PRELIMINARY
SOLID STATE DEVICES, INC.
14005 Stage Road * Santa Fe Springs, Ca 90670
Phone: (562) 404-4474 * Fax: (562) 404-1773
SED110LB30
SED110LE30
110 AMP
30 VOLTS
SCHOTTKY
RECTIFIER
SEDPACK 3
Designer's Data Sheet
FEATURES:
Low Reverse Leakage
Low Forward Voltage Drop
Hermetically Sealed Power Surface Mount Package
Guard Ring for Overvoltage Protection
Eutectic Die Attach
175
o
C Operating Temperature
TX, TXV and Space Level Screening Available
Maximum Ratings
Peak Repetitive Reverse and DC Blocking Voltage
Average Rectified Forward Current
(Resistive Load, 60Hz, Sine Wave, T
C
= 100
o
C
Peak Surge Current
(8.3 ms Pulse, Half Sine Wave Superimposed on Io, allow
junction to reach equilibrium between pulses, T
A
= 25
o
C)
Operating and Storage Temperature
Maximum Thermal Resistance
Junction to Case
SYMBOL
V
RRM
V
RWM
V
R
Io
I
FSM
Top & Tstg
R
2JC
VALUE
30
110
1000
-55 TO +175
0.3
UNITS
Volts
Amps
Amps
o
C
o
C/W
NOTE:
All specifications are subject to change without notification.
SCD's for these devices should be reviewed by SSDI prior to release.
DATA SHEET #: SH0015A
SED110LB30
SED110LE30
Electrical Characteristics
Instantaneous Forward Voltage Drop
(I
F
= 25A
DC
, T
A
= 25
o
C, 300:s Pulse)
(I
F
= 50A
DC
, T
A
= 25
o
C, 300:s Pulse)
(I
F
= 110A
DC
, T
A
= 25
o
C, 300:s Pulse)
Instantaneous Forward Voltage Drop
(I
F
= 110A
DC
, T
A
= 125
o
C, 300:s Pulse)
Reverse Leakage Current
Rated V
R
, T
A
= 25
o
C, 300:sec pulse minimum
Reverse Leakage Current
Rated V
R
, T
A
= 125
o
C, 300:sec pulse minimum
Junction Capacitance
(V
R
= 5V
DC
, T
A
= 25
o
C, f = 1MHz)
CASE OUTLINE:
P/N SED110KB30
PRELIMINARY
SOLID STATE DEVICES, INC.
14005 Stage Road * Santa Fe Springs, Ca 90670
Phone: (562) 404-4474 * Fax: (562) 404-1773
SYMBOL
V
F1
V
F2
V
F3
V
F4
I
R1
I
R2
C
J
VALUE
0.40
0.46
0.55
0.52
7.5
500
7500
UNITS
V
DC
V
DC
mA
mA
pF
CASE OUTLINE:
P/N SED110KE30
POWER DERATING CURVE
PERCENT OF MAXIMUM FORWARD
CURRENT RATING (%)
100
FORWARD VOLTAGE @T
A
= 25
o
C
0.6
FORWARD VOLTAGE (V)
0
25
50
75
100
125
150
175
200
90
80
70
60
50
40
30
20
10
0
0.55
0.5
0.45
0.4
0.35
0.3
0
20
40
60
80
100
120
140
160
CASE TEMPERATURE (
o
C)
FORWARD CURRENT (A)
