MIL-DTL-24308
D-Subminiature
550-039
D-Subminiature
Banding Split Backshell
550 T 039 M 2 F0 B 1-02 B
Basic Part No.
Cable Entry Style
T = Top
S = Side
E = End
Basic Part Number
Finish Symbol (Page 3)
Shell Size (Table I)
B = Band Supplied (600-052), Omit for None
Dash No. (Table II)
0 = Without EMI Gasket, 1 = With EMI Gasket
Jackscrew Type (Page A-4)
Receptacle Mounting (Right Page)
CC = Cable-to-Cable Mounting
F0 = Front Mounting
R1-R9 = Rear Mounting
.440 (11.2)
.440 (11.2)
K*
J*
* Typ.
H*
E
END
ENTR
Y
T
TOP
ENTR
Y
.78 (19.8)
Max
EMI Gasket (Optional)
Dash
K Dia
H Dia
J Dia
No.
01 .125 (3.2) .250 (6.4) .312 (7.9)
02 .250 (6.4) .375 (9.5) .438 (11.1)
03 .312 (7.9) .438 (11.1) .500 (12.7)
04 .395 (10.0) .500 (12.7) .562 (14.3)
05 .438 (11.1) .562 (14.3) .625 (15.9)
06 .500 (12.7) .625 (15.9) .688 (17.5)
07 .562 (14.3) .688 (17.5) .750 (19.1)
08 .624 (15.8) .750 (19.1) .812 (20.6)
09 .688 (17.5) .812 (20.6) .875 (22.2)
10 .750 (19.1) .875 (22.2) .937 (23.8)
.812 (20.6) .937 (23.8) 1.000 (25.4)
11
12 .875 (22.2) 1.000 (25.4) 1.125 (28.6)
13 .937 (23.8) 1.062 (27.0) 1.187 (30.1)
14 1.000 (25.4) 1.125 (28.6) 1.250 (31.8)
© 2011 Glenair, Inc.
TABLE II: CABLE ENTRY
S
SIDE
ENTR
Y
Com’l Max En-
Shell try Dash
Shell Size
No.
Size
05
Ref
1
05
E/09
2
05
A/15
3
07
B/25
4
08
C/37
5
14
D/50
6
F/104
CAGE Code 06324
TABLE I: SHELL SIZE
1. Metric dimensions (mm) are
indicated in parentheses.
2.
DO NOT USE
CONNECTORS WITH
FLOAT MOUNTINGS.
Printed in U.S.A.
GLENAIR, INC.
•
1211 AIR WAY
•
GLENDALE, CA 91201-2497
•
818-247-6000
•
FAX 818-500-9912
www.glenair.com
E-Mail: sales@glenair.com
A-38
D-Subminiature Split Backshells
Standard Dimensions
Termination
Type
Jackscrew
Types B, D,
E, H, K
(Page A-4)
P
Jackscrew
Types B, D,
E, H, K
(Page A-4)
F
R
F
E
E
S - SIDE
ENTRY
T - TOP
ENTRY
Termination
Type
A
D
C
B
Jackscrew Types B , D, H
and J Only (Page A-4)
Shrink Sleeve (As Required)
E - END
ENTRY
E
A
G
.12 (3.0) Ref.
Com’l
Shell Shell Size
Ref
Size
1
E/09
A/15
2
B/25
3
4
C/37
D/50
5
6
F/104
COMMON CONNECTOR/SHELL INTERFACE & BACKSHELL DIMENSIONS
A
Max
1.393 (35.4)
1.706 (43.3)
2.265 (57.5)
2.900 (73.7)
2.800 (71.1)
2.900 (73.7)
B
Max
.624 (15.8)
.624 (15.8)
.624 (15.8)
.624 (15.8)
.750 (19.1)
.844 (21.4)
C Ref.
.312 (7.9)
.312 (7.9)
.312 (7.9)
.312 (7.9)
.375 (9.5)
.422 (10.7)
±.005
.984
1.312
1.852
2.500
2.406
2.500
D
(.1)
(25.0)
(33.3)
(47.0)
(63.5)
(61.1)
(63.5)
P
(18.5)
(26.7)
(40.5)
(56.9)
(54.4)
(56.9)
R Ref
.719 (18.3)
.719 (18.3)
.938 (23.8)
.938 (23.8)
.938 (23.8)
1.094 (27.8)
.730
1.050
1.594
2.240
2.140
2.240
Panel
Dash
No. Thickness
n/a
CC
n/a
F0
.031 (.8)
R1
.047 (1.2)
R2
.062 (1.6)
R3
.093 (2.4)
R4
.104 (2.6)
R5
.125 (3.2)
R6
.156 (4.0)
R7
.135 (3.4)
R8
.188 (4.8)
R9
CABLE MOUNTING AND BACKSHELL DIMENSIONS
E
.174 (4.4)
.343 (8.7)
.247 (6.3)
.231 (5.9)
.216 (5.5)
.185 (4.7)
.174 (4.4)
.153 (3.9)
.125 (3.2)
.140 (3.6)
.094 (2.4)
Sizes 1 & 2
1.451 (36.9)
1.625 (41.3)
1.525 (38.7)
1.509 (38.3)
1.500 (38.1)
1.470 (37.3)
1.451 (36.9)
1.430 (36.3)
1.400 (35.6)
1.417 (36.0)
1.368 (34.7)
F + .031 (0.79)
Sizes 3 - 5
1.671 (42.4)
1.844 (46.8)
1.745 (44.3)
1.728 (43.9)
1.720 (43.7)
1.690 (42.9)
1.671 (42.4)
1.650 (41.9)
1.620 (41.1)
1.637 (41.6)
1.590 (40.4)
Size 6
1.820 (46.2)
2.000 (50.8)
1.890 (48.0)
1.875 (47.6)
1.860 (47.2)
1.829 (46.5)
1.820 (46.2)
1.798 (45.7)
1.767 (44.9)
1.805 (45.8)
1.740 (44.2)
G + .031 (0.79)
Sizes 1 & 2 Sizes 3 - 5
1.583 (40.2) 1.831 (46.5)
1.750 (44.5) 2.000 (50.8)
1.656 (42.1) 1.904 (48.4)
1.640 (41.7) 1.888 (48.0)
1.625 (41.3) 1.873 (47.6)
1.594 (40.5) 1.842 (46.8)
1.583 (40.2) 1.831 (46.5)
1.563 (39.7) 1.811 (46.0)
1.531 (38.9) 1.781 (45.2)
1.550 (39.4) 1.798 (45.7)
1.500 (38.1) 1.750 (44.5)
Metric dimensions (mm) are indicated in parentheses.
© 2011 Glenair, Inc.
CAGE Code 06324
Printed in U.S.A.
GLENAIR, INC.
•
1211 AIR WAY
•
GLENDALE, CA 91201-2497
•
818-247-6000
•
FAX 818-500-9912
www.glenair.com
E-Mail: sales@glenair.com
A-39
