331237: DescriptionCONNECTOR, PANEL MOUNT, CABLE TERMINATED, FEMALE, TNC CONNECTOR, CRIMP, JACK; CategoryThe connector The connector; File Size105KB，1 Pages; ManufacturerTE Connectivity; Websitehttp://www.te.com

Download Datasheet Parametric View All

331237 Overview

CONNECTOR, PANEL MOUNT, CABLE TERMINATED, FEMALE, TNC CONNECTOR, CRIMP, JACK

331237 Parametric

Parameter Name	Attribute value
Maker	TE Connectivity
Reach Compliance Code	unknown
Other features	APPLICABLE CABLES: RG 174/U, RG 188/U
Body/casing type	JACK
Characteristic impedance	50 Ω
Connector type	RF TNC CONNECTOR
Contact to complete cooperation	GOLD
Contact completed and terminated	GOLD
Contact point gender	FEMALE
Coupling type	THREADED
DIN compliance	NO
Filter function	NO
IEC compliance	NO
insulator material	POLYTETRAFLUORO ETHYLENE
JESD-609 code	e4
MIL compliance	NO
Manufacturer's serial number	331237
Installation method	STRAIGHT
Installation type	CABLE
Maximum operating frequency	4 GHz
Options	GENERAL PURPOSE
Panel mounting	YES
Termination type	CRIMP
voltage standing wave ratio	1.35
Base Number Matches	1

Preview

Download Datasheet

View All

C orporate Hom e

Electronic Components

Se gm e nts

W ho W e Are

My Account

Searc h

Products

Documentation

Resources

My Account

Customer Support

Home

Products

By Type

RF & C oax

Product Feature Selector

> Product Details

331237 Product Details

Live Product Chat

TNC RF Connectors

Not re vie we d for R oHS C om plia nce

No Im a ge Ava ila ble

Quick Links

C heck Pricing & Availability

Search for Tooling

Product Feature Selector

C ontact Us About This Product

331237

T E I nternal N umber: 3 3 1 2 3 7

Product Highlights:

C onnector

Jack

Terminate To C oaxial C able

C rimp Type = Single

C oaxial C able Termination Type = C rimp

View all Features

A dd to M y P art L is t

Reques t Sample

Find Similar P roduc ts

Obsolete

Search for Replacement Parts

Buy P roduc t

Documentation & Additional Information

Product Drawings:

None Available

Catalog Pages/Data Sheets:

RF C OAX PRODUC TS

(PDF, English)

Product Specifications:

C onnector, C oaxial, TNC Series, Dual C rimp Type

(PDF, English)

Application Specifications:

None Available

Instruction Sheets:

TNC Series Single C rimp 50-OHM Jacks

(PDF, English)

CAD Files:

None Available

List all Documents

Product Features

(Please use the Product Drawing for all design activity)

Product Type Features:

Product Type

= C onnector

Gender

= Jack

C rimp Type = Single

Body Style

= Straight

Weatherproof = No

Solder Terminal

= Without

Panel Thickness (mm [in]) = 3.18 [0.125]

Grade = Military

Dielectric Material = TEFLON

Mechanical Attachment:

Panel Attachment

= With

Panel Attachment Method = Bulkhead

Electrical Characteristics:

C onnector Impedance (?)

= 50

Termination Related Features:

C oaxial C able Termination Type

= C rimp

Body Related Features:

Body Plating

= Silver

Contact Related Features:

C enter C ontact Plating = Gold

Configuration Related Features:

C oaxial C able Type (RG/U or Mfg.)

= 174, 188

Industry Standards:

Government/Industry Qualification = No

RoHS/ELV C ompliance

= Not reviewed for ELV/RoHS compliance

Lead Free Solder Processes

= Not reviewed for lead free solder

process

Conditions for Usage:

Terminate To

= C oaxial C able

Other:

Brand = AMP

Additional Information:

Product Line Information
