DM74ALS652 Octal 3-STATE Bus Transceiver and Register
October 1986
Revised June 2001
DM74ALS652
Octal 3-STATE Bus Transceiver and Register
General Description
This device incorporates an octal transceiver and an octal
D-type register configured to enable transmission of data
from bus to bus or internal register to bus.
This bus transceiver features totem-pole 3-STATE outputs
designed specifically for driving highly-capacitive or rela-
tively low-impedance loads. The high-impedance state and
increased high level logic drive provide this device with the
capability of being connected directly to and driving the bus
lines in a bus organized system without need for interface
or pull-up components. They are particularly attractive for
implementing buffer registers, I/O ports, bidirectional bus
drivers, and working registers.
The registers in the DM74ALS652 are edge-triggered
D-type flip-flops. On the positive transition of the clock
(CAB or CBA), the input data is stored into the appropriate
register. The CAB input controls the transfer of data into
the A register and the CBA input controls the B register.
The SAB and SBA control pins are provided to select
whether real-time data or stored data is transferred. A LOW
input level selects real-time data and a HIGH level selects
stored data. The select controls have a “make before
break” configuration to eliminate a glitch which would nor-
mally occur in a typical multiplexer during the transition
between stored and real-time data.
The enable (GAB and GBA) control pins provide four
modes of operation: real-time data transfer from bus A to
B, real-time data transfer from bus B to A, real-time bus A
and/or B data transfer to internal storage, or internal stored
data transfer to bus A and/or B.
Features
s
Switching specifications at 50 pF
s
Switching specifications guaranteed over full tempera-
ture and V
CC
range
s
Advanced oxide-isolated, ion-implanted Schottky TTL
process
s
3-STATE buffer-type outputs drive bus lines directly
s
Independent registers and enables for A and B buses
s
Multiplexed real-time and stored data
Ordering Code:
Order Number
DM74ALS652WM
DM74ALS652NT
Package Number
M24B
N24C
Package Description
24-Lead Small Outline Integrated Circuit (SOIC), JEDEC MS-013, 0.300" Wide
24-Lead Plastic Dual-In-Line Package (PDIP), JEDEC MS-001, 0.300" Wide
Devices also available in Tape and Reel. Specify by appending the suffix letter “X” to the ordering code.
Connection Diagram
© 2001 Fairchild Semiconductor Corporation
DS009174
www.fairchildsemi.com
DM74ALS652
Function Table
Inputs
GAB
X
L
L
L
L
L
H
H
H
L
H
GBA
H
X
H
H
L
L
H
H
H
L
L
CAB
CBA
H/L
SAB
X
X
X
X
X
X
L
X
X
(Note 2)
X
H
SBA
X
X
X
X
L
H
X
X
X
X
(Note 2)
H
Data I/O (Note 1)
Operation or Function
A1 thru A8
Input
Not Specified
Input
Input
Output
Output
Input
Input
Input
Output
Output
B1 thru B8
Not Specified Store A, Hold B
Input
Input
Input
Input
Input
Output
Output
Output
Input
Output
Store B, Hold A
Store A and B Data
Isolation, Hold Storage
Real-Time B Data to A Bus
Stored B Data to A Bus
Real-Time A Data to B Bus
Stored A Data to B Bus
Store A in both Registers
Store B in both Registers
Stored A Data to B Bus and
Stored B Data to A Bus
↑
H/L
↑
↑
H/L
X
H/L
X
↑
H/L
X
X
X
↑
↑
↑
H or L
↑
↑
↑
H or L
H
=
HIGH Logic Level
L
=
LOW Logic Level
X
=
Don’t Care (Either LOW or HIGH Logic Levels, including transitions)
H/L
=
Either LOW or HIGH Logic Level excluding transitions
↑ =
Positive-going edge of pulse
Note 1:
The data output functions may be enabled or disabled by various signals at the G and DIR inputs. Data input functions are always enabled,
i.e., data at the bus pins will be stored on every LOW-to-HIGH transition on the clock inputs.
Note 2:
Select control
=
L; clocks can occur simultaneously
Select control
=
H; clocks must be staggered in order to load both registers.
Logic Diagram
www.fairchildsemi.com
2
DM74ALS652
Absolute Maximum Ratings
(Note 3)
Supply Voltage
Input Voltage
Control Inputs
I/O Ports
Operating Free-Air Temperature Range
Storage Temperature Range
Typical
θ
JA
N Package
M Package
44.5
°
C/W
80.5
°
C/W
7V
5.5V
0
°
C to
+
70
°
C
Note 3:
The “Absolute Maximum Ratings” are those values beyond which
the safety of the device cannot be guaranteed. The device should not be
operated at these limits. The parametric values defined in the Electrical
Characteristics tables are not guaranteed at the absolute maximum ratings.
The “Recommended Operating Conditions” table will define the conditions
for actual device operation.
7V
−
65
°
C to
+
150
°
C
Recommended Operating Conditions
Symbol
V
CC
V
IH
V
IL
I
OH
I
OL
f
CLK
t
W
t
SU
t
H
T
A
Supply Voltage
HIGH Level Input Voltage
LOW Level Input Voltage
HIGH Level Output Current
LOW Level Output Current
Clock Frequency
Pulse Duration, Clocks LOW or HIGH
Data Setup Time, A before CAB or
B before CBA (Note 4)
Data Hold Time, A after CAB or
B after CBA (Note 4)
Free Air Operating Temperature
0
70
0
↑
ns
0
12.5
10
↑
Parameter
Min
4.5
2
0.8
Nom
5
Max
5.5
Units
V
V
V
mA
mA
MHz
ns
ns
−
15
24
40
°
C
Note 4:
↑ =
with reference to the LOW-to-HIGH transition of the respective clock.
Electrical Characteristics
over recommended free air temperature range
Symbol
Parameter
V
IK
V
OH
Input Clamp Voltage
HIGH Level
Output Voltage
V
OL
LOW Level
Output Voltage
I
I
I
IH
I
IL
I
O
I
CC
Input Current at Maximum
Input Voltage
HIGH Level Input Current
LOW Level
Input Current
Output Drive Current
Supply Current
V
CC
=
Max,
V
I
=
0.4V (Note 5)
V
CC
=
Max, V
O
=
2.25V
V
CC
=
Max
Outputs HIGH
Outputs LOW
Outputs Disabled
Note 5:
For I/O ports the 3-STATE output currents (I
OZH
and I
OZL
) are included in the I
IH
and I
IL
parameters.
Test Conditions
V
CC
=
Min, I
I
= −18
mA
V
CC
=
4.5V to 5.5V
V
CC
=
Min
V
CC
=
Min
I
OH
= −0.4
mA
I
OH
= −3
mA
I
OH
=
Max
I
OL
=
12 mA
I
OL
=
24 mA
I
OL
=
48 mA
V
CC
=
Max
I/O Ports, V
I
=
5.5V
Control Inputs, V
I
=
7V
V
CC
=
Max, V
I
=
2.7V, (Note 5)
Control Inputs
I/O Ports
Min
V
CC
−
2
2.4
2
Typ
Max
−1.2
Units
V
V
3.2
0.25
0.35
0.35
0.4
0.5
0.5
100
100
20
−200
−200
V
µA
µA
µA
mA
mA
−30
47
55
55
−112
76
88
88
3
www.fairchildsemi.com
