LH52256AT-70LL datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > storage> storage> LH52256AT-70LL

LH52256AT-70LL: DescriptionStandard SRAM, 32KX8, 70ns, CMOS, PDSO28, TSOP1-28; Categorystorage storage; File Size147KB，1 Pages; ManufacturerSHARP; Websitehttp://sharp-world.com/products/device/

Download Datasheet Parametric Compare View All

LH52256AT-70LL Overview

Standard SRAM, 32KX8, 70ns, CMOS, PDSO28, TSOP1-28

LH52256AT-70LL Parametric

Parameter Name	Attribute value
Maker	SHARP
package instruction	TSOP1-28
Reach Compliance Code	unknown
Maximum access time	70 ns
JESD-30 code	R-PDSO-G28
length	11.8 mm
memory density	262144 bit
Memory IC Type	STANDARD SRAM
memory width	8
Number of functions	1
Number of terminals	28
word count	32768 words
character code	32000
Operating mode	ASYNCHRONOUS
Maximum operating temperature	70 °C
Minimum operating temperature
organize	32KX8
Package body material	PLASTIC/EPOXY
encapsulated code	TSOP1
Package shape	RECTANGULAR
Package form	SMALL OUTLINE, THIN PROFILE
Certification status	Not Qualified
Maximum seat height	1.2 mm
Maximum supply voltage (Vsup)	5.5 V
Minimum supply voltage (Vsup)	4.5 V
Nominal supply voltage (Vsup)	5 V
surface mount	YES
technology	CMOS
Temperature level	COMMERCIAL
Terminal form	GULL WING
Terminal pitch	0.55 mm
Terminal location	DUAL
width	8 mm
Base Number Matches	1

