NC7NZ17 TinyLogic UHS Triple Buffer with Schmitt Trigger Inputs
July 2001
Revised November 2005
NC7NZ17
TinyLogic
UHS Triple Buffer
with Schmitt Trigger Inputs
General Description
The NC7NZ17 is a triple buffer with Schmitt trigger inputs
from Fairchild’s Ultra High Speed Series of TinyLogic
in
the US8 package. The device is fabricated with advanced
CMOS technology to achieve ultra high speed with high
output drive while maintaining low static power dissipation
over a very broad V
CC
operating range. The device is
specified to operate over the 1.65V to 5.5V V
CC
range. The
inputs and outputs are high impedance when V
CC
is 0V.
Inputs tolerate voltages up to 7V independent of V
CC
oper-
ating voltage. Schmitt trigger inputs typically achieve 1V
hysteresis between the positive going and negative going
input threshold voltage at 5V V
CC
.
Features
s
Space saving US8 surface mount package
s
MicroPak
Pb-Free leadless package
s
Ultra High Speed: t
PD
3.6 ns Typ into 50 pF at 5V V
CC
s
High Output Drive:
±
24 mA at 3V V
CC
s
Broad V
CC
Operating Range; 1.65V to 5.5V
s
Power down high impedance inputs/outputs
s
Overvoltage tolerant inputs facilitate 5V to 3V translation
s
Patented noise/EMI reduction circuitry implemented
Ordering Code:
Product
Order
Number
NC7NZ17K8X
NC7NZ17L8X
Package
Number
MAB08A
MAC08A
Code
Top Mark
NZ17
U4
8-Lead US8, JEDEC MO-187, Variation CA 3.1mm Wide 3k Units on Tape and Reel
Pb-Free 8-Lead MicroPak, 1.6 mm Wide
5k Units on Tape and Reel
Package Description
Supplied As
Pb-Free package per JEDEC J-STD-020B.
TinyLogic is a registered trademark of Fairchild Semiconductor Corporation.
MicroPak is a trademark of Fairchild Semiconductor Corporation.
© 2005 Fairchild Semiconductor Corporation
DS500493
www.fairchildsemi.com
NC7NZ17
Logic Symbol
IEEE/IEC
Connection Diagrams
Pin Descriptions
(Top View)
Pin Names
A
1
, A
2
, A
3
Y
1
, Y
2
, Y
3
Description
Data Inputs
Output
Pin One Orientation Diagram
Function Table
Y
=
A
Input
A
L
H
H
=
HIGH Logic Level
L
=
LOW Logic Level
Output
Y
L
H
Pad Assignments for MicroPak
AAA represents Product Code Top Mark - see ordering code
Note:
Orientation of Top Mark determines Pin One location. Read the Top
Product Code Mark left to right, Pin One is the lower left pin (see diagram).
(Top Thru View)
www.fairchildsemi.com
2
NC7NZ17
Absolute Maximum Ratings
(Note 1)
Supply Voltage (V
CC
)
DC Input Voltage (V
IN
)
DC Output Voltage (V
OUT
)
DC Input Diode Current (I
IK
)
@ V
IN
< −
0.5V
DC Output Diode Current (I
OK
)
@ V
OUT
< −
0.5V
DC Output Current (I
OUT
)
DC V
CC
/GND Current (I
CC
/I
GND
)
Storage Temperature (T
STG
)
Junction Temperature under Bias (T
J
)
Junction Lead Temperature (T
L
)
(Soldering, 10 seconds)
Power Dissipation (P
D
) @
+
85
°
C
260
°
C
250 mW
−
0.5V to
+
7V
−
0.5V to
+
7V
−
0.5V to
+
7V
−
50 mA
−
50 mA
±
50 mA
±
100 mA
−
65
°
C to
+
150
°
C
150
°
C
Recommended Operating
Conditions
(Note 2)
Supply Voltage Operating (V
CC
)
Supply Voltage Data Retention (V
CC
)
Input Voltage (V
IN
)
Output Voltage (V
OUT
)
Operating Temperature (T
A
)
Thermal Resistance (
θ
JA
)
1.65V to 5.5V
1.5V to 5.5V
0V to 5.5V
0V to V
CC
−
40
°
C to
+
85
°
C
250
°
C/W
Note 1:
Absolute maximum ratings are DC values beyond which the device
may be damaged or have its useful life impaired. The datasheet specifica-
tions should be met, without exception, to ensure that the system design is
reliable over its power supply, temperature, and output/input loading vari-
ables. Fairchild does not recommend operation outside datasheet specifi-
cations.
Note 2:
Unused inputs must be held HIGH or LOW. They may not float.
