISTOR
2SK1959
N-CHANNEL MOS FET FOR HIGH-SPEED SWITCHING
The 2SK1959 is an N-channel vertical MOS FET. Because
it can be driven by a voltage as low as 1.5 V and it is not
necessary to consider a drive current, this FET is ideal as an
actuator for low-current portable systems such as headphone
stereos and video cameras.
PACKAGE DIMENSIONS (in mm)
4.5 ±0.1
1.6 ±0.2
1.5 ±0.1
• Gate can be driven by 1.5 V
• Low ON resistance
R
DS(on)
= 3.2
MAX.
R
DS(on)
= 0.5
MAX.
@ V
GS
= 1.5 V, I
D
= 50 mA
@ V
GS
= 4.0 V, I
D
= 1.0 A
0.8 MIN.
FEATURES
S
0.42 ±0.06
D
G
0.42 ±0.06
1.5 0.47
±0.06
3.0
0.41
+0.03
–0.05
Marking: NQ
EQUIVALENT CURCUIT
Drain (D)
Gate (G)
Gate
protection
diode
Source (S)
Internal
diode
PIN CONNECTIONS
S: Source
D: Drain
G: Gate
ABSOLUTE MAXIMUM RATINGS (T
A
= 25 ˚C)
PARAMETER
Drain to Source Voltage
Gate to Source Voltage
Drain Current (DC)
Drain Current (Pulse)
Total Power Dissipation
Channel Temperature
Storage Temperature
SYMBOL
V
DSS
V
GSS
I
D(DC)
I
D(pulse)
P
T
T
ch
T
stg
PW
10 ms, duty cycle
50 %
16 cm
2
×
0.7 mm ceramic substrate used
V
GS
= 0
V
DS
= 0
TEST CONDITIONS
RATING
16
±7.0
±2.0
±4.0
2.0
150
–55 to +150
UNIT
V
V
A
A
W
˚C
˚C
Document No. D11222EJ2V0DS00 (2nd edition)
Date Published June 1996 P
Printed in Japan
4.0 ±0.25
2.5 ±0.1
©
1996
