RB411D
Diodes
Schottky barrier diode
RB411D
Applications
Low current rectification
External dimensions
(Unit : mm)
Land size figure
(Unit : mm)
1.9
Features
1) Small mold type. (SMD3)
2) Low I
R
3) High reliability.
－0.05
(3)
2.8±0.2
1.6
－0.1
＋0.2
1.0MIN.
0.15
－0.06
＋0.1
0.95
0.8MIN.
0½0.1
0.3½0.6
SMD3
(2)
0.95
0.95
1.9±0.2
(1)
0.8±0.1
1.1±0.2
0.01
Construction
Silicon epitaxial planar
Structure
ROHM : SMD3
JEDEC :S0T-346
JEITA : SC-59
week code
Taping specifications
(Unit : mm)
4.0±0.1
2.0±0.05
φ1.5±0.1
0
1.75±0.1
0.3±0.1
3.5±0.05
8.0±0.2
3.2±0.1
3.2±0.1
4.0±0.1
φ1.05MIN
0½0.5
5.5±0.2
3.2±0.1
1.35±0.1
Absolute maximum ratings
(Ta = 25°C)
Param eter
R evers e voltage (repetitive peak)
Revers e voltage (DC)
Average rectified forward current
（
*1
）
Forward current s urge peak
（
60Hz
・
1cyc
）（
*1
）
J unction tem perature
S torage tem perature
(*1) Rating of per diode
Sym bol
V
RM
V
R
Io
I
FSM
Tj
Ts tg
Lim its
40
20
500
3
125
-40 to +125
Unit
V
V
mA
A
℃
℃
Electrical characteristics
(Ta = 25°C)
Param eter
Forwarad voltage
Revers e current
Capacitance between term inal
Sym bol
V
F
1
V
F
2
I
R
1
Ct1
Min.
-
-
-
-
Typ.
-
-
-
20
Max.
0.50
0.30
30
-
Unit
V
V
µA
pF
I
F
=500m A
I
F
=10m A
V
R
=10V
V
R
=10V , f=1MHz
Conditions
Rev.B
2.4
0.4
＋0.1
2.9±0.2
各リードとも
Each lead has same dimension
同寸法
1/3
Appendix
Notes
No technical content pages of this document may be reproduced in any form or transmitted by any
means without prior permission of ROHM CO.,LTD.
The contents described herein are subject to change without notice. The specifications for the
product described in this document are for reference only. Upon actual use, therefore, please request
that specifications to be separately delivered.
Application circuit diagrams and circuit constants contained herein are shown as examples of standard
use and operation. Please pay careful attention to the peripheral conditions when designing circuits
and deciding upon circuit constants in the set.
Any data, including, but not limited to application circuit diagrams information, described herein
are intended only as illustrations of such devices and not as the specifications for such devices. ROHM
CO.,LTD. disclaims any warranty that any use of such devices shall be free from infringement of any
third party's intellectual property rights or other proprietary rights, and further, assumes no liability of
whatsoever nature in the event of any such infringement, or arising from or connected with or related
to the use of such devices.
Upon the sale of any such devices, other than for buyer's right to use such devices itself, resell or
otherwise dispose of the same, no express or implied right or license to practice or commercially
exploit any intellectual property rights or other proprietary rights owned or controlled by
ROHM CO., LTD. is granted to any such buyer.
Products listed in this document are no antiradiation design.
The products listed in this document are designed to be used with ordinary electronic equipment or devices
(such as audio visual equipment, office-automation equipment, communications devices, electrical
appliances and electronic toys).
Should you intend to use these products with equipment or devices which require an extremely high level of
reliability and the malfunction of with would directly endanger human life (such as medical instruments,
transportation equipment, aerospace machinery, nuclear-reactor controllers, fuel controllers and other
safety devices), please be sure to consult with our sales representative in advance.
About Export Control Order in Japan
Products described herein are the objects of controlled goods in Annex 1 (Item 16) of Export Trade Control
Order in Japan.
In case of export from Japan, please confirm if it applies to "objective" criteria or an "informed" (by MITI clause)
on the basis of "catch all controls for Non-Proliferation of Weapons of Mass Destruction.
Appendix1-Rev1.1
