ISSUED DATE :2005/07/11
REVISED DATE :
G 5 E 111 8
1A Positive Low Dropout Fixed-mode Regulator With EN Function
Description
The G5E1118 is a low dropout positive fixed-mode regulator with minimum of 1A output current capability. The product is specifically
designed to provide well-regulated supply for low voltage IC applications such as high-speed bus termination and low current 3.3V logic
supply. G5E1118 is also well suited for other applications such as VGA cards. The product is guaranteed to have <1.4V dropout at full load
current making it ideal to provide well regulated outputs 1.5V to 12V with up to 18V input supply. The product offers a TTL-Logic
compatible enable pin.
Features
&
maximum dropout voltage at full load current
1.4V
& Built-in thermal shutdown
& Output current limiting
& Fixed output voltage 1.5V, 1.8V, 2.5V, 3.3V, 5.0V, 9.0V, 12V
& Fast transient response
& Good noise rejection
& Enable function
Applications
&
peripheral
PC
& Communication
& CDROM..
Package Dimensions
REF.
A
b
c
D
E
L4
Millimeter
Min.
Max.
4.40
4.80
0.76
1.00
0.36
0.50
8.60
9.00
9.80
10.4
14.7
15.3
REF.
L5
c1
L
e
L1
Ø
Millimeter
Min.
Max.
6.20
6.60
1.25
1.45
13.25
14.25
1.70 REF.
2.60
2.89
3.71
3.96
Typical Circuit
G5E1118
Page: 1/3
ISSUED DATE :2005/07/11
REVISED DATE :
Pin Descriptions
Name
GND
V
OUT
V
IN
EN
NC
Symbol
V
IN
V
EN
P
D
T
ST
T
OP
Description
Ground
The output of the regulator. A minimum of 10uF capacitor must be connected from this pin to ground to insure stability.
The input pin of regulator. Typically a large storage capacitor is connected from this pin to ground to insure that the input
voltage does not sag below the minimum dropout voltage during the load transient response .This pin must always be 1.3V
higher than V
OUT
in order for the device to regulate properly.
This input pin of regulator. TTL/CMOS compatible input Logic high= disable output, Logic Low or open= output enable.
( internal pull-down resistor~100K).
No connection.
Absolute Maximum Ratings
Parameter
DC Supply Voltage
Enable Pin Voltage
Power Dissipation
Storage Temperature Range
Operating Junction Temperature Range
Ratings
-0.3 to 18
7
Internally Limited
-65 ~ + 150
0 ~ + 150
Unit
V
V
:
:
Electrical Characteristics
(Under operating Conditions)
Output Voltage
Parameter
Conditions
MIN
1.470
1.764
2.450
3.235
4.900
8.820
11.760
-
-
-
-
-
-
-
-
-
1.1
-
-
1.6
-
-
-
-
-
-
-
TYP MAX UNIT
1.500
1.800
2.500
3.300
5.000
9.000
12.00
0
-
12
15
20
26
40
70
100
1.3
-
5
-
-
-
-
0.008
60
0.5
85
0.65/2.7
Line Regulator
Load Regulation
G5E1118-15
G5E1118-18
G5E1118-25
G5E1118-33
G5E1118-50
G5E1118-90
G5E1118-12
G5E1118-XX
G5E1118-15
G5E1118-18
G5E1118-25
G5E1118-33
G5E1118-50
G5E1118-90
G5E1118-12
G5E1118-XX
Io=10mA,
T
J
=25 : , 3.0V V
IN
15V
Io=10mA,
T
J
=25 : , 3.3V V
IN
15V
Io=10mA,
T
J
=25 : , 4.0V V
IN
15V
Io=10mA,
T
J
=25 : , 4.8V V
IN
15V
Io=10mA,
T
J
=25 : , 6.5V V
IN
15V
Io=10mA,
T
J
=25 : , 10.5V V
IN
18
Io=10mA,
T
J
=25 : , 13.5V V
IN
18V
Io=10mA,
T
J
=25 : , V
OUT
+1.5< V
IN
<18V
V
IN
=3.0V, 0mA<Io<1A, T
J
=25 : ,
(Note 1, 2)
V
IN
=3.3V, 0mA<Io<1A, T
J
=25 : ,
(Note 1, 2)
V
IN
=4.0V, 0mA<Io<1A, T
J
=25 : ,
(Note 1, 2)
V
IN
=5.0V, 0mA<Io<1A, T
J
=25 : ,
(Note 1, 2)
V
IN
=8.0V, 0mA<Io<1A, T
J
=25 : ,
(Note 1, 2)
V
IN
=12.0V, 0mA<Io<1A, T
J
=25 : ,
(Note 1, 2)
V
IN
=15.0V, 0mA<Io<1A, T
J
=25 : ,
(Note 1, 2)
Io=1A,
V
OUT
=0.1 V
OUT
1.530
1.836
2.550
3.365
5.100
9.180
12.24
0
0.2
15
18
25
33
50
90
120
1.4
-
10
0.8
-
10
80
0.04
70
-
-
-
V
V
V
V
V
V
V
%
mV
mV
mV
mV
mV
mV
%
V
A
mA
V
A
%/W
dB
%
: /W
: /W
Dropout Voltage
(V
IN
-V
OUT
)
Current Limit
Minimum Load Current
Enable Input Voltage
V
EN
Enable Input Current
I
EN
Thermal Regulation
Ripple Rejection
Temperature Stability
JA
Thermal Resistance
Junction–to-Ambient
(No heat sink ;No air flow)
JC
Thermal Resistance
Control Circuitry/Power Transistor
Junction-to-Case
G5E1118-XX
(V
IN
-V
OUT
)=5V
G5E1118-XX
0 : T
J
125 :
Logic Low (ON)
Logic High (OFF)
V
EN
=0.8V
V
EN
=2.0V
T
A
=25 : , 30ms pulse
F=120Hz, C
OUT
=25uF, Tantalum,
Io=1A
G5E1118-XX
V
IN
=V
OUT
+3V
Io=10mA
Note 1: See thermal regulation specifications for charges in output voltage due to heating effects. Line and load regulation are measured
at a constant junction temperature by low duty cycle pulse testing. Load regulation is measured at the output lead=1/8” from the
package.
Note 2: Line and load regulations are guaranteed up to the maximum power dissipation of 15W. Power dissipation is determined by the
input/output differential and the output current. Guaranteed maximum power dissipation will not be available over the full
input/output range
Note 3: Quiescent current is defined as the minimum output current required to maintain regulation. At 12V input/output differential the
device is guaranteed to regulate if the output current is greater than 10mA.
G5E1118
Page: 2/3
ISSUED DATE :2005/07/11
REVISED DATE :
Typical Performance Characteristics
I load=800mA
Important Notice:
All rights are reserved. Reproduction in whole or in part is prohibited without the prior written approval of GTM.
GTM reserves the right to make changes to its products without notice.
GTM semiconductor products are not warranted to be suitable for use in life-support Applications, or systems.
GTM assumes no liability for any consequence of customer product design, infringement of patents, or application assistance.
Head Office And Factory:
Taiwan:
No. 17-1 Tatung Rd. Fu Kou Hsin-Chu Industrial Park, Hsin-Chu, Taiwan, R. O. C.
TEL : 886-3-597-7061 FAX : 886-3-597-9220, 597-0785
China:
(201203) No.255, Jang-Jiang Tsai-Lueng RD. , Pu-Dung-Hsin District, Shang-Hai City, China
TEL : 86-21-5895-7671 ~ 4 FAX : 86-21-38950165
G5E1118
Page: 3/3
