lVDS 7x5mm 2.5V Oscillator
F4710 SERiES
FEATURES
•
2.5V Operation
RoHS compliant / Pb Free
XpressO
®
Equivalent
FXO-LC72
Why XpressO?
Lower Cost, Faster Delivery, Low Jitter!
Rev. 1/22/2009
•
•
•
•
LVDS Output
Differential Outputs
Standby Function
Tape and Reel
(2,000 pcs. STD)
Model
Number
F4710
F4710R
F4715
F4715R
F4716
F4716R
F4718
• PART nUMbER SElEcTiOn
Learn More - Internet Required
Part Number
710-Frequency-xxxxx
711-Frequency-xxxxx
712-Frequency-xxxxx
713-Frequency-xxxxx
714-Frequency-xxxxx
715-Frequency-xxxxx
716-Frequency-xxxxx
Operating
Frequency
1
Stability Temperature (ºC)
-10 ~ +70
±100PPM
-40 ~ +85
±100PPM
-10 ~ +70
±50PPM
-40 ~ +85
±50PPM
-10 ~ +70
±25PPM
-40 ~ +85
±25PPM*
-10 ~ +70
±20PPM*
Frequency
Range (MHz)
75.000 ~ 270.000
75.000 ~ 270.000
75.000 ~ 270.000
75.000 ~ 270.000
75.000 ~270.000
75.000 ~ 170.000
75.000 ~ 170.000
• ElEcTRicAl cHARAcTERiSTicS
PARAMETERS
Frequency Range (F
o
)
Storage Temperature Range (T
stg
)
Supply Voltage
(V
dd
)
Input Current
(I
dd
)
Differential Output Voltage
(V
od
) (Out 1 - Out 2)
Offset Voltage (V
os
)
Differential Output Swing (V
o
p-p)
Output Symmetry (Output Crossing Point)
Rise Time (T
r
) (20% ~ 80% Vp-p)
Fall Time (T
f
) (80% ~ 20% Vp-p)
Output Load (Out 1 - Out 2)
Standby Current
Start-up Time
(T
s
)
Output Disable Time
2
Output Enable Time
2
1
MAX
(unless otherwise noted)
75.000 ~ 270.000 MHz
-55ºC ~ +125ºC
2.5V ± 5%
63mA
0.247V ~ 0.454V
(0.33V Typical)
1.125V ~ 1.375V
(1.25V Typical)
0.25Vp-p Min
45% ~ 55%
0.7nS
0.7nS
100 Ohms Typical
30µA
10mS
200nS
10mS
Inclusive operating temperature range, input voltage change, load change, aging,
shock, and vibration. (*F4716R, F4718R: Excludes Shock/Vibration)
2
An internal pullup resistor from pin 1 to pin 6 allows active output if pin 1 is left open.
Note: A 0.01µF bypass capacitor should be placed between
V
dd
(Pin 6) and GND (Pin 3) to
minimize power supply line noise.
Drawing is for reference to critical specifications defined by size measurements.
Certain non-critical visual attributes, such as side castellations, reference pin shape, etc. may vary.
All specifications subject to change without notice.
All dimensions are in millimeters.
• EnAblE / DiSAblE FUncTiOn
OUTPUT (Pin 4)
(Pin 1)
ACTIVE
OPEN
2
'1' Level V
ih
≥
70% V
dd
ACTIVE
'0' Level V
il
≤
30% V
dd
High Z
OUTPUT (Pin 5)
ACTIVE
ACTIVE
High Z
FOXElectronics
5570 Enterprise Parkway Fort Myers, Florida 33905 USA +1.239.693.0099 FAX +1.239.693.1554
http://www.foxonline.com
© 2009 FOX ELECTRONICS | ISO9001:2000 Certified
EMEA
Tel/Fax: +44 .1767.312632 |
Asia
Hong Kong Tel: +852.2854.4285 Fax +852.2854.4282
|
Japan
Tel: +81.3.3374/2079 Fax: +81.3.3374.5221
