Lead-free
DLPT05
SURFACE MOUNT DATALINE PROTECTION
DEVICE
Features
NEW PRODUCT
·
·
·
·
·
300 Watts Peak Pulse Power (tp = 8x20ms)
Transient Protection for data line to IEC61000-4-2 level 4
(ESD), 8kV HBM, and IEC 61000-4-4 (EFT)
Low Leakage Current
Surface Mount Package Ideally Suited for Automatic
Insertion
Lead Free/RoHS Compliant (Note 4)
B
TOP VIEW
E
E
D
G
H
K
C
B
C
A
SOT-23
Dim
A
B
C
D
E
G
H
M
L
Min
0.37
1.20
2.30
0.89
0.45
1.78
2.80
0.013
0.903
0.45
0.085
0°
Max
0.51
1.40
2.50
1.03
0.60
2.05
3.00
0.10
1.10
0.61
0.180
8°
Mechanical Data
·
·
·
·
·
·
·
·
·
Case: SOT-23
Case Material: Molded Plastic. UL Flammability
Classification Rating 94V-0
Moisture Sensitivity: Level 1 per J-STD-020C
Terminals: Solderable per MIL-STD-202, Method 208
Lead Free Plating (Matte Tin Finish annealed over
Alloy 42 leadframe).
Terminal Connections: See Diagram
Part Marking (See Page 3): A01
Ordering & Date Code Information: Page 3
Weight: 0.008 grams (approximate)
J
K
L
M
a
J
GROUND
TVS
All Dimensions in mm
LINE TO
BE PROTECTED
V
CC
Maximum Ratings, Total Device
Characteristic
Peak Pulse Power (tp = 8x20ms)
Peak Forward Voltage (I
PP
= 1A, tp = 8x20ms)
Diode Peak Repetitive Reverse Voltage
Thermal Resistance, Junction to Ambient
Operating and Storage Temperature Range
@ T
A
= 25°C unless otherwise specified
Symbol
P
PK
V
FP
V
RRM
R
qJA
T
j
, T
STG
Value
300
2.1
75
417
-55 to +150
Unit
W
V
V
°C/W
°C
Electrical Characteristics, TVS Element
Reverse
Standoff
Voltage
V
RWM
(V)
5
Notes:
@ T
A
= 25°C unless otherwise specified
Max. Clamping
Voltage @ I
pp
= 1A
(Note 3)
V
C
(V)
9.8
Max. Peak Pulse
Current (Note 2)
(A)
17
Typical Total
Capacitance
(Note 1)
(pF)
1.9
Breakdown Voltage
V
BR
@ I
T
Min (V)
6
Max (V)
¾
Test
Current
I
T
(mA)
1.0
Max. Reverse
Leakage @ V
RWM
I
R
(mA)
20
1. V
R
= 0V, f = 1MH
Z
from line to be protected to ground pin.
2. tp = 8x20ms.
3. Clamping voltage values are based on an 8x20ms peak pulse current (I
pp
) waveform.
4. No purposefully added lead.
DS30310 Rev. 6 - 2
1 of 4
www.diodes.com
DLPT05
ã
Diodes Incorporated
100
1.8
1.6
T
j
= 25 °C
f = 1MHz
PEAK PULSE DERATING IN % OF
PEAK POWER OR CURRENT
NEW PRODUCT
C
T
, CAPACITANCE (pF)
75
1.4
1.2
1.0
0.8
0.6
0.4
0.2
See Note 4
50
25
0
0
25
50
75
100 125 150 175 200
T
A
, AMBIENT TEMPERATURE (
°
C)
Fig. 1 Pulse Derating Curve
10
0
0.1
1.0
10
100
V
R,
REVERSE VOLTAGE (V)
Fig. 2 Typical Total Capacitance vs Reverse Voltage
T
j
= 25
°
C
P
d
, PEAK PULSE POWER (kW)
Non Repetitive
Pulse Waveform
See Note 5
1
0.1
0.01
0.1
1.0
10
100
1000
See Note 5
I
P
, PEAK PULSE CURRENT (%I
pp
)
100
Peak Value I
pp
Half Value I
pp
/2
50
t
p
0
8x20 Waveform
as defined by R.E.A.
0
20
40
60
Notes:
5. Measured from line to be protected to ground pin.
6. Curves apply to TVS element of device.
DS30310 Rev. 6 - 2
2 of 4
www.diodes.com
DLPT05
Ordering Information
(Note 7)
Packaging
SOT-23
Shipping
3000/Tape & Reel
NEW PRODUCT
Device
DLPT05-7-F
Notes:
7. For Packaging Details, go to our website at http://www.diodes.com/datasheets/ap02007.pdf.
Marking Information
A01
Date Code Key
Year
Code
Month
Code
1998
J
Jan
1
1999
K
Feb
2
2000
L
March
3
2001
M
Apr
4
A01 = Product Type Marking Code
YM = Date Code Marking
Y = Year ex: N = 2002
M = Month ex: 9 = September
YM
2002
N
May
5
2003
P
Jun
6
2004
R
Jul
7
2005
S
Aug
8
2006
T
Sep
9
2007
U
Oct
O
2008
V
Nov
N
2009
W
Dec
D
Typical Application Schematics
Vcc
Driver
Rg
Transmission Line
Fig. 1 Data Line Terminator
Vcc
Vcc
I/O Line 1
Vcc
IC
I/O Line 2
Fig. 2 Data Line Protection
DS30310 Rev. 6 - 2
3 of 4
www.diodes.com
DLPT05
IMPORTANT NOTICE
Diodes, Inc. and its subsidiaries reserve the right to make changes without further notice to any product herein to make corrections, modifications, enhance-
ments, improvements, or other changes. Diodes, Inc. does not assume any liability arising out of the application or use of any product described herein;
neither does it convey any license under its patent rights, nor the rights of others. The user of products in such applications shall assume all risks of such
use and will agree to hold Diodes Incorporated and all the companies whose products are represented on our website, harmless against all damages.
LIFE SUPPORT
The products located on our website at
www.diodes.com
are not recommended for use in life support systems where a failure or malfunction of the
component may directly threaten life or cause injury without the expressed written approval of Diodes Incorporated.
DS30310 Rev. 6 - 2
4 of 4
www.diodes.com
DLPT05
