5-175694-1

Description
CONNECTOR, 11-11 CONTACT(S), MALE, BOARD MOUNT, PCB ADAPTER
CategoryThe connector    The connector
File Size116KB,1 Pages
ManufacturerTE Connectivity
Websitehttp://www.te.com
Download Datasheet Parametric View All

5-175694-1 Overview

CONNECTOR, 11-11 CONTACT(S), MALE, BOARD MOUNT, PCB ADAPTER

5-175694-1 Parametric

Parameter NameAttribute value
Is it Rohs certified?incompatible
MakerTE Connectivity
Reach Compliance Codeunknown
Other featuresPANEL MOUNTABLE
Connector typeBOARD CONNECTOR ADAPTER
Contact to complete cooperationTIN
Contact completed and terminatedTIN
Contact point genderMALE-MALE
Contact materialBRASS
DIN complianceNO
Filter functionNO
IEC complianceNO
JESD-609 codee3
MIL complianceNO
Mixed contactsNO
Installation typeBOARD
触点数量:侧 111
触点数量:侧 211
Number of rows loaded1
OptionsGENERAL PURPOSE
direct connectionNO
UL Flammability Code94V-0
Base Number Matches1
C orporate Hom e
|
Electronic Components
|
Se gm e nts
|
W ho W e Are
My Account
Searc h
Products
Documentation
Resources
My Account
Customer Support
Home
>
Products
>
By Type
>
Discrete Wire C onnectors - IDC
>
Product Feature Selector
> Product Details
5-175694-1 Product Details
Live Product Chat
Product Photo
2mm AMP CT Connectors
Not EU R oHS or ELV C om plia nt
(
Find R oHS C om plia nt Alte rna te s
)
Quick Links
C heck Pricing & Availability
Search for Tooling
Product Feature Selector
C ontact Us About This Product
5-175694-1
T E I nternal N umber: 5 - 1 7 5 6 9 4 - 1
Product Highlights:
l
C onnector
l
C onnector Type = MT (Mass Termination)
l
Mating Type = Header
l
Number of Positions = 11
l
Number of Rows = 1
View all Features
Superseded
Search for Replacement Parts
View 3D PDF
Documentation & Additional Information
Product Drawings:
l
None Available
Catalog Pages/Data Sheets:
l
None Available
Product Specifications:
l
AMP C ommon Termination (C T), C onn, 2mm Pitch, M/T Type
(PDF, English)
Application Specifications:
l
None Available
Instruction Sheets:
l
None Available
CAD Files:
(C
AD Format & C ompression Information)
l
2D Drawing
(DXF, Version J)
l
3D Model
(IGES, Version J)
l
3D Model
(STEP, Version J)
List all Documents
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
l
Product Type
= C onnector
l
C onnector Type
= MT (Mass Termination)
l
Mating Type
= Header
l
Number of Positions
= 11
Mechanical Attachment:
l
Panel Attachment
= With
Termination Related Features:
l
Solder Tail C ontact Plating = Pre-tinned
Body Related Features:
l
Number of Rows
= 1
l
Header Body Style
= Box
l
C enterline (mm [in]) = 2.00 [0.079]
Contact Related Features:
l
C ontact Base Material = Brass
l
C ontact Mating Area Plating Material = Pre-Tin
Housing Related Features:
l
Housing Material
= Nylon
l
Housing C olor
= Yellow
l
Housing Flammability Rating = UL 94V-0
Industry Standards:
l
RoHS/ELV C ompliance
= Not ELV/RoHS compliant
l
Lead Free Solder Processes
= Not relevant for lead free process
Conditions for Usage:
l
Terminate To
= Printed C ircuit Board
Other:
l
Brand = AMP
Additional Information:
l
Product Line Information
Related Products:
l
Tooling
A dd to M y P art L is t
Reques t Sample
Find Similar P roduc ts
Buy P roduc t
Provide Website Feedback
|
Need Help?
Home
|
C ustomer Support
|
Suppliers
|
Site Map
|
Privacy Policy
|
Browser Support
©
2009 Tyco Electronics C orporation All Rights Reserved
