5962D9569301VXA datasheet, PDF

Datasheet> All Categories > Analog mixed-signal IC> The signal circuit> 5962D9569301VXA

5962D9569301VXA: Description16-CHANNEL, SGL ENDED MULTIPLEXER, CDIP28, CERDIP-28; CategoryAnalog mixed-signal IC The signal circuit; File Size198KB，6 Pages; ManufacturerRenesas Electronics Corporation; Websitehttps://www.renesas.com/

Download Datasheet Parametric Compare View All

5962D9569301VXA Overview

16-CHANNEL, SGL ENDED MULTIPLEXER, CDIP28, CERDIP-28

5962D9569301VXA Parametric

Parameter Name	Attribute value
Is it Rohs certified?	incompatible
Maker	Renesas Electronics Corporation
Parts packaging code	DIP
package instruction	DIP, DIP28,.6
Contacts	28
Reach Compliance Code	not_compliant
Analog Integrated Circuits - Other Types	SINGLE-ENDED MULTIPLEXER
JESD-30 code	R-GDIP-T28
JESD-609 code	e0
Nominal Negative Supply Voltage (Vsup)	-15 V
Number of channels	16
Number of functions	1
Number of terminals	28
Nominal off-state isolation	50 dB
On-state resistance matching specifications	126 Ω
Maximum on-state resistance (Ron)	1800 Ω
Maximum operating temperature	125 °C
Minimum operating temperature	-55 °C
Package body material	CERAMIC, GLASS-SEALED
encapsulated code	DIP
Encapsulate equivalent code	DIP28,.6
Package shape	RECTANGULAR
Package form	IN-LINE
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
power supply	+-15 V
Certification status	Not Qualified
Filter level	MIL-PRF-38535 Class V
Maximum seat height	5.92 mm
Maximum signal current	0.008 A
Maximum supply current (Isup)	2 mA
Nominal supply voltage (Vsup)	15 V
surface mount	NO
Maximum disconnect time	1000 ns
Maximum connection time	1000 ns
switch	BREAK-BEFORE-MAKE
technology	CMOS
Temperature level	MILITARY
Terminal surface	Tin/Lead (Sn/Pb)
Terminal form	THROUGH-HOLE
Terminal pitch	2.54 mm
Terminal location	DUAL
Maximum time at peak reflow temperature	NOT SPECIFIED
total dose	10k Rad(Si) V
width	15.24 mm
Base Number Matches	1

Preview

Download Datasheet

View All

HS-0546RH, HS-0547RH

Data Sheet

August 1999

File Number

3544.2

Radiation Hardened Single 16/Differential

8 Channel CMOS Analog Multiplexers with

Active Overvoltage Protection

The HS-0546RH and HS-0547RH are radiation hardened

analog multiplexers with Active Overvoltage Protection and

guaranteed r

matching. Analog input levels may greatly

exceed either power supply without damaging the device or

disturbing the signal path of other channels. Active protection

circuitry assures that signal fidelity is maintained even under

fault conditions that would destroy other multiplexers. Analog

inputs can withstand constant 70V peak-to-peak levels with

±15V

supplies and digital inputs will sustain continuous faults

up to 4V greater than either supply. In addition, signal sources

are protected from short circuiting should multiplexer supply

loss occur: each input presents 1kΩ of resistance under this

condition. These features make the HS-0546RH and

HS-0547RH ideal for use in systems where the analog inputs

originate from external equipment or separately powered

circuitry. Both devices are fabricated with 44V dielectrically

isolated CMOS technology. The HS-0546 is a 16 channel

device and the HS-0547 is an 8 channel differential version. If

input overvoltage protection is not needed, the HS-0506 and

HS-0507 multiplexers are recommended.

Speciﬁcations for Rad Hard QML devices are controlled

by the Defense Supply Center in Columbus (DSCC). The

SMD numbers listed here must be used when ordering.

Detailed Electrical Speciﬁcations for these devices are

contained in SMD 5962-95693. A “hot-link” is provided

on our homepage for downloading.

http://www.intersil.com/spacedefense/space.htm

Features

• Electrically Screened to SMD # 5962-95693

• QML Qualiﬁed per MIL-PRF-38535 Requirements

• Gamma Dose . . . . . . . . . . . . . . . . . . . . . . 1 x 10

RAD(Si)

• No Latch-Up

• No Channel Interaction During Overvoltage

• Guaranteed r

Matching

• Maximum Power Supply . . . . . . . . . . . . . . . . . . . . . . . .44V

• Break-Before-Make Switch

• Analog Signal Range

. . . . . . . . . . . . . . . . . . . . . . . . . . . .±15V

• Access Time. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.0µs

Applications

• Data Acquisition Systems

• Control Systems

• Telemetry

Ordering Information

INTERNAL

ORDERING NUMBER

MKT. NUMBER

5962D9569301V9A

HS0-0546RH-Q

5962D9569301VXA

5962D9569301VXC

5962D9569302V9A

5962D9569302VXA

5962D9569302VXC

HS1-0546RH-Q

HS1B-0546RH-Q

HS0-0547RH-Q

HS1-0547RH-Q

HS1B-0547RH-Q

TEMP. RANGE

(

-55 to 125

Pinouts

HS-0546RH GDIP1-T28 (CERDIP) OR CDIP2-T28 (SBDIP)

