www.hamlin.com
55110 L.E.D. Flange Mount Hall Effect Sensor Features and Benefits
Features
•
Magnetically operated position sensor
•
Digital or latching types available
•
Integral LED
•
Medium or high senstivities
•
3 wire (voltage output)
•
Vibration 50g max. @ 50-2,000Hz
•
Shock 150g max. @ 11ms
1
/
2
Sine
•
EMC to DIN 40839 (Consult Hamlin)
•
Reverse/Over Voltage Protection
•
Built in temperature compensation
Benefits
High switching speed up to 10kHz
Long life; up to 20 billion operations
Visual indication of operation
Unaffected by harsh environments
Operates in static or dynamic magnetic
field
•
Customer selection of cable length and
connector type
•
•
•
•
•
Applications
•
•
•
•
•
•
Position and limit sensing
RPM measurement
Flow metering
Commutation of brushless dc motors
Angle sensing
Magnetic encoders
DIMENSIONS (in) mm
BLOCK DIAGRAMS
(.266)
6.75
Centre of Sensitivity
(.626)
15.90
Note
Add capacitor Cn as
shown, close for the
sensor, for transient
suppression if required
General Tol.: ± (.010) 0.25
CUSTOMER OPTIONS - Switching Specifications
SPECIFICATIONS
Hall Type
Absolute Ratings
Operate
Overvoltage Protection
Vdc
Vdc
Vdc-max
Vdc-min
Vdc-max
mA-max
kHz-max
Operating
Storage
O
O
Digital Switch or Digital Latch
3 Wire
(Voltage output)
-15 to +28
+3.8 to +24
32
Vdd-2 @ 0.1mA (sinking output with internal pull-up)
0.4 @ 20mA
20
10
-40 to +85
-65 to +85
Supply Voltage
(Note 1)
Output High Voltage
Output Low Voltage
Output Current (continuously on)
Switching Speed
Temperature
C
C
Note 1 - As long as Tj (Junction Temperature) max. is not exceeded
CUSTOMER OPTIONS - Sensitivity, Cable Length and Termination Specification
TABLE 1
HALL OPTIONS
ACTIVATE DISTANCES ARE APPROXIMATE
USING
N
E
F
E
B
MAGNET
TABLE 2
N
S
d
Cable Length:-
(Cable type 24 AWG 7/32 PVC
85
o
C Double Insulated)
SELECT
OPTION
LENGTH
TABLE 3
Termination Options:-
SELECT
OPTION
DESCRIPTION
(.827L
X
HAMLIN P
/
N
.276W
X
.185H) 21
5812334000
X
7
X
4.7
(in)
mm
A
B
C
D
E
Tinned leads
Crimped terminals
6.35mm fastons
AMP MTE 2.54mm pitch
JST XHP 2.5mm pitch
Select
Hall Option
3M
Hall
Type
3 Wire Switch
Sensitivity
Gauss (Typ.)
130
Activate - d
(in) mm
(.492) 12.5
01
02
03
(3.94) 100
(11.81) 300
(19.69) 500
(29.53) 750
(39.37) 1000
3H
3 Wire Switch
59
(.709) 18.0
04
05
3L
3 Wire Latch
86
(.394) 10.0
ORDERING INFORMATION
55110
Series 55110
Hall option
Cable Length
Termination
Table 1
Table 2
Table 3
XX
XX
X
Hamlin USA
Hamlin UK
Hamlin Germany
Hamectrol France
Tel:
Tel:
Tel:
Tel:
+1 920 648 3000
•
Fax: +1 920 648 3001
•
Email: sales.us@hamlin.com
+44 (0)1379 649700
•
Fax: +44 (0)1379 649702
•
Email: sales.uk@hamlin.com
+49 (0) 6142 923920
•
Fax: +49 (0) 6142 923921
•
Email: sales.de@hamlin.com
+33 (0) 1 4687 0202
•
Fax: +33 (0) 1 4686 6786
•
Email: sales.fr@hamlin.com
INFORMATION PROVIDED ON THIS DATA SHEET IS PROVIDED FOR
INFORMATION PURPOSES ONLY AND SHOULD NOT BE RELIED UPON AS
BEING ACCURATE FOR ANY PARTICULAR PURPOSE. Product performance
may be affected by the application to which the product is put. Upon request,
HAMLIN will assist purchasers by providing information specific to any
particular application. HAMLIN disclaims any and all liability whatsoever for any
purchaser’s reliance upon the information contained on this data sheet without
further consultation with authorised representatives of HAMLIN.
Issue No:
AD
Date:
16/07/09
DCR
B6301
