SAW Components
Low-Loss Filter
Data Sheet
B5000
190,0 MHz
Ceramic package
DCC12A
Features
q
Low-loss IF filter for GSM base stations
q
Ceramic SMD package
q
Temperature stable
7,62
1,0
1
2
3
4
5
1,7
Terminals
q
Gold plated
1,6
10
9
8
7
6
2,3
bottom view
3,81
side view
6,5
top view
13,3
Dimensions in mm, aprox. weight 0,4 g
Pin configuration
1
10
6
5
2, 4, 7, 9
3, 8
Input
Input ground
Output
Output ground
Case ground
To be grounded
Type
B5000
Ordering code
B39191-B5000-H510
Marking and Package
according to
C61157-A7-A94
Packing
according to
F61074-V8163-Z000
Electrostatic Sensitive Device
(ESD)
Maximum ratings
Operable temperature range
Storage temperature range
DC voltage
Source power
T
T
stg
V
DC
P
s
–30 / +85
–40 / +85
0
10
˚C
˚C
V
dBm
2
Nov 24, 2003
SAW Components
Low-Loss Filter
Data Sheet
B5000
190,0 MHz
Characteristics
Operating temperature range:
Terminating source impedance:
Terminating load impedance:
T = 0 - 70 ˚C
Z
S
= 50
Ω
unbalanced and matching network
Z
L
= 50
Ω
unbalanced and matching network
min.
Nominal frequency
Insertion attenuation
at
f
N
(including matching network)
Passband width
α
rel
≤
3 dB
Amplitude ripple
f
N
±
70 kHz
Group delay ripple
(p-p)
f
N
±
70 kHz
Relative attenuation
(relative to
α
N
)
f
N
±
330 kHz ... f
N
±
500 kHz
f
N
±
500 kHz ... f
N
±
50 MHz
Temperature coefficient of frequency
1)
Turnover temperature
1)
Temperature
typ.
190,0
3,5
max.
—
6,0
MHz
dB
f
N
α
N
—
—
Β
3,0dB
∆α
rel
—
0,29
—
MHz
—
∆τ
—
α
rel
27
40
±0,3
±1,0
dB
0,8
—
µs
40
50
– 0,036
35
—
—
—
—
dB
dB
ppm/K
2
˚C
TC
f
T
0
—
—
dependance of
f
c
:
f
c
(T
A
) =
f
c
(T
0
)(1 +
TC
f
(T
A
–
T
0
)
2
)
3
Nov 24, 2003
