PR6001 - PR6005
6.0A FAST RECOVERY RECTIFIER
Features
·
·
·
·
·
·
·
·
·
·
·
·
·
·
Diffused Junction
Fast Switching for High Efficiency
High Current Capability and Low Forward Voltage Drop
Surge Overload Rating to 300A Peak
Low Reverse Leakage Current
Lead Free Finish, RoHS Compliant (Note 4)
A
B
A
Mechanical Data
Case: R-6
Case Material: Molded Plastic
.
UL Flammability
Classification Rating 94V-0
Moisture Sensitivity: Level 1 per J-STD-020C
Terminals: Finish - Bright Tin. Plated Leads Solderable per
MIL-STD-202, Method 208
Polarity: Cathode Band
Ordering Information: See Last Page
Marking: Type Number
Weight: 2.1 grams (approximate)
R-6
Dim
A
B
C
D
Min
25.40
8.60
1.20
8.60
C
D
Max
¾
9.10
1.30
9.10
All Dimensions in mm
Maximum Ratings and Electrical Characteristics
Single phase, half wave, 60Hz, resistive or inductive load.
For capacitive load, derate current by 20%.
Characteristic
Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage
RMS Reverse Voltage
Average Rectified Output Current
(Note 1)
@ T
A
= 60°C
Non-Repetitive Peak Forward Surge Current
8.3ms Single half sine-wave Superimposed on Rated Load
(JEDEC Method)
Forward Voltage
Peak Reverse Current
at Rated DC Blocking Voltage
Reverse Recovery Time (Note 3)
Typical Junction Capacitance (Note 2)
Typical Thermal Resistance Junction to Ambient
Operating and Storage Temperature Range
Notes:
1.
2.
3.
4.
@ T
A
= 25°C unless otherwise specified
Symbol
V
RRM
V
RWM
V
R
V
R(RMS)
I
O
I
FSM
V
FM
I
RM
t
rr
C
j
R
qJA
T
j,
T
STG
PR
6001
50
35
PR
6002
100
70
PR
6003
200
140
6.0
300
1.2
10
150
150
140
32
-65 to +150
PR
6004
400
280
PR
6005
600
420
Unit
V
V
A
A
V
mA
@ I
F
= 6.0A
@ T
A
= 25°C
@ T
A
= 125°C
250
70
ns
pF
K/W
°C
Valid provided that leads are maintained at ambient temperature at a distance of 9.5mm from the case.
Measured at 1.0MHz and applied reverse voltage of 4.0 V DC.
Measured with I
F
= 0.5A, I
R
= 1.0A, I
rr
= 0.25 A. See figure 5.
RoHS revision 13.2.2003. Glass and High Temperature Solder Exemptions Applied, see
EU Directive Annex Notes 5 and 7.
DS26007 Rev. 3 - 2
1 of 3
www.diodes.com
PR6001 - PR6005
ã
Diodes Incorporated
I
Fsm
, PEAK FORWARD SURGE CURRENT (A)
8
600
8.3ms Single Half Sine-Wave
JEDEC Method
I
(AV)
, AVERAGE FORWARD CURRENT
500
6
400
4
300
200
2
100
0
1
10
100
NUMBER OF CYCLES AT 60Hz
Fig. 2 Max Non-Repetitive Peak Surge Current
1000
0
0
25
50
75
100
125
150
175
T
A
, AMBIENT TEMPERATURE (
°
C)
Fig. 1, Typical Forward Current Derating Curve
I
F
, INSTANTANEOUS FORWARD CURRENT (A)
1000
C
j
, CAPACITANCE (pF)
100
100
PR6001 - PR6004
10
PR6005
10
1
0.1
0.6
0.8
1.0
1.2
1.4
1.6
1.8
2.0
1.0
1.0
10
T
j
= 25
°
C
f = 1.0MHz
100
V
F
, INSTANTANEOUS FORWARD VOLTAGE (V)
Fig. 3, Typical Instantaneous Forward Characteristics
V
R
, REVERSE VOLTAGE (V)
Fig. 4 Typical Junction Capacitance
t
rr
+0.5A
Device
Under
Test
(-)
Pulse
Generator
(Note 2)
0A
(+)
50V DC
Approx
-0.25A
(-)
Oscilloscope
(Note 1)
(+)
-1.0A
Set time base for 50/100 ns/cm
Fig. 5 Reverse Recovery Time Characteristic and Test Circuit