DC Electrical Characteristics
Symbol
V
P
Parameter
Positive Threshold
Voltage
V
CC
(V)
1.65
2.3
3.0
4.5
5.5
V
N
Negative Threshold
Voltage
1.65
2.3
3.0
4.5
5.5
V
H
Hysteresis Voltage
1.65
2.3
3.0
4.5
5.5
V
OH
HIGH Level Output
Voltage
1.65
2.3
3.0
4.5
1.65
2.3
3.0
3.0
4.5
V
OL
LOW Level Output
Voltage
1.65
2.3
3.0
4.5
1.65
2.3
3.0
3.0
4.5
I
IN
I
OFF
Input Leakage Current
Power Off Leakage Current
0 to 5.5
0.0
Min
0.7
1.0
1.3
1.9
2.2
0.25
0.40
0.6
1.0
1.2
0.15
0.25
0.4
0.6
0.7
1.55
2.2
2.9
4.4
1.29
1.9
2.4
2.3
3.8
T
A
= +25°C
Typ
1.07
1.38
1.74
2.43
2.88
0.56
0.75
0.98
1.42
1.68
0.51
0.62
0.76
1.01
1.20
1.65
2.3
3.0
4.5
1.52
2.14
2.75
2.62
4.13
0.0
0.0
0.0
0.0
0.08
0.10
0.16
0.24
0.25
0.1
0.1
0.1
0.1
0.24
0.3
0.4
0.55
0.55
±0.1
1
Max
1.5
1.8
2.2
3.1
3.6
0.9
1.15
1.5
2.0
2.3
1.0
1.1
1.2
1.5
1.7
T
A
= −40°C
to
+85°C
Min
0.7
1.0
1.3
1.9
2.2
0.25
0.40
0.6
1.0
1.2
0.15
0.25
0.4
0.6
0.7
1.55
2.2
2.9
4.4
1.29
1.9
2.4
2.3
3.8
0.1
0.1
0.1
0.1
0.24
0.3
0.4
0.55
0.55
±1.0
10
µA
µA
V
V
IN
=
V
IL
I
OL
=
4 mA
I
OL
=
8 mA
I
OL
=
16 mA
I
OL
=
24 mA
I
OL
=
32 mA
V
IN
=
5.5V, GND
V
IN
or V
OUT
=
5.5V
I
OL
=
100
µA
V
V
IN
=
V
IH
I
OH
= −4
mA
I
OH
= −8
mA
I
OH
= −16
mA
I
OH
= −24
mA
I
OH
= −32
mA
I
OH
= −100 µA
Max
1.5
1.8
2.2
3.1
3.6
0.9
1.15
1.5
2.0
2.3
1.0
1.1
1.2
1.5
1.7
V
V
V
Units
Conditions
3
www.fairchildsemi.com
NC7NZ17
DC Electrical Characteristics
Symbol
I
CC
Parameter
Quiescent Supply Current
V
CC
(V)
1.65 to 5.5
(Continued)
T
A
= +25°C
T
A
= −40°C
to
+85°C
Max
1.0
Min
Max
10
µA
V
IN
=
5.5V, GND
Units
Conditions
Min
Typ
AC Electrical Characteristics
Symbol
t
PLH
t
PHL
Parameter
Propagation Delay
V
CC
(V)
1.8
±
0.15
2.5
±
0.2
3.3
±
0.3
5.0
±
0.5
t
PLH
t
PHL
C
IN
C
PD
Input Capacitance
Power Dissipation
Capacitance
Propagation Delay
3.3
±
0.3
5.0
±
0.5
0
3.3
5.0
Min
2.0
1.5
1.0
0.8
1.5
1.0
T
A
= +25°C
Typ
6.9
4.8
3.7
3.0
4.3
3.6
2.5
9
11
Max
11.9
8.2
5.6
4.7
6.6
5.6
T
A
= −40°C
to
+85°C
Min
2.0
1.5
1.0
0.8
1.5
1.0
Max
13.1
9.0
6.2
5.2
7.3
6.2
ns
pF
pF
(Note 3)
Figure 2
C
L
=
50 pF,
R
L
=
500Ω
Figures
1, 3
ns
C
L
=
15 pF,
R
L
=
1 MΩ
Figures
1, 3
Units
Conditions
Figure
Number
Note 3:
C
PD
is defined as the value of the internal equivalent capacitance which is derived from dynamic operating current consumption (I
CCD
) at no output
loading and operating at 50% duty cycle. (See Figure 2.) C
PD
is related to I
CCD
dynamic operating current by the expression:
I
CCD
=
(C
PD
)(V
CC
)(f
IN
)
+
(I
CC
static).
Dynamic Switching Characteristics
Symbol
V
OLP
V
OLV
Parameter
Quiet Output Dynamic Peak V
OL
Quiet Output Dynamic Valley V
OL
Conditions
C
L
=
50pF, V
IH
=
5.0V, V
IL
=
0V
C
L
=
50pF, V
IH
=
5.0V, V
IL
=
0V
V
CC
(V)
5.0
5.0
T
A
=
25°C
Typical
0.8
−0.8
Unit
V
V
AC Loading and Waveforms
C
L
includes load and stray capacitance
Input PRR
=
1.0 MHz; t
W
=
500 ns
FIGURE 1. AC Test Circuit
Input
=
AC Waveform; t
r
=
t
f
=
1.8 ns;
PRR
=
variable; Duty Cycle
=
50%
FIGURE 3. AC Waveforms
FIGURE 2. I
CCD
Test Circuit
www.fairchildsemi.com
4
NC7NZ17
Tape and Reel Specification
TAPE FORMAT for US8
Package
Designator
K8X
Tape
Section
Leader (Start End)
Carrier
Trailer (Hub End)
TAPE DIMENSIONS
inches (millimeters)
Number
Cavities
125 (typ)
3000
75 (typ)
Cavity
Status
Empty
Filled
Empty
Cover Tape
Status
Sealed
Sealed
Sealed
TAPE FORMAT for MicroPak
Package
Designator
L8X
Tape
Section
Number
Cavities
125 (typ)
3000
75 (typ)
Cavity
Status
Empty
Filled
Empty
Cover Tape
Status
Sealed
Sealed
Sealed
Leader (Start End)
Carrier
Trailer (Hub End)
TAPE DIMENSIONS
inches (millimeters)
5
www.fairchildsemi.com
