www.hamlin.com
55075 Hall Effect Geartooth Speed Sensor
Features
●
Rotary position geartooth sensor
●
Stainless steel M12 threaded barrel
●
Electronic protection against severe and
automotive environments
Benefits
●
Long life; up to 20 billion operations
●
High speed operation
●
No chopper delay
●
Unaffected by harsh environments
●
Rotary orientation not critical
●
On-chip 10 bit A/D converter
●
Customer selection of cable length and
connector type
Applications
●
●
●
●
Geartooth sensor
Camshaft sensor
Linear encoder
Rotary encoder
●
Self adjusting magnetic range
●
3 wire (voltage output)
●
EMC Protection (consult Hamlin)
●
Short circuit/reverse voltage protection
DIMENSIONS (in) mm
BLOCK DIAGRAM
SPECIFICATIONS
Hall Type
Digital Switch
3 Wire (Voltage Output)
Maximum
Operation
Overvoltage Protection
Vdc
Vdc
Vdc - max.
Vdc - min.
Vdc - max.
mA - max.
mA - min.
mA - max.
KHz-max.
Operating
Storage
°C
°C
-25 to +25.2
4.75 to 25.2
27
VDD - 2 (sinking output with internal pull-up resistor)
0.6 @20mA
20
1
10.5
15
-40 to +85
-65 to +85
Supply Voltage (Note1)
Output High Voltage
Output Low Voltage
Output Current (continuously on)
Current Consumption
Switching Speed
Temperature
Note 1: As long as Tj (Junction Temperature) is not exceeded.
APPLICATION EXAMPLE - Geartooth Sensor
CUSTOMER OPTIONS - Cable Length and Terminations
Table 1
Cable Length Options:
(Cable Type 24 AWG 7/32
PVC 105°C Double Insulated
Table 2
Termination Options:
Select
Option
A
Description
Tinned leads
(.059") 1.5mm Typical
Select
Option
01
Cable
Length
(in) mm
(3.94) 100
(11.81) 300
(19.69) 500
(29.53) 750
(39.37) 1000
C
D
E
6.35mm fastons
AMP MTE 2,54mm pitch
Jst xhp 2,5mm pitch
Typical Output
02
03
04
05
ORDERING INFORMATION
55075
Series 55075
Cable Length
Termination
Table 1
Table 2
00
XX
X
Hamlin USA
Hamlin Europe
Hamlin China
Tel: +1 920 648 3000
•
Fax: +1 920 648 3001
•
Email: sales.us@hamlin.com
Tel: +44 (0)1603 257700
•
Fax: +44 (0)1603 257702
•
Email: sales.uk@hamlin.com
Tel: +86 (0) 512 69365 800
•
Fax: +86 (0) 512 69365 811
•
Email: sales.cn@hamlin.com
DRGNo: 55075XXXXX REV : AG Date: 9/6/12 DCR:B9016
