74VHC32MTCX datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > logic> logic> 74VHC32MTCX

74VHC32MTCX: DescriptionAHC/VHC/H/U/V SERIES, QUAD 2-INPUT OR GATE, PDSO14, 4.40 MM, MO-153AB, TSSOP-14; Categorylogic logic; File Size977KB，11 Pages; ManufacturerRochester Electronics; Websitehttps://www.rocelec.com/; Environmental Compliance

Download Datasheet Parametric Compare View All

74VHC32MTCX Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	74VHC32MTCX	-	-	View	Buy Now

74VHC32MTCX Overview

AHC/VHC/H/U/V SERIES, QUAD 2-INPUT OR GATE, PDSO14, 4.40 MM, MO-153AB, TSSOP-14

74VHC32MTCX Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	Rochester Electronics
Parts packaging code	TSSOP
package instruction	TSSOP,
Contacts	14
Reach Compliance Code	unknown
series	AHC/VHC/H/U/V
JESD-30 code	R-PDSO-G14
JESD-609 code	e4
length	5 mm
Logic integrated circuit type	OR GATE
Humidity sensitivity level	1
Number of functions	4
Number of entries	2
Number of terminals	14
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
Package body material	PLASTIC/EPOXY
encapsulated code	TSSOP
Package shape	RECTANGULAR
Package form	SMALL OUTLINE, THIN PROFILE, SHRINK PITCH
Peak Reflow Temperature (Celsius)	260
propagation delay (tpd)	13 ns
Maximum seat height	1.2 mm
Maximum supply voltage (Vsup)	5.5 V
Minimum supply voltage (Vsup)	2 V
Nominal supply voltage (Vsup)	3.3 V
surface mount	YES
technology	CMOS
Temperature level	INDUSTRIAL
Terminal surface	NICKEL PALLADIUM GOLD
Terminal form	GULL WING
Terminal pitch	0.65 mm
Terminal location	DUAL
Maximum time at peak reflow temperature	30
width	4.4 mm
Base Number Matches	1
