Color-Keyed
®
Connectors for Code Copper Cables
®
®
Copper Two-Way Splicers for Up to 15KV Application
Cat.
No.
54006-TB
54007-TB
54008-TB
54009-TB
54010
54011
54012-TB
54013
54015
54018
54023
Cable+
Size
#4 AWG
#2 AWG
#1 AWG
1/0 AWG
2/0 AWG
3/0 AWG
4/0 AWG
250 Kcmil
350 Kcmil
500 Kcmil
750 Kcmil
Dimensions (in.)
A
2.00
2.13
2.25
2.38
2.38
2.63
2.69
3.19
4.13
4.13
4.75
B
.37
.41
.47
.52
.57
.63
.69
.74
.89
1.06
1.30
Installing Tools
13100A, TBM15PF* & TBM14M
Die Set
Color
Strip
Cat. No.
Code
Length
15CA29R
15CA33R
15CA37R
15CA42R
15CA45R
15CA49R
15CA54R
15CA60R
15CA71R
15CA87R
15CA106R
Gray
Brown
Green
Pink
Black
Orange
Purple
Ruby
Red
Brown
Black
1
1
⁄
2
1
5
⁄
8
1
5
⁄
8
1
3
⁄
4
1
3
⁄
4
1
13
⁄
16
1
13
⁄
16
2
1
⁄
8
2
5
⁄
8
2
5
⁄
8
* Cat. No. 15500-TB Die Adaptor required for TBM15 PF
+ Cable Size: Cancentric and Conipact strandings
F
A
A APPROX.
B
B
*Kopr-Shield
®
Cat. No.
CP8-TB
CP16
CP128
1
Contains
⁄
2
Can with Brush
Description
KOPR-SHIELD compound is a blend of
colloidal copper and inhibitors for rust
and corrosion protection; it is an anti-
sieze and conductive compound that
flow easily into threads
One lb. Can with Brush
One Gallon Can
• Prevents oxidation and corrosion-compound
flows between and around cable strands and
reduces inner-strand resistance.
*TM of Jet Lube, Inc.
U.L. listed only for use on electrical cables in cable connector assemblies, or on bus bars
rated for NEC applications up to 8 KV and 90°C.
When connecting cables for direct burial or in concrete, the cable joint area shall be
cleaned, wire brushed, and treated with a conductive anti-corrosion compound, such as
Thomas & Betts series CP8-TB.
F/57
