05008
DLZ-5
thru
DLZ-30CA
STANDARD CAPACITANCE TVS ARRAY
APPLICATIONS
✔
✔
✔
✔
Military & Aerospace Data Line Protection
RS-232 & RS-423 Data Lines
Microprocessor Based Equipment
Multiple Data & Power Bus Line Protection
IEC COMPATIBILITY
(EN61000-4)
✔
61000-4-2 (ESD): Air - 15kV, Contact - 8kV
✔
61000-4-4 (EFT): 40A - 5/50ns
✔
61000-4-5 (Surge): 24A, 8/20µs Level 2 (Line-Ground) & Level 3 (Line-Line)
16 PIN CERAMIC
FEATURES
✔
MIL-STD-461 Compatible
✔
Protects I/O Devices
✔
Satisfies Military NEMP Requirements
✔
1300 Watts Peak Pulse Power per Line (tp=8/20µs)
✔
Unidirectional & Bidirectional Configurations
✔
ESD Protection > 40 kilovolts
✔
Internal Common Ground
✔
Available in Multiple Voltage Types: 5.0V to 30.0V
✔
Multiple TVS Array: Protects up to 15 Lines
MECHANICAL CHARACTERISTICS
✔
Ceramic 16 Pin Hermetically Sealed Package
✔
Weight 3.2 grams (Approximate)
✔
Flammability Rating UL 94V-0
✔
Marking: Logo, Part Number, Date Code & Pin One Defined By Flag on Lead
✔
Screening Available Upon Request - The DLZ series can be screened upon request for
military requirements in accordance with MIL-PRF-19500 (applicable test). Standard
screening is available based on the following options:
H1 - 100% screening per test plans 05227 & 05229
H2 - 100% screening per test plans 05228 & 05230
✔
Screening to DESC Drawing #94029 (Bidirectional) & #94030 (Unidirectional) is also
available
PIN CONFIGURATIONS
UNIDIRECTIONAL
BIDIRECTIONAL
16
15
14
13
12
11
10
9
16
15
14
13
12
11
10
9
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
05008.R7 2/07
1
www.protekdevices.com
DLZ-5
thru
DLZ-30CA
DEVICE CHARACTERISTICS
MAXIMUM RATINGS
@ 25°C Unless Otherwise Specified
PARAMETER
Peak Pulse Power (t
p
= 8/20µs) - See Figure 1
Operating Temperature
Storage Temperature
Forward Surge Rating (1/20 seconds) - Unidirectional Only
SYMBOL
P
PP
T
L
T
STG
I
F
VALUE
1300
-55 to 150
-55 to 150
10
UNITS
Watts
°C
°C
Amps
ELECTRICAL CHARACTERISTICS PER LINE
PART
NUMBER
(See Note 1)
RATED
STAND-OFF
VOLTAGE
MINIMUM
BREAKDOWN
VOLTAGE
MAXIMUM
CLAMPING
VOLTAGE
(See Fig. 2)
@ I
P
= 1A
V
C
VOLTS
10.2
9.5
21.1
19.1
30.4
27.5
42.3
38.3
52.8
47.8
13.4
22.8
20.6
34.2
31.0
52.8
47.8
@ 25°C Unless Otherwise Specified
MAXIMUM
LEAKAGE
CURRENT
MAXIMUM
CAPACITANCE
TEMPERATURE
COEFFICIENT
OF V
(BR)
qV
(BR)
mV/°C
MAXIMUM
CLAMPING
VOLTAGE
(See Fig. 2)
V
WM
VOLTS
DLZ-5
DLZ-5A
DLZ-12
DLZ-12A
DLZ-17
DLZ-17A
DLZ-24
DLZ-24A
DLZ-30
DLZ-30A
DLZ-8C
DLZ-13C
DLZ-13CA
DLZ-19C
DLZ-19CA
DLZ-30C
DLZ-30CA
5.0
5.0
12.0
12.0
17.0
17.0
24.0
24.0
30.0
30.0
8.0
13.0
13.0
19.0
19.0
30.0
30.0
@ 1mA
V
(BR)
VOLTS
6.0
6.0
13.3
13.3
19.2
19.2
26.7
26.7
33.3
33.3
8.5
14.4
14.4
21.6
21.6
33.3
33.3
@8/20µs
V
C
@ I
PP
19.2V
18.1V
33.0V
28.0V
40.0V
37.4V
62.4V
50.5V
62.9V
60.0V
29.0V
34.0V
31.0V
47.6V
40.5V
68.7V
62.5V
@
@
@
@
@
@
@
@
@
@
@
@
@
@
@
@
@
66A
70A
41A
48A
33A
35A
21A
26A
21A
24A
45A
39A
43A
28A
33A
19A
21A
@V
WM
I
D
µA
200
200
2
2
2
2
2
2
2
2
10
4
4
4
4
4
4
0V @ 1 MHz
C
pF
880
880
440
440
330
330
275
275
220
220
440
385
385
275
275
165
165
5
5
18
18
20
20
31
31
39
39
9
18
18
24
24
39
39
Note 1:
Part numbers with a “C” suffix are bidirectional devices, i.e., DLZ-8C.
05008.R7 2/07
2
www.protekdevices.com
DLZ-5
thru
DLZ-30CA
16 PIN CERAMIC PACKAGE OUTLINE & DIMENSIONS
PACKAGE OUTLINE
16 PIN CERAMIC DIP
A
C
DIMENSIONS
B
Pin 1
Pin 1 Index
D
DIM
A
B
C
D
E
F
MILLIMETERS
MIN
MAX
22.72
11.43
-
7.36
-
4.19
2.42
0.33
0.88
23.48
12.19
4.87
7.84
-
-
2.66
0.57
1.12
INCHES
MIN
MAX
0.895
0.450
-
0.310
0.025 REF
0.165
0.095
0.023
0.035
0.925
0.480
0.192
0.290
- REF
-
0.105
0.013
0.045
E
G
H
I
F
NOTES:
G
H
I
1. Dimensions are exclusive of metal burrs and solder
protusions.
2. Package sealed with ceramic or metal lid.
Outline & Dimensions: Rev 0 - 3/02, 06029
