NTE30109 Overview

LED − Dual Color 5mm Yellow/Yellow Green

NTE30109 Parametric

Parameter Name	Attribute value
Reach Compliance Code	unknow
Base Number Matches	1

Preview

Download Datasheet

View All

NTE30109

LED

−

Dual Color

3mm Yellow/Yellow Green

Features:

RoHS Compliant

White Diffused

Absolute Maximum Ratings:

= +25°C unless otherwise specified)

Power Dissipation, P

Yellow . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90mW

Yellow Green . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84mW

Continuous Forward Current, I

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25mA

Peak Forward Current (1/10 Duty Ratio, 0.1ms Pulse Width), I

. . . . . . . . . . . . . . . . . . . . . . . 50mA

Reverse Voltage, VR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5V

LED Junction Temperature, T

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . +100°C

Operating Temperature Range, T

opr

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

−25°C

to +80°C

Storage Temperature Range, T

stg

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

−40°C

to +100°C

DIP Soldering Temperature (During Soldering, 3mm from body, 5sec max), T

. . . . . . . . . . +260°C

Electro−Optical Characteristics:

= +25°C unless otherwise specified)

Parameter

View Angle of Half Power

Forward Voltage

Yellow

Yellow Green

Luminous Intensity (Note 1)

Yellow

Yellow Green

Peak Emission Wavelength

Yellow

Yellow Green

Dominate Wave Length (Note 2)

Yellow

Yellow Green

Symbol

2Q 1/2

Test Conditions

IF = 20mA

Min

−

Typ

2.10

2.15

589

570

585

567

Max

−

2.80

−

Unit

deg

mcd

IF = 20mA

λp

IF = 20mA

λd(HUE)

(

)

IF = 20mA

Note 1. Luminous intensity is measured with an Exeltron 2001, Tolerance = 30%.

Note 2. The dominate wavelength,

, is derived from the CIE Chromaticity Diagram and represents

the color of the device.
