SOLID STATE DEVICES, INC.
14830 Valley View Blvd * La Mirada, Ca 90638
Phone: (562) 404-7855 * Fax: (562) 404-1773
SDR2410CTM
SDR2412CTM
24AMPS
1200 VOLTS
65 nsec
ULTRAFAST
CENTERTAP RECTIFIER
TO-254 (M)
TO-254Z (Z)
Designer's Data Sheet
FEATURES:
•
•
•
•
•
•
•
•
•
Ultra Fast Recovery: 65 nsec Maximum
High Surge Rating
Low Reverse Leakage Current
Low Junction Capacitance
Hermetically Sealed Package
Ultrasonic Aluminum Wire Bonds
Ceramic Seal for Improved Hermeticity Available
Common Anode and Doubler Versions Available
TX, TXV and Space Level Screening Available
Maximum Ratings
Peak Repetitive Reverse and
DC Blocking Voltage
SDR2410CTM
SDR2412CTM
SYMBOL
V
RRM
V
RWM
V
R
Io
I
FSM
T
OP
& Tstg
VALUE
1000
1200
24
75
-65 TO +200
1.2
2.4
UNITS
Volts
Average Rectified Forward Current.
(Resistive load, 60Hz, Sine Wave, T
A
=25
o
C) 1/
Peak Surge Current
(8.3 ms Pulse, Half Sine Wave, T
C
= 55
o
C, I
O
= 12A) 2/
Operating and Storage Temperature
Maximum Thermal Resistance
Junction to Case, 1/
Junction to Case, 2/
NOTE:
1/
Both Legs Tied Together
2/
Per Leg.
Amps
Amps
o
C
R
0
JC
o
C/W
NOTE:
All specifications are subject to change without notification.
SCD's for these devices should be reviewed by SSDI prior to release.
DATA SHEET #: RC0068A
SDR2410CTM
SDR2412CTM
Electrical Characteristics (Per Leg)
Instantaneous Forward Voltage Drop
(T
A
= 25
o
C, 300µsec Pulse )
I
F
= 12A
SOLID STATE DEVICES, INC.
14830 Valley View Blvd * La Mirada, Ca 90638
Phone: (562) 404-7855 * Fax: (562) 404-1773
SYMBOL
V
F1
V
F2
V
F3
I
R1
I
R2
C
J
t
RR
MINIMUM
--
--
--
--
--
--
MAXIMUM
1.9
1.8
2.2
50
2.5
60
65
UNITS
V
DC
V
DC
µ
A
mA
pF
nsec
Instantaneous Forward Voltage Drop
T
A
= 100
o
C
(I
F
= 12A, 300µsec pulse )
T
A
= -55
o
C
Reverse Leakage Current
(80% of Rated V
R,
300µs pulse min.)
Junction Capacitance
(V
R
= 10V
DC
, T
A
= 25
o
C, f = 1MHz)
Reverse Recovery Time
(I
F
= 500mA, I
R
= 1.0A, I
RR
= 250 mA, T
A
= 25
o
C)
CASE OUTLINE: TO-254 (Sufix M)
PIN 1: ANODE 1
PIN 2: CATHODE
PIN 3: ANODE 2
T
A
= 25
o
C
T
C
= 100
o
C
CASE OUTLINE: TO-254Z (Sufix Z)
PIN 1: ANODE 1
PIN 2: CATHODE
PIN 3: ANODE 2
