PART NUMBER
597-5006-502F,507F
597-5036-502F,507F
597-5206-502F,507F
597-5406-502F,507F
597-5506-502F,507F
597-5606-502F,507F
597-5906-502F,507F
LED COLOR
RED (630nm)
RED (620nm)
ORANGE
YELLOW
REV
A
ECN NO
REVISIONS
NEW RELEASE
DRN CKD APP
BP
DATE
NO 03-22-18
597-5316-502F,507F GREEN (560nm)
597-5326-502F,507F GREEN (527nm)
WHITE
BLUE
YELLOW GREEN
CATHODE
.079
[2]
.055
[1,4 ]
.049
[1,25 ]
UNITS: mm
TOLERANCE (UNLESS OTHERWISE SPECIFIED): ±0.2mm
TAPING SPECIFICATIONS
.033
[0,85 ]
ABSOLUTE MAXIMUM RATINGS AT 25 $ C
.031
[0,8 ]
LED COLOR
RED (630nm)
.012
[0,3 ]
.039
[1]
RED (620nm)
ORANGE
YELLOW
75
30
100
5
-40 TO +85
-40 TO +100
POWER
DISSIPATON
(mW)
FORWARD
CURRENT
(mA)
PEAK FORWARD
CURRENT
(mA)
REVERSE
VOLTAGE
(V)
OPERATING
TEMPRATURE
( $ C)
STORAGE
TEMPRATURE
( $ C)
MARK
Ts
Ts
max
min
s
L
L
P
P
MEANING
MAXIMUM OF PRE-HEATING TEMP.
MINIMUM OF PRE-HEATING TEMP.
TIME FROM Tsmin TO Tsmax
REFERENCE TEMP
RETENTION TIME FOR TL
PEAK TEMP
TIME FOR PEAK TEMP
TEMP. RISING RATE
TEMP. DECREASING RATE
CONDITIONS
180
140
$ C
$ C
GREEN (560nm)
GREEN (527nm)
BLUE
WHITE
YLW GREEN
81
70
68
20
12
-40 TO +100 -40 TO +100
t
T
t
OVER 60 sec.
230-250
$ C
.354
[9]
1
2
WITHIN 40 sec.
250
$ C (MAX)
2 x R.012
[0,3 ]
LED COLOR
OPERATING CHARACTERISTICS AT 25 $ C
LUMINOUS
INTENSITY
(mcd)
IF (mA)
MIN
40
63
20
100
6.3
5
56
14
56
25
TYP
120
160
45
140
140
36
16
75
MIN
625
615
602
587
569
557
519
464
DOMINANT
WAVELENGTH
(nm)
TYP.
630
620
605
590
572
560
527
470
MAX
635
625
608
593
575
563
536
476
10 @ VR=12V
10 @ VR=5V
REVERSE
CURRENT
MAX
FORWARD
VOLTAGE
TYP.
2 @ IF=20mA
T
t
WITHIN 10 sec.
UNDER 3 $ C/sec.
OVER -3 $ C/sec.
T / t
R
T / t
D
RED (630nm)
.043
[1,1 ]
RED (620nm)
ORANGE
YELLOW
GREEN (560nm)
GREEN (527nm)
.049
[1,25 ]
BLUE
WHITE
YLW GREEN
2.2 @ IF=20mA
3 @ IF=5mA
2.9 @ IF=5mA
RECOMMENDED RoHS SOLDER PROFILE
(X,Y) (0.30,0.28)
.043
[1,1 ]
PIN 1
CATHODE
PIN 2
ANODE
LED SCHEMATIC
.049
[1,25 ]
NOTES:
1. DIALIGHT P/N: 597-5XX6-502F, 597-5XX6-507F
SUFFIX -502F FOR 20 PCS ON A SAMPLE TAPE STRIP
SUFFIX -507F FOR 7" DUANETER REEL, PACKAGED 3000 PCS PER REEL.
2. LABELING FOR REEL AND OUTSIDE OF ALUMINUM BAG:
DIALIGHT P/N, QUANTITY PER REEL, DATE CODE, INTENSITY BIN CODE,
LOT NUMBER AND COUNTRY OF ORIGIN
3. TAPE AND REEL LEDS MAY REQUIRE RE-TAPING AFTER TWELVE MONTHS.
4. PIN NUMBERS ARE FOR REFERENCE ONLY, DESIGNATION NON-EXISTENT
ON PART.
5. THIS PRODUCT IS RoHS COMPLIANT. EACH BAG IS TO BE MARKED WITH RoHS
COMPLIANT LABEL OR EQUIVALENT MARKINGS. LED MUST BE Pb FREE.
6. ESD WITHSTAND VOLTAGE 4000V MAX PER JS-001-2014.
7. MSL LEVEL 4
THIS DRAWING AND THE CONTENTS HEREIN ARE CONFIDENTIAL AND THE SOLE
PROPERTY OF DIALIGHT CORP. REPRODUCTION OF THIS DRAWING OR
CONSTRUCTION OF ANY PARTS WITHIN THIS DRAWING ARE FORBIDDEN WITHOUT
THE WRITTEN CONSENT OF DIALIGHT CORP.
SCALE: 25.000
DIALIGHT CORP INTERNAL REFERENCE ONLY = 3D MODEL :
DRAWING NUMBER
5975006507F-A.1
REV
ALL DIM'S IN: INCHES (MM)
TOLERANCES:
UNLESS OTHERWISE SPECIFIED
FRACTIONS:
DECIMALS (.XX):
# 1/64
TITLE
# .005
MATERIAL
# .01
C-18370
SM LED 0805 PACKAGE
A
RECOMMENDED SOLDER PAD LAYOUT
OBSERVE PRECAUTIONS FOR
HANDLING ELECTROSTATIC
SENSITIVE DEVICES
ATTENTION:
DECIMALS (.XXX):
ANGLES:
# 1 $
DECIMALS (.XXXX):
FINISH
# .0005
FSCM
83330
1501 ROUTE 34 SOUTH
FARMINGDALE, NJ 07727
(732) 919-3119
www.dialight.com
SHEET
1
OF
1
FAMILY TABLE:
