935320783557 Overview

Interface Circuit

935320783557 Parametric

Parameter Name	Attribute value
Maker	NXP
package instruction	,
Reach Compliance Code	unknown
Telecom integrated circuit types	INTERFACE CIRCUIT
Base Number Matches	1

Preview

Download Datasheet

View All

FS6500, FS4500

Rev. 1.0 — 14 December 2017

Safety Power System Basis Chip with CAN FD and LIN

Transceivers

Short data sheet: advance information

General description

The FS6500/FS4500 SMARTMOS devices are a multi-output, power supply, integrated

circuit, including CAN Flexible Data (FD) and/or LIN transceivers, dedicated to the

automotive market.

Multiple switching and linear voltage regulators, including low-power mode (32 μA) are

available with various wake-up capabilities. An advanced power management scheme

is implemented to maintain high efficiency over a wide range of input voltages (down to

2.7 V) and output current ranges (up to 2.2 A).

The FS6500/FS4500 includes configurable fail-safe/fail silent safety behavior and

features, with two fail-safe outputs, becoming a full part of a safety oriented system

partitioning, to reach a high integrity safety level (up to ASIL D).

The built-in CAN FD interface fulfills the ISO 11898-2 and -5 standards. The LIN interface

fulfills LIN protocol specifications 2.0, 2.1, 2.2, and SAEJ2602-2.

Features

•

Battery voltage sensing and MUX output pin

•

Highly flexible SMPS pre-regulator, allowing two topologies: non-inverting buck-boost

and standard buck

•

Family of devices to supply MCU core from 1.0 V to 5.0 V, with SMPS (0.8 A, 1.5 A or

2.2 A) or LDO (0.5 A)

•

36 V maximum input operating voltage

•

Linear voltage regulator dedicated to auxiliary functions, or to sensor supply (V

CCA

tracker or independent), 5.0 V or 3.3 V

•

Linear voltage regulator dedicated to MCU A/D reference voltage or I/Os supply (V

CCA

5.0 V or 3.3 V

•

3.3 V keep alive memory supply available in low-power mode

•

Long duration timer, counting up to 6 months with 1.0 s resolution

•

Multiple wake-up sources in low-power mode: CAN, LIN, IOs, LDT

•

Five configurable I/Os

Applications

•

Drive train electrification (BMS, hybrid EV and HEV, inverter, DCDC, alterno starter)

Drive train - chassis and safety (active suspension, steering, safety domain gateway)

Power train (EMS, TCU, gear box)

ADAS (LDW, Radar, sensor fusion safety area)