TOP VIEW

SUPPLY

NC 2

NC 3

IN 16 4

IN 15 5

IN 14 6

IN 13 7

IN 12 8

IN 11 9

IN 10 10

IN 9 11

GND 12

REF

ADDRESS A3 14

28 OUT

27 -V

SUPPLY

26 IN 8

25 IN 7

24 IN 6

23 IN 5

22 IN 4

21 IN 3

20 IN 2

19 IN 1

18 ENABLE

17 ADDRESS A0

16 ADDRESS A1

15 ADDRESS A0

HS-0547RH GDIP1-T28 (CERDIP) OR CDIP2-T28 (SBDIP)

TOP VIEW

SUPPLY

OUT B 2

NC 3

IN 8B 4

IN 7B 5

IN 6B 6

IN 5B 7

IN 4B 8

IN 3B 9

IN 2B 10

IN 1B 11

GND 12

REF

NC 14

28 OUT A

27 -V

SUPPLY

26 IN 8A

25 IN 7A

24 IN 6A

23 IN 5A

22 IN 4A

21 IN 3A

20 IN 2A

19 IN 1A

18 ENABLE

17 ADDRESS A0

16 ADDRESS A1

15 ADDRESS A2

CAUTION: These devices are sensitive to electrostatic discharge; follow proper IC Handling Procedures.

http://www.intersil.com or 407-727-9207

Intersil Corporation 1999

5962D9569301VXA Related Products

	5962D9569301VXA	5962D9569302V9A	5962D9569302VXA
Description	16-CHANNEL, SGL ENDED MULTIPLEXER, CDIP28, CERDIP-28	16-CHANNEL, DIFFERENTIAL MULTIPLEXER, UUC28, DIE-28	8-CHANNEL, DIFFERENTIAL MULTIPLEXER, CDIP28
Is it Rohs certified?	incompatible	conform to	incompatible
Parts packaging code	DIP	DIE	DIP
package instruction	DIP, DIP28,.6	DIE,	DIP, DIP28,.6
Contacts	28	28	28
Reach Compliance Code	not_compliant	compliant	not_compliant
Analog Integrated Circuits - Other Types	SINGLE-ENDED MULTIPLEXER	DIFFERENTIAL MULTIPLEXER	DIFFERENTIAL MULTIPLEXER
JESD-30 code	R-GDIP-T28	R-XUUC-N28	R-GDIP-T28
Nominal Negative Supply Voltage (Vsup)	-15 V	-15 V	-15 V
Number of channels	16	16	8
Number of functions	1	1	1
Number of terminals	28	28	28
Nominal off-state isolation	50 dB	50 dB	50 dB
On-state resistance matching specifications	126 Ω	126 Ω	126 Ω
Maximum on-state resistance (Ron)	1800 Ω	1800 Ω	1800 Ω
Package body material	CERAMIC, GLASS-SEALED	UNSPECIFIED	CERAMIC, GLASS-SEALED
encapsulated code	DIP	DIE	DIP
Package shape	RECTANGULAR	RECTANGULAR	RECTANGULAR
Package form	IN-LINE	UNCASED CHIP	IN-LINE
Peak Reflow Temperature (Celsius)	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED
Certification status	Not Qualified	Not Qualified	Not Qualified
Filter level	MIL-PRF-38535 Class V	MIL-PRF-38535 Class V	MIL-PRF-38535 Class V
Nominal supply voltage (Vsup)	15 V	15 V	15 V
surface mount	NO	YES	NO
Maximum disconnect time	1000 ns	1000 ns	1000 ns
Maximum connection time	1000 ns	1000 ns	1000 ns
technology	CMOS	CMOS	CMOS
Terminal form	THROUGH-HOLE	NO LEAD	THROUGH-HOLE
Terminal location	DUAL	UPPER	DUAL
Maximum time at peak reflow temperature	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED
total dose	10k Rad(Si) V	10k Rad(Si) V	10k Rad(Si) V
Maker	Renesas Electronics Corporation	-	Renesas Electronics Corporation
JESD-609 code	e0	-	e0
Maximum operating temperature	125 °C	-	125 °C
Minimum operating temperature	-55 °C	-	-55 °C
Encapsulate equivalent code	DIP28,.6	-	DIP28,.6
power supply	+-15 V	-	+-15 V
Maximum seat height	5.92 mm	-	5.92 mm
Maximum signal current	0.008 A	-	0.008 A
Maximum supply current (Isup)	2 mA	-	2 mA
switch	BREAK-BEFORE-MAKE	-	BREAK-BEFORE-MAKE
Temperature level	MILITARY	-	MILITARY
Terminal surface	Tin/Lead (Sn/Pb)	-	Tin/Lead (Sn/Pb)
Terminal pitch	2.54 mm	-	2.54 mm
width	15.24 mm	-	15.24 mm
Base Number Matches	1	1	-
