Part Number

Search

2-1623720-0

Description
RESISTOR
CategoryPassive components    The resistor
File Size147KB,2 Pages
ManufacturerTE Connectivity
Websitehttp://www.te.com
Environmental Compliance
Download Datasheet Parametric View All

2-1623720-0 Online Shopping

Suppliers Part Number Price MOQ In stock
2-1623720-0 - - View Buy Now

2-1623720-0 Overview

RESISTOR

2-1623720-0 Parametric

Parameter NameAttribute value
Is it Rohs certified?conform to
MakerTE Connectivity
package instruction,
Reach Compliance Codecompliant
Factory Lead Time21 weeks 6 days
Installation featuresTHROUGH HOLE MOUNT
Number of terminals2
Maximum operating temperature200 °C
Minimum operating temperature-40 °C
Package shapeTUBULAR PACKAGE
method of packingBULK
Rated power dissipation(P)2 W
resistance3.9 Ω
Resistor typeFIXED RESISTOR
surface mountNO
Temperature Coefficient1300 ppm/°C
Terminal shapeWIRE
Tolerance10%
Operating Voltage400 V
Base Number Matches1
This browser does not have Java enabled.
TE Connectivity
 My Cart |
 My Part Lists | Sign In/Register
English
(Change)
Have a Question?
Chat with a Product
Information Specialist
What can we help you find?
Products
Industries
Resources
About TE
My Account
Innovation
Support Center
Home > Products > Resistors > Product Feature Selector > Product Details
CCR23R9KB Product Details
Fixed Resistors

Always EU RoHS/ELV Compliant
 (
Statement of Compliance
)
Product Highlights:
Fixed Resistor
Resistor Type = Power Resistor
Resistance Selection = <1K Ω
Resistance = 3.9 Ω
Power Rating = 2.00 W
View all Features
 Share
 Print
 Email
Quick Links
Pricing & Availability
Search for Tooling
Product Feature Selector
Contact Us About This Product
CCR23R9KB
(2­1623720­0)
TE Internal Number: 2­1623720­0
 Active
Add to My Part List
Request Sample
Find Similar Products
Buy Product
View 3D PDF
Documentation & Additional Information
Product Drawings:
None Available
Catalog Pages/Data Sheets:
1309350_PASSIVE_COMPONENT (PDF, English)
Ceramic Composition Resistors ­ Type CCR Series ­ Ty... (PDF, English)
4­1773460­6_RESISTIVE_SOLUTIONS_RAIL (PDF, English)
8­1773459­4_POWER_FILTERING_AND_RESISTIVE_SOLUTIONS_... (PDF, English)
Product Specifications:
None Available
Application Specifications:
None Available
Instruction Sheets:
None Available
CAD Files: (CAD Format & Compression Information)
2D Drawing (DXF, Version BA)
3D Model (IGES, Version BA)
3D Model (STEP, Version BA)
Additional Information:
Product Line Information
Related Products:
Tooling
List all Documents
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
Product Type = Fixed Resistor
Resistor Type = Power Resistor
Element = Ceramic Composition
Electrical Characteristics:
Resistance Selection (Ω) = <1K
Resistance (Ω) = 3.9
Power Rating (W) = 2.00
Tolerance (%) = 10
Termination Features:
Termination Type = Tinned Copper Leads
Body Features:
Mount Style = Axial Leaded
Package, Component Size = 22.5 x 8
Configuration Features:
Number of Terminations = 2
Number of Resistors = 1
Industry Standards:
RoHS/ELV Compliance = RoHS compliant, ELV compliant
Lead Free Solder Processes = Wave solder capable to 240°C, Wave
solder capable to 260°C, Wave solder capable to 265°C
RoHS/ELV Compliance History = Always was RoHS compliant
Conditions for Usage:
Temperature Coefficient (ppm/°C) = ±1300
Operation/Application:
Application = High Voltage
Packaging Features:
Package Type = Loose Piece ­ Box
Other:
Series = CCR
Brand = CGS
