HI-547 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > semiconductor> Analog mixed-signal IC> HI-547

HI-547: Description4-CHANNEL, DIFFERENTIAL MULTIPLEXER, PDSO16; Categorysemiconductor Analog mixed-signal IC; File Size734KB，25 Pages; ManufacturerIntersil ( Renesas ); Websitehttp://www.intersil.com/cda/home/

Download Datasheet Parametric View All

HI-547 Overview

4-CHANNEL, DIFFERENTIAL MULTIPLEXER, PDSO16

HI-547 Parametric

Parameter Name	Attribute value
Number of functions	1
Number of terminals	16
Maximum operating temperature	85 Cel
Minimum operating temperature	-40 Cel
Rated supply voltage	15 V
Processing package description	ROHS COMPLIANT, SOIC-16
Lead-free	Yes
EU RoHS regulations	Yes
state	ACTIVE
Craftsmanship	CMOS
packaging shape	Rectangle
Package Size	SMALL OUTLINE
surface mount	Yes
Terminal form	GULL WING
Terminal spacing	1.27 mm
terminal coating	MATTE Tin
Terminal location	pair
Packaging Materials	Plastic/Epoxy
Temperature level	INDUSTRIAL
Number of inputs	4
Maximum on-time	1000 ns
Maximum off time	1000 ns
Analog IC other types	Differential Multiplexer
Isolation Rating in Off State	68 dB
Maximum limit analog input voltage	15 V
Rated negative supply voltage	-15 V
Forward conduction resistance matching rating	126 ohm
Maximum on-state resistance	1800 ohm

Preview

Download Datasheet

View All

DATASHEET

HI-546, HI-547, HI-548, HI-549

Single 16 and 8, Differential 8-Channel and 4-Channel CMOS Analog MUXs with

Active Overvoltage Protection

The HI-546, HI-547, HI-548 and HI-549 are analog

multiplexers with active overvoltage protection and

guaranteed r

matching. Analog input levels may greatly

exceed either power supply without damaging the device or

disturbing the signal path of other channels. Active

protection circuitry assures that signal fidelity is maintained

even under fault conditions that would destroy other

multiplexers.

Analog inputs can withstand constant 70V

P-P

levels with

15V

supplies. Digital inputs will also sustain continuous

faults up to 4V greater than either supply. In addition, signal

sources are protected from short circuiting should

multiplexer supply loss occur. Each input presents 1k of

resistance under this condition. These features make the

HI-546, HI-547, HI-548 and HI-549 ideal for use in systems

where the analog inputs originate from external equipment

or separately powered circuitry. All devices are fabricated

with 44V Dielectrically Isolated CMOS technology. The

HI-546 is a single 16-Channel, the HI-547 is an 8-Channel

differential, the HI-548 is a single 8-Channel and the HI-549

is a 4-Channel differential device. If input overvoltage

protection is not needed the HI-506/507/508/509

multiplexers are recommended. For further information see

Application Notes AN520 and AN521.

For MIL-STD-883 compliant parts, request the HI-546/883,

HI-547/883, HI-548/883 and HI-549/883 datasheets.

FN3150

Rev 7.00

Jun 15, 2016

Features

• Analog Overvoltage Protection. . . . . . . . . . . . . . . . . . 70V

P-P

• No Channel Interaction During Overvoltage

• Guaranteed r

Matching

• Maximum Power Supply . . . . . . . . . . . . . . . . . . . . . . 44V

• Break-Before-Make Switching

• Analog Signal Range . . . . . . . . . . . . . . . . . . . . . . . .

15V

• Access Time (Typical) . . . . . . . . . . . . . . . . . . . . . . . 500ns

• Standby Power (Typical) . . . . . . . . . . . . . . . . . . . . 7.5mW

• Pb-Free Plus Anneal Available (RoHS Compliant)

Applications

• Data Acquisition

• Industrial Controls

• Telemetry

FN3150 Rev 7.00

Jun 15, 2016

Page 1 of 25
