Mimix Broadband, Inc. 10795 Rockley Rd. Houston, Texas 77099
Tel: 281.988.4600 Fax: 281.988.4615 mimixbroadband.com
Rockwell MDR-6 TWTA
SSPA Replacement Kits
Features:
Units operate over the full 5.9-6.4 GHz frequency range
5 and 10 Watt output power levels are available
Simple and easy Installation Instructions are included
All units accept -21 to -56 VDC input voltage range
Standard 5-Year
Warranty
Description:
Mimix Broadband’s SMaRTPAK (Standard Microwave Radio TWT replacement Power Amplifier Kit) amplifiers are
uniquely designed to combine the DC/DC Converter, microwave amplifier and cooling devices into one single
integrated unit. Each unit has been designed using modern device technology and includes reverse polarity,
overvoltage and excess thermal protection. Unlike TWT's and other TWT replacement options, SMaRTPAKs do not
require a separate, bulky and often unreliable power supply.
All units are designed to directly drop-in place of existing TWT or SSPA units with no modifications saving
significant time and effort. Using the proper equipment, unit installations and alignment can typically be done
almost effortlessly in less than an hour. It is r
ecommended that all first time users have a Mimix Broadband
representative present during initial installation. Ask us about our onsite installation and alignment options.
Mimix is confident that you will be pleased with our product and each unit comes with a standard five-year
warranty. If you do not see a part number that covers your desired frequency,
power or radio type, feel free to
contact us and we will gladly review your requirements.
Electrical Characteristics (T=25
o
C)
Parameter
Frequency Range
Input Return Loss
Input/Output Impedance
Gain
Gain Flatness
Noise Figure
Input Power
Output Power (P1dB)
Spurious
Harmonics
Base Operating T emperature
Humidity (Non-Condensing)
Altitude (Operating)
Altitude (Storage)
DC Power
DC Current @ +12 Volts
Units
GHz
dB
ohms
dB
dB
dB
dBm
dBm
dBc
dBc
o
C
%
ft
ft
V
A
1006418 - 5W
Min
5.9
-
-
45.0
-
-
-
+37.0
-
-
-
-20
0.0
0.0
0.0
-21.0
-
Typ
-
-14.0
50
50.0
+/-0.5
8.0
-12.0
+38.0
-
-
-
-
-
-
-
-
4.5
Max
6.4
-9.5
-
-
+/-1.0
10.0
+5.0
-
-
70.0
60.0
+70
95
16,000
60,000
-56.0
5.0
1005385 - 10W
Min
5.9
-
-
45.0
-
-
-
+40.0
-
-
-
-20
0.0
0.0
0.0
-21.0
-
Typ
-
-14.0
50
50.0
+/-0.5
8.0
-12.0
+41.0
-
-
-
-
-
-
-
-
6.5
Max
6.4
-9.5
-
-
+/-1.0
10.0
+5.0
-
-
70.0
60.0
+70
95
16,000
60,000
-56.0
7.0
Specifications are subject to change without notice. Export of this item may require appropriate export licensing from the U.S. Government. In purchasing
these parts, U.S. Domestic customers accept their obligation to be compliant with U.S. Export Laws. Revision-02-May-02
