Surface Mount Aluminum Electrolytic Capacitors
NACNW Series
FEATURES
• CYLINDRICAL V-CHIP CONSTRUCTION FOR SURFACE MOUNTING
• NON-POLARIZED, 1000 HOURS AT 105
O
C
• 5.5mm HEIGHT
• ANTI-SOLVENT (2 MINUTES)
• DESIGNED FOR REFLOW SOLDERING
includes all homogeneous materials
RoHS
Compliant
CHARACTERISTICS
*See Part Number System for Details
6.3 ~ 50Vcc
0.1 ~ 47µF
-55 ~ +105°C
±20% (M)
0.03CV + 8µA max.
W.V. (Vdc)
Tan
δ
@ 120Hz/20°C
W.V. (Vdc)
Z -25°C/Z +20°C
Z -40°C/Z +20°C
Capacitance Change
Tan
δ
Leakage Current
6.3
10
16
25
35
50
0.24
0.22
0.20
0.20
0.20
0.18
6.3
10
16
25
35
50
3
3
2
2
2
2
8
8
4
4
3
3
Within ±25% of initial measured value
Less than 200% of specified max. value
Less than specified max. value
Rated Voltage Range
Rated Capacitance Range
Operating Temp. Range
Capacitance Tolerance
Max. Leakage Current
After 1 Minutes @ 20°C
Tan
δ
@ 120Hz/20°C
Low Temperature Stability
Impedance Ratio @ 120Hz
Load Life Test
105°C 1,000 Hours
(Reverse polarity every 500 Hours)
STANDARD VALUES, CASE SIZES & SPECIFICATIONS
Cap.
(µF)
22
33
47
10
22
33
4.7
10
22
33
3.3
4.7
10
2.2
3.3
4.7
10
0.1
0.22
0.33
0.47
1.0
2.2
3.3
4.7
50Vdc
35Vdc
25Vdc
16Vdc
10Vdc
Working
Voltage
6.3Vdc
Case
Size
5X5.5
6.3X5.5
6.3X5.5
4X5.5
6.3X5.5
6.3X5.5
4X5.5
5X5.5
6.3X5.5
6.3X5.5
4X5.5
5X5.5
6.3X5.5
4X5.5
5X5.5
5X5.5
6.3X5.5
4X5.5
4X5.5
4X5.5
4X5.5
4X5.5
5X5.5
5X5.5
6.3X5.5
Max. ESR (Ω) Max. Ripple Current (mA rms)
AT 120Hz/105°C
AT 120Hz/20°C
18.09
22
12.06
8.47
36.49
16.59
11.06
70.58
33.17
15.08
10.05
100.53
70.58
33.17
150.79
100.53
70.58
33.17
2985.67
1357.12
904.75
635.25
298.57
135.71
90.47
63.52
27
33
12
25
30
8
17
27
40
7
13
20
5.9
12
14
21
0.7
1.6
2.4
3.5
7
10
13
16
P
B
0.3mm max.
PART NUMBER SYSTEM
NACNW
100 M 16V 5x5.5
Series
RoHS Compliant
97% Sn (min.),
3% Bi (max.)
330mm (13”) Reel
Tape & Reel
Size in mm
Working Voltage
Tolerance Code M=20%, K=10%
Capacitance Code in
µF,
first 2 digits are significant
Third digit is no. of zeros, “R” indicates decimal for
values under 10µF
10
TR 13 F
Dφ
W
I
I
L
A
DIMENSIONS (mm)
Case Size Dφ ± 0.5 L max. A ± 0.2 I ± 0.2
W
P ± 0.2
4x5.5
4.0
5.5
4.3
1.8 0.5 ~ 0.8
1.0
5x5.5
5.0
5.5
5.3
2.1 0.5 ~ 0.8
1.4
6.3x5.5
6.3
5.5
6.6
2.5 0.5 ~ 0.8
2.2
®
Please review the notes on correct use, safety and precautions found on
pages T10
&
T11
of NIC’s
Electrolytic Capacitor catalog.
Also found at
www.niccomp.com/precautions
If in doubt or uncertainty, please review your specific application - process details with
NIC’s technical support personnel:
tpmg@niccomp.com
PRECAUTIONS
30
NIC COMPONENTS CORP.
www.niccomp.com
www.lowESR.com
www.RFpassives.com
www.SMTmagnetics.com