Preview

Download Datasheet

View All

LH52256AT-70LL Related Products

	LH52256AT-70LL	LH52256AVHT	LH51256N-10L	LH52256AT-10LL	LH52256AVTR	LH52256AN-70LL	LH52256AVHN	LH52256AN-10LL	LH52256AN-85LL	LH52256AT-85LL
Description	Standard SRAM, 32KX8, 70ns, CMOS, PDSO28, TSOP1-28	Standard SRAM, 32KX8, 200ns, CMOS, PDSO28, TSOP1-28	Standard SRAM, 32KX8, 100ns, CMOS, PDSO28, SOP-28	Standard SRAM, 32KX8, 100ns, CMOS, PDSO28, TSOP1-28	Standard SRAM, 32KX8, 200ns, CMOS, PDSO28, REVERSE, TSOP1-28	Standard SRAM, 32KX8, 70ns, CMOS, PDSO28, SOP-28	Standard SRAM, 32KX8, 200ns, CMOS, PDSO28, SOP-28	Standard SRAM, 32KX8, 100ns, CMOS, PDSO28, SOP-28	Standard SRAM, 32KX8, 85ns, CMOS, PDSO28, SOP-28	Standard SRAM, 32KX8, 85ns, CMOS, PDSO28, TSOP1-28
Maker	SHARP	SHARP	SHARP	SHARP	SHARP	SHARP	SHARP	SHARP	SHARP	SHARP
package instruction	TSOP1-28	TSOP1-28	SOP-28	TSOP1-28	REVERSE, TSOP1-28	SOP-28	SOP-28	SOP-28	SOP-28	TSOP1-28
Reach Compliance Code	unknown	unknown	unknown	unknown	unknown	unknown	unknown	unknown	unknown	unknown
Maximum access time	70 ns	200 ns	-	100 ns	200 ns	70 ns	200 ns	100 ns	85 ns	85 ns
JESD-30 code	R-PDSO-G28	R-PDSO-G28	-	R-PDSO-G28	R-PDSO-G28	R-PDSO-G28	R-PDSO-G28	R-PDSO-G28	R-PDSO-G28	R-PDSO-G28
length	11.8 mm	11.8 mm	-	11.8 mm	11.8 mm	18 mm	18 mm	18 mm	18 mm	11.8 mm
memory density	262144 bit	262144 bit	-	262144 bit	262144 bit	262144 bit	262144 bit	262144 bit	262144 bit	262144 bit
Memory IC Type	STANDARD SRAM	STANDARD SRAM	-	STANDARD SRAM	STANDARD SRAM	STANDARD SRAM	STANDARD SRAM	STANDARD SRAM	STANDARD SRAM	STANDARD SRAM
memory width	8	8	-	8	8	8	8	8	8	8
Number of functions	1	1	-	1	1	1	1	1	1	1
Number of terminals	28	28	-	28	28	28	28	28	28	28
word count	32768 words	32768 words	-	32768 words	32768 words	32768 words	32768 words	32768 words	32768 words	32768 words
character code	32000	32000	-	32000	32000	32000	32000	32000	32000	32000
Operating mode	ASYNCHRONOUS	ASYNCHRONOUS	-	ASYNCHRONOUS	ASYNCHRONOUS	ASYNCHRONOUS	ASYNCHRONOUS	ASYNCHRONOUS	ASYNCHRONOUS	ASYNCHRONOUS
Maximum operating temperature	70 °C	85 °C	-	70 °C	70 °C	70 °C	85 °C	70 °C	70 °C	70 °C
organize	32KX8	32KX8	-	32KX8	32KX8	32KX8	32KX8	32KX8	32KX8	32KX8
Package body material	PLASTIC/EPOXY	PLASTIC/EPOXY	-	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY
encapsulated code	TSOP1	TSOP1	-	TSOP1	TSOP1-R	SOP	SOP	SOP	SOP	TSOP1
Package shape	RECTANGULAR	RECTANGULAR	-	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR
Package form	SMALL OUTLINE, THIN PROFILE	SMALL OUTLINE, THIN PROFILE	-	SMALL OUTLINE, THIN PROFILE	SMALL OUTLINE, THIN PROFILE	SMALL OUTLINE	SMALL OUTLINE	SMALL OUTLINE	SMALL OUTLINE	SMALL OUTLINE, THIN PROFILE
Certification status	Not Qualified	Not Qualified	-	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified
Maximum seat height	1.2 mm	1.2 mm	-	1.2 mm	1.2 mm	2.6 mm	2.6 mm	2.6 mm	2.6 mm	1.2 mm
Maximum supply voltage (Vsup)	5.5 V	3.6 V	-	5.5 V	5.5 V	5.5 V	3.6 V	5.5 V	5.5 V	5.5 V
Minimum supply voltage (Vsup)	4.5 V	2.7 V	-	4.5 V	2.7 V	4.5 V	2.7 V	4.5 V	4.5 V	4.5 V
Nominal supply voltage (Vsup)	5 V	3.3 V	-	5 V	3.3 V	5 V	3 V	5 V	5 V	5 V
surface mount	YES	YES	-	YES	YES	YES	YES	YES	YES	YES
technology	CMOS	CMOS	-	CMOS	CMOS	CMOS	CMOS	CMOS	CMOS	CMOS
Temperature level	COMMERCIAL	OTHER	-	COMMERCIAL	COMMERCIAL	COMMERCIAL	OTHER	COMMERCIAL	COMMERCIAL	COMMERCIAL
Terminal form	GULL WING	GULL WING	-	GULL WING	GULL WING	GULL WING	GULL WING	GULL WING	GULL WING	GULL WING
Terminal pitch	0.55 mm	0.55 mm	-	0.55 mm	0.55 mm	1.27 mm	1.27 mm	1.27 mm	1.27 mm	0.55 mm
Terminal location	DUAL	DUAL	-	DUAL	DUAL	DUAL	DUAL	DUAL	DUAL	DUAL
width	8 mm	8 mm	-	8 mm	8 mm	8.6 mm	8.6 mm	8.6 mm	8.6 mm	8 mm
