5mm FLANGE BASED LED LAMP
BLF051SYC-6V-P
SUPER BRIGHT YELLOW
Features
!
BUILT-IN CURRENT LIMITING RESISTOR FOR DIRECT
Description
The Super Bright Yellow source color devices are made
with DH InGaAlP on GaAs substrate Light Emitting
Diode.
APPLICATION OF DIFFERENT ACROSS CURRENT.
!
LONG LIFE.
!
LOW
CURRENT, POWER SAVINGS.
!
LOW MAINTENANCE.
!
DIFFERENT
COLOR AVAILABLE.
!
SOLID STATE, HIGH VIBRATION RESISTANT.
!
6V INTERNAL RESISTOR.
Package Dimensions
Notes:
1. All dimensions are in millimeters (inches).
2. Tolerance is
±0.25(0.01")
unless otherwise noted.
3. Specifications are subject to change without notice.
SPEC NO: DSAB3169
APPROVED: J.LU
REV NO: V.2
CHECKED: Allen Liu
DATE: APR/08/2003
DRAWN: L.ZHANG
PAGE: 1 OF 3
Selection Guide
P ar t N o .
Dic e
L en s Ty p e
Min .
BLF051SYC-6V-P
SUPER BRIGHT YELLOW(InGaAlP)
WATER CLEAR
280
Iv (m c d )
V=6V
Ty p .
500
V i ew i n g
An g l e
2θ1/2
30°
Note:
1.
θ1/2
is the angle from optical centerline where the luminous intensity is 1/2 the optical centerline value.
Electrical / Optical Characteristics at T
A
=25°C
°
Sy m b o l
λ
peak
λ
D
∆λ
1/2
I
F
I
R
P ar am et er
Peak Wavelength
Dominate Wavelength
D ev i c e
Super Bright Yellow
Super Bright Yellow
Ty p .
590
588
28
25.8
10
Max .
Un its
nm
nm
nm
mA
uA
Tes t Co n d it io n s
V
F
=6V
V
F
=6V
V
F
=6V
V
F
=6V
V
R
=5V
Spectral Line Half-width Super Bright Yellow
ForwardCurrent
Reverse Current
Super Bright Yellow
Super Bright Yellow
Absolute Maximum Ratings at T
A
=25°C
°
P ar am et er
Power dissipation
Forward Voltage
Reverse Voltage
Operating Temperature
Storage Temperature
Su p er B r ig h t Yello w
150
7
5
-40
°
C To + 70
°C
-40
°
C To + 85
°C
Un its
mW
V
V
SPEC NO: DSAB3169
APPROVED: J.LU
REV NO: V.2
CHECKED: Allen Liu
DATE: APR/08/2003
DRAWN: L.ZHANG
PAGE: 2 OF 3
