MINIATURE WIDEBAND RF AMPLIFIERS
0.1 – 2.0 GHz
FEATURES
•
More Than One Octave Band Frequency Range
•
Small Size With Removable Connectors for Drop-In
Integration
•
Low Power Consumption Options
•
Flat Gain Response
•
Internal Regulator Circuit for Unregulated Power
Supplies
APPLICATIONS
•
•
•
•
•
Microwave Radio & VSAT
Military & Space
Test Instrumentation
Fiber Optics
Telecom Infrastructure
ENVIRONMENTAL RATINGS
Max Input Power……......................................100mW
Operating Temperature Range…….…-55°C to +85°C
Storage Temperature Range…..……-65°C to +125°C
Shock……………...……….….………… 50G, 11 msec
Vibration..………...……….…….. 20G, 100 to 2000 Hz
Specifications: (@ +25°C)
MODEL
FREQ. RANGE
(GHz)
MIN
GAIN
(dB)
11
21
31
11
21
31
10
20
30
10
20
30
10
20
30
10
20
30
10
20
30
MAX
GAIN
VARIATION
(+/- dB)
0.5
0.5
0.75
0.5
0.5
0.75
0.5
0.75
0.75
0.5
0.5
0.75
0.5
0.5
0.75
0.5
0.75
0.75
0.5
0.75
1.0
MAX
N. F. (dB)
MAX
VSWR
P OUT @
1 dB COMP
(dBm)
NOM DC
1
CURRENT @
+12V (mA)
80
140
180
80
140
180
80
140
180
80
140
180
80
140
180
80
140
180
80
140
180
OUTLINE
A0105116A
A0105216A
A0105316A
A0215115A
A0205215A
A0205315A
A0110106A
A0110206A
A0110306A
A0515104A
A0515204A
A0515304A
A0520104A
A0520204A
A0520304A
A0220105A
A0220205A
A0220305A
A0120106A
A0120206A
A0120306A
0.1 - 0.5
6
2:1
+ 15
2A
2A
3B
2A
2A
2A
3B
2A
0.2 - 1.0
5
2:1
+ 15
0.1 - 1.0
6
2:1
+ 15
0.5 - 1.5
4
2:1
+ 15
0.5 - 2.0
4
2:1
+ 15
2A
0.2 - 2.0
5
2:1
+ 15
2A
2A
2A
3B
0.1 - 2.0
6
2:1
+ 15
Note 1: For proper operation the bias voltage shall be limited to +12 V. For lower DC power consumption consideration options are available for DC supplies +7 to +10 V or for regulated +5 V
DC supply.
For Package Outlines see Outline Drawings Page
0606-3-1B
HEROTEK, INC. 155 Baytech Drive, San Jose, California 95134
Phone: (408) 941-8399 Fax: (408) 941-8388 Email:info@herotek.com www.herotek.com
Page 1/1
